G8620 (6S Gearbox with Transmission Code: G8620 and installed 08/99-07/04)
porsche 2000 (986 boxster) gears and shafts parts diagram

303-001 - gears and shafts

Porsche 2000 (986 Boxster) gears and shafts Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                    #
                                                    Part number
                                                    Description
                                                    Key
                                                    Price
                                                    # 1
                                                    MPN: 98630210100
                                                    INPUT SHAFT 1./2.GEAR
                                                    from £930.94
                                                    from £930.94
                                                    DRIVE SHAFT Genuine Porsche Part - New (to order)
                                                    # 2
                                                    MPN: 99630281100
                                                    NEEDLE BEARING -
                                                    from £18.35
                                                    from £18.35
                                                    NEEDLE BEARING - Genuine Porsche Part - New (to order)
                                                    # 3
                                                    MPN: 99630207500
                                                    LOOSE GEAR WHEEL 5-SPEED
                                                    from £579.59
                                                    from £579.59
                                                    LOOSE GEAR WHEEL Genuine Porsche Part - New (to order)
                                                    # 4
                                                    MPN: 99630229500
                                                    THRUST WASHER 5-SPEED
                                                    from £22.16
                                                    from £22.16
                                                    THRUST WASHER Genuine Porsche Part - New (to order)
                                                    # 5
                                                    MPN: 99630441100
                                                    SYNCHRONIZER RING
                                                    from £242.43
                                                    from £242.43
                                                    SYNCHRONIZER RING Genuine Porsche Part - New (to order)
                                                    # 6
                                                    MPN: 99630404100
                                                    SYNCHRONIZING HUB WITH 5TH/6TH GEAR LOCKING COLLAR
                                                    from £617.35
                                                    from £617.35
                                                    SYNCHRONIZING HUB WITH - OPERATING SLEEVE Genuine Porsche Part - New (to order)
                                                    # 7
                                                    MPN: 99630445100
                                                    THRUST PIECE
                                                    THRUST PIECE Genuine Porsche Part - New (to order)
                                                    # 8
                                                    MPN: 90010805800
                                                    BALL
                                                    from £2.68
                                                    from £2.68
                                                    ball - 5 MM Genuine Porsche Part - New (to order)
                                                    # 9
                                                    MPN: 99630446100
                                                    PRESSURE SPRING
                                                    from £2.18
                                                    from £2.18
                                                    PRESSURE SPRING Genuine Porsche Part - New (to order)
                                                    # 10
                                                    MPN: 99630226600
                                                    INNER RING
                                                    from £34.76
                                                    from £34.76
                                                    INNER RING Genuine Porsche Part - New (to order)
                                                    # 11
                                                    MPN: 99630281200
                                                    NEEDLE BEARING - WHITE
                                                    from £24.97
                                                    from £24.97
                                                    NEEDLE BEARING - - WHITE Genuine Porsche Part - New (to order)
                                                    # 11
                                                    MPN: 99630281201
                                                    NEEDLE BEARING - BLUE
                                                    from £17.50
                                                    from £17.50
                                                    NEEDLE BEARING - - BLUE Genuine Porsche Part - New (to order)
                                                    # 11
                                                    MPN: 99630281202
                                                    NEEDLE BEARING - GREEN
                                                    from £24.97
                                                    from £24.97
                                                    NEEDLE BEARING - - GREEN Genuine Porsche Part - New (to order)
                                                    # 12
                                                    MPN: 99630207615
                                                    LOOSE GEAR WHEEL 6TH GEAR
                                                    from £579.59
                                                    from £579.59
                                                    Loose gear wheel - D >> - MJ 2001 Genuine Porsche Part - New (to order)
                                                    # 13
                                                    MPN: 99630229600
                                                    THRUST WASHER 3RD/6TH GEAR
                                                    from £17.50
                                                    from £17.50
                                                    thrust washer - 3. + 6. Gang Genuine Porsche Part - New (to order)
                                                    # 14
                                                    MPN: 99630281300
                                                    NEEDLE ROLLER WITH INNER RING
                                                    from £86.56
                                                    from £86.56
                                                    NEEDLE ROLLER WITH INNER RING Genuine Porsche Part - New (to order)
                                                    # 15
                                                    MPN: 99630207300
                                                    Loose gear wheel 3.gear
                                                    from £493.74
                                                    from £493.74
                                                    Loose gear wheel - D >> - MJ 2001 Genuine Porsche Part - New (to order)
                                                    # 16
                                                    MPN: 99630441100
                                                    SYNCHRONIZER RING
                                                    from £242.43
                                                    from £242.43
                                                    SYNCHRONIZER RING Genuine Porsche Part - New (to order)
                                                    # 17
                                                    MPN: 99630404101
                                                    SYNCHRONIZING HUB WITH LOCKING COLLAR
                                                    from £381.24
                                                    from £381.24
                                                    SYNCHRONIZING HUB WITH - OPERATING SLEEVE Genuine Porsche Part - New (to order)
                                                    # 18
