porsche 2010 (997-2 turbo / gt2 rs) oil pan parts diagram

104-002 - OIL PAN

Porsche 2010 (997-2 Turbo / GT2 RS) OIL PAN Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                      #
                      Part number
                      Description
                      Key
                      Price
                      # 1
                      MPN: 9A110703271
                      OIL SUMP-LOWER PART
                      Discontinued part
                      OIL SUMP-LOWER PART Genuine Porsche Part - New (to order)
                      # 1
                      MPN: 9A110703270
                      OIL SUMP-LOWER PART
                      Discontinued part
                      OIL SUMP-LOWER PART Genuine Porsche Part - New (to order)
                      # 1
                      MPN: 9A110703275
                      OIL PAN
                      Lower part
                      from £658.04
                      from £658.04
                      This part replaces part number 9A110703200 - and 1 more. Click to view details
                      OIL PAN Genuine Porsche Part - New (to order)
                      # 2
                      MPN: 9A110732502
                      GASKET FOR OIL PAN
                      from £20.67
                      from £20.67
                      GASKET FOR OIL PAN Genuine Porsche Part - New (to order)
                      # 3
                      MPN: 9A110731300
                      TORX SCREW
                      M 6 X 25
                      TORX SCREW Genuine Porsche Part - New (to order)
                      # 4
                      MPN: 90012310630
                      SEAL RING
                      A 18 X 24
                      from £1.43
                      from £1.43
                      This part replaces part number 90012300930
                      OIL DRAIN PLUG SEAL RING, A 18 X 24 Genuine Porsche Part - New In stock
                      Alternative (#95110093000) Maintenance set - - for - Periodic maintenance - comprising: Genuine Porsche Part - New (to order)
                      # 5
                      MPN: 90021902031
                      THREADED PLUG
                      M 18 X 1,5
                      Supersession
                      Supersession
                      Genuine Porsche Part (no longer available to order)
                      # 6
                      MPN: 9A110724370
                      FILLER PLATE
                      Discontinued part
                      FILLER PLATE Genuine Porsche Part - New (to order)
                      # 6
                      MPN: 9A110724375
                      FILLER PLATE
                      from £104.79
                      from £104.79
                      FILLER PLATE Genuine Porsche Part - New (to order)
                      # 7
                      MPN: 90038501901
                      TORX SCREW
                      M6 x 20
                      Supersession
                      Supersession
                      Genuine Porsche Part (no longer available to order)
                      # 8
                      MPN: 9A110742070
                      oil separator
                      from £116.82
                      from £116.82
                      oil separator Genuine Porsche Part - New (to order)
                      # 9
                      MPN: 9A110738301
                      oil separator
                      from £212.45
                      from £212.45
                      oil separator Genuine Porsche Part - New (to order)
                      # 10
                      MPN: 9A110732700
                      SEAL RING
                      from £11.07
                      from £11.07
                      SEAL RING Genuine Porsche Part - New (to order)
                      # 11
                      MPN: 9A110738001
                      oil separator
                      from £212.45
                      from £212.45
                      oil separator Genuine Porsche Part - New (to order)
                      # 12
                      MPN: 94810743910
                      O-RING
                      20,0 X 3,8 |
                      D >> - MJ 2011
                      from £4.99
                      from £4.99
                      O-RING Genuine Porsche Part - New (to order)
                      # 12
                      MPN: 99970765140
                      O-RING
                      20,0 X 3,8 N |
                      D - MJ 2012>>
                      from £7.32
                      from £7.32
                      O-RING Genuine Porsche Part - New (to order)
                      # 13
                      MPN: 99970763740
                      O-RING
                      15,0 X 3,0 | Deleted |
                      without: | Replacement |
                      D >> - MJ 2011
                      from £1.90
                      from £1.90
                      O-RING Genuine Porsche Part - New (to order)
                      # 14
                      MPN: 9A110703171
                      OIL SUMP-UPPER PART
                      from £814.19
                      from £814.19
                      OIL SUMP-UPPER PART Genuine Porsche Part - New (to order)
                      # 15
                      MPN: 9A110731503
                      GASKET FOR OIL PAN
                      Supersession
                      Supersession
                      Genuine Porsche Part (no longer available to order)
                      # 16
                      MPN: 90006301001
                      THREADED PLUG
                      M8 X 1,0
                      from £3.07
                      from £3.07
                      THREADED PLUG Genuine Porsche Part - New (to order)
                      # 17
                      MPN: 9A110101000
                      oil separator
                      from £56.54
                      from £56.54
                      oil separator Genuine Porsche Part - New (to order)
                      # 18
                      MPN: 90038501901
                      TORX SCREW
                      M6 X 20
                      Supersession
                      Supersession
                      Genuine Porsche Part (no longer available to order)
                      # 19
                      MPN: 94860615000
                      OIL LEVEL SENDER
                      from £88.26
                      from £88.26
                      OIL LEVEL SENDER Genuine Porsche Part - New (to order)
                      # 20
                      MPN: 94860624000
                      GASKET
                      from £9.23
                      from £9.23
                      GASKET Genuine Porsche Part - New (to order)
                      # 21
                      MPN: 90038507201
                      TORX SCREW
                      M 6 X 25
                      Supersession
                      Supersession
                      Genuine Porsche Part (no longer available to order)
