801-070 - trims
Porsche 2009 (997-2 GT3) TRIMS Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 99750452702
COVER
lhd (PR:098)
from £148.11
from £148.11
# 1
MPN: 99750452701
COVER
rhd (PR:099)
from £148.11
from £148.11
# 1
MPN: 99750452701
COVER
front (PR:664)
from £148.11
from £148.11
# 2
MPN: 99904902840
PLASTIC NUT
T 5
Supersession
Supersession
# 3
MPN: 99750404300
COVER
center
from £167.47
from £167.47
# 4
MPN: 99750434303
COVER
left | center
from £129.43
from £129.43
This part replaces part number 99750434302
# 4
MPN: 99750434403
COVER
right | center
from £129.43
from £129.43
# 5
MPN: 99750462992
COVER
rear
from £114.35
from £114.35
# 6
MPN: 99750439390
TRIM
LEFT
Supersession
Supersession
# -
-
SATIN BLACK
This part replaces part number 99750439390
# 6
MPN: 99750439490
TRIM
RIGHT
Supersession
Supersession
# -
-
SATIN BLACK
This part replaces part number 99750439490
# -
-
NUT
ST4,8
# 7
MPN: 99750442901
COVER
TRANSMISSION
from £104.75
from £104.75
# 8
MPN: 99950779509
SPEED NUT
ST 4,8
Supersession
Supersession
# 9
MPN: 99907350501
tapping screw
ST 4,8 X 16
Supersession
Supersession
# 10
MPN: 99650547100
heat deflector
center
from £52.24
from £52.24
# 11
MPN: 99750547702
heat deflector
LEFT
from £91.51
from £91.51
# 11
MPN: 99750547802
heat deflector
RIGHT
from £91.51
from £91.51
# 12
MPN: 99904902509
SHOULDERED NUT
T 5
from £0.91
from £0.91
# 13
MPN: 99750463500
CLAMP
from £5.06
from £5.06
# 14
MPN: 99757518300
AIR DUCT
BRAKE
from £88.17
from £88.17
# 14
MPN: 99757518400
AIR DUCT
BRAKE
from £88.17
from £88.17
# 15
MPN: 99750443190
ENGINE COVER
(PR:074,172, 193)
from £6,960.82
from £6,960.82
# 16
MPN: 999073295A2
FILLISTER HD. SCREW
from £6.39
from £6.39
