porsche 997 gt3 (2011) shock absorber parts diagram

502-000 - SHOCK ABSORBER

Porsche 997 GT3 (2011) SHOCK ABSORBER Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
      #
      Part number
      Description
      Price
      # 1
      MPN: 99733305191
      SHOCK ABSORBER
      D - MJ 2007>> - MJ 2007
      # 1
      MPN: 99733305194
      SHOCK ABSORBER
      D - MJ 2008>> - MJ 2008
      from £543.88
      from £543.88
      # 1
      MPN: 99733305195
      SHOCK ABSORBER
      D - MJ 2010>>
      # 1
      MPN: 99733305199
      SHOCK ABSORBER
      also use: 2x 99634350901 |
      D - MJ 2010>>
      Supersession
      Supersession
      # -
      -
      MOUNT
      SHOCK ABSORBER
      # -
      -
      SCREW, HEX. HD.
      M 12 X 1,5 X 70
      # -
      -
      LOCK NUT
      M 12 X 1,5
      # 2
      MPN: 99733306101
      SHOCK ABSORBER MOUNTING
      from £226.16
      from £226.16
      # 2
      MPN: 99733306101
      SHOCK ABSORBER MOUNTING
      D >> - MJ 2008
      from £226.16
      from £226.16
      # 2
      MPN: 99733306180
      SHOCK ABSORBER MOUNTING
      D - MJ 2010>>
      from £226.16
      from £226.16
      # 3
      MPN: 99733353191
      COIL SPRING
      1 set (PR:-004)
      Supersession
      Supersession
      # -
      -
      1 PAIR OF SPRINGS
      red |
      D >> - 23.11.2006
      This part replaces part number 99733353191
      # 3
      MPN: 99733353193
      COIL SPRING
      1 set (PR:-004)
      Supersession
      Supersession
      # -
      -
      1 PAIR OF SPRINGS
      red | D - 24.11.2006>> - 31.07.2008
      This part replaces part number 99733353193
      # 3
      MPN: 99733353193
      COIL SPRING
      1 set |
      D >> - MJ 2008 (PR:004)
      Supersession
      Supersession
      # -
      -
      1 PAIR OF SPRINGS
      red
      This part replaces part number 99733353193
      # 3
      MPN: 99733353195
      COIL SPRING
      D - 01.08.2009>> | Discontinued part
      Supersession
      Supersession
      # -
      -
      1 PAIR OF SPRINGS
      Blue
      This part replaces part number 99733353195
      # 3
      MPN: 9973335319F
      COIL SPRING
      D - 01.08.2009>>
      Supersession
      Supersession
      # -
      -
      1 PAIR OF SPRINGS
      Blue
      This part replaces part number 9973335319F
      # 4
      MPN: 99633352992
      spring hanger
      D >> - MJ 2008
      from £95.31
      from £95.31
      # 4
      MPN: 99733350400
      SHELF
      D - MJ 2010>> (PR:475)
      from £26.42
      from £26.42
      # 5
      MPN: 99633355190
      RUBBER SUPPORT
      D >> - MJ 2008
      from £15.04
      from £15.04
      # 6
      MPN: 99733353990
      BELLOWS
      F >> 99-ZS790 741 |
      D >> - MJ 2008
      from £17.99
      from £17.99
      # 6
      MPN: 99333310701
      BELLOWS
      Only in combination with: | shock absorber | 997.333.051.95 |
      D - MJ 2010>>
      from £22.49
      from £22.49
      # 6
      MPN: 99634350901
      BELLOWS
      Only in combination with: | shock absorber | 997.333.051.99 |
      D - MJ 2010>>
      from £76.03
      from £76.03
      # 7
      MPN: 99902527102
      WASHER
      # 8
      MPN: 99733310501
      HELPER SPRING
      from £65.17
      from £65.17
      # 9
      MPN: 99908405002
      HEX. NUT
      M 12 X 1
      Supersession
      Supersession
      # 10
      MPN: 90038000801
      HEX. NUT
      M 10
      from £2.29
      from £2.29
      # 11
      MPN: 99761810590
      electronic control module
      shock absorber |
      D >> - MJ 2007
      # 11
      MPN: 99761810591
      electronic control module
      shock absorber |
      D - MJ 2008>>
      # 11
      MPN: 99761810595
      electronic control module
      shock absorber |
      D - MJ 2010>> | Discontinued part (GT-3)
      # 11
      MPN: 99761810596
      electronic control module
      shock absorber |
      D - MJ 2010>> (GT-3)
      # 11
      MPN: 99761810596
      electronic control module
      shock absorber |
      D - MJ 2010>> (PR:004)
      # -
      -
      BRACKET FOR CONTROL UNIT
      FOR
      # 12
      MPN: 99760611101
      ACCELERATION SENSOR FOR
      BODY
      Supersession
      Supersession
      # 13
      MPN: 99760621401
      BRACKET
      ACCELERATION SENSOR
      from £6.82
      from £6.82
      # 14
      MPN: 99633351102
      SPACER PLATE
      0,5 MM |
      D - MJ 2010>>
      from £18.73
      from £18.73
      # 14
      MPN: 99633351103
      SPACER PLATE
      4,0 MM |
      D - MJ 2010>>
      from £18.73
      from £18.73
      # 15
      MPN: 99733350490
      RUBBER PAD
      for | coil spring |
      D - MJ 2010>>
      from £49.99
      from £49.99
