porsche 2008 (997-1 gt3) radiator parts diagram

105-018 - RADIATOR

Porsche 2008 (997-1 GT3) RADIATOR Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 1
            MPN: 99610603775
            RADIATOR
            from £491.31
            from £491.31
            RADIATOR Genuine Porsche Part - New (to order)
            # 2
            MPN: 99750448792
            retaining frame
            from £106.92
            from £106.92
            retaining frame Genuine Porsche Part - New (to order)
            # 3
            MPN: 99750448580
            retaining frame
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
            # 4
            MPN: 93011343000
            RUBBER ISOLATOR
            from £11.45
            from £11.45
            RUBBER ISOLATOR Genuine Porsche Part - New (to order)
            # 5
            MPN: 90037803501
            SCREW, HEX. HD.
            M 6 X 16
            from £0.91
            from £0.91
            screw, hex. hd. - M 6 X 16 - D - MJ 1999>> Genuine Porsche Part - New (to order)
            # 6
            MPN: 99959188201
            SPEED NUT
            M 6
            from £2.29
            from £2.29
            speed nut - M6 Genuine Porsche Part - New (to order)
            # 7
            MPN: 99907204801
            SCREW, HEX. HD.
            M 8 X 25
            SCREW, HEX. HD Genuine Porsche Part - New (to order)
            # 8
            MPN: 99908444701
            HEX. NUT
            M 8
            hex. nut - M 8 Genuine Porsche Part - New (to order)
            # 8
            MPN: PAF003923
            HEX. NUT
            M 8
            from £0.87
            from £0.87
            This part replaces part number 99908444709
            hex. nut - M 8 Genuine Porsche Part - New (to order)
            # 9
            MPN: 99757514191
            AIR DUCT
            from £97.48
            from £97.48
            AIR DUCT Genuine Porsche Part - New (to order)
            # 10
            MPN: 99710663991
            WATER HOSE
            supply
            from £43.10
            from £43.10
            WATER HOSE Genuine Porsche Part - New (to order)
            # 11
            MPN: 99710663891
            WATER HOSE
            RETURN LINE
            from £43.10
            from £43.10
            WATER HOSE Genuine Porsche Part - New (to order)
            # 12
            MPN: 99710656500
            ADAPTER
            RADIATOR
            from £16.14
            from £16.14
            ADAPTER Genuine Porsche Part - New (to order)
            # 13
            -
            SEE ILLUSTRATION:
            105-015
            # 14
            MPN: 99610654571
            PLUG
            RADIATOR
            from £14.25
            from £14.25
            PLUG Genuine Porsche Part - New (to order)
            # -
            -
            RETAINING SPRING
            # -
            -
            AIR DUCT
            No longer use the part here
            # -
            -
            AIR DUCT
            # -
            -
            HEX. NUT
            T5