                                                    MPN: 99630226400
                                                    INNER RING
                                                    from £41.48
                                                    from £41.48
                                                    INNER RING Genuine Porsche Part - New (to order)
                                                    # 19
                                                    MPN: 99630281400
                                                    NEEDLE BEARING - WHITE
                                                    from £24.97
                                                    from £24.97
                                                    NEEDLE BEARING - - WHITE Genuine Porsche Part - New (to order)
                                                    # 19
                                                    MPN: 99630281401
                                                    NEEDLE BEARING - BLUE
                                                    from £17.50
                                                    from £17.50
                                                    NEEDLE BEARING - - BLUE Genuine Porsche Part - New (to order)
                                                    # 19
                                                    MPN: 99630281402
                                                    NEEDLE BEARING - GREEN
                                                    from £24.97
                                                    from £24.97
                                                    NEEDLE BEARING - - GREEN Genuine Porsche Part - New (to order)
                                                    # 20
                                                    MPN: 99630207400
                                                    LOOSE GEAR WHEEL 4-SPEED
                                                    from £480.60
                                                    from £480.60
                                                    LOOSE GEAR WHEEL Genuine Porsche Part - New (to order)
                                                    # 21
                                                    MPN: 99630226700
                                                    SPACER RING
                                                    from £64.56
                                                    from £64.56
                                                    SPACER RING Genuine Porsche Part - New (to order)
                                                    # 22
                                                    MPN: 99630280700
                                                    ANGULAR BALL BEARING
                                                    from £233.38
                                                    from £233.38
                                                    BALL BEARING Genuine Porsche Part - New (to order)
                                                    # 23
                                                    MPN: 99630212400
                                                    FITTED WASHER 56 X 72 X 0,50
                                                    from £1.99
                                                    from £1.99
                                                    FITT WASHER - 56 X 72 X 0,50 Genuine Porsche Part - New (to order)
                                                    # 23
                                                    MPN: 99630212401
                                                    FITTED WASHER 56 X 72 X 0,55
                                                    from £3.30
                                                    from £3.30
                                                    FITT WASHER - 56 X 72 X 0,55 Genuine Porsche Part - New (to order)
                                                    # 23
                                                    MPN: 99630212402
                                                    FITTED WASHER 56 X 72 X 0,60
                                                    from £3.30
                                                    from £3.30
                                                    FITT WASHER - 56 X 72 X 0,60 Genuine Porsche Part - New (to order)
                                                    # 23
                                                    MPN: 99630212403
                                                    FITTED WASHER 56 X 72 X 0,65
                                                    from £4.73
                                                    from £4.73
                                                    FITT WASHER - 56 X 72 X 0,65 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217300
                                                    FITTED WASHER 35 X 45 X 1,2
                                                    from £6.19
                                                    from £6.19
                                                    FITT WASHER - 35 X 45 X 1,2 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217301
                                                    FITTED WASHER 35 X 45 X 1,3
                                                    from £6.19
                                                    from £6.19
                                                    FITT WASHER - 35 X 45 X 1,3 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217302
                                                    FITTED WASHER 35 X 45 X 1,4
                                                    from £6.19
                                                    from £6.19
                                                    FITT WASHER - 35 X 45 X 1,4 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217303
                                                    FITTED WASHER 35 X 45 X 1,5
                                                    from £20.82
                                                    from £20.82
                                                    FITT WASHER - 35 X 45 X 1,5 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217304
                                                    FITTED WASHER 35 X 45 X 1,6
                                                    from £6.19
                                                    from £6.19
                                                    FITT WASHER - 35 X 45 X 1,6 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217305
                                                    FITTED WASHER 35 X 45 X 1,7
                                                    from £7.60
                                                    from £7.60
                                                    FITT WASHER - 35 X 45 X 1,7 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217306
                                                    FITTED WASHER 35 X 45 X 1,8
                                                    from £11.56
                                                    from £11.56
                                                    FITT WASHER - 35 X 45 X 1,8 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217307
                                                    FITTED WASHER 35 X 45 X 1,9
                                                    from £7.60
                                                    from £7.60
                                                    FITT WASHER - 35 X 45 X 1,9 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217308
                                                    FITTED WASHER 35 X 45 X 2,0
                                                    from £7.60
                                                    from £7.60
                                                    FITT WASHER - 35 X 45 X 2,0 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217309
                                                    FITTED WASHER 35 X 45 X 2,1
                                                    from £7.60
                                                    from £7.60
                                                    FITT WASHER - 35 X 45 X 2,1 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217310
                                                    FITTED WASHER 35 X 45 X 2,2
                                                    from £6.19
                                                    from £6.19
                                                    FITT WASHER - 35 X 45 X 2,2 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217311
                                                    FITTED WASHER 35 X 45 X 2,3
                                                    from £7.60
                                                    from £7.60
                                                    FITT WASHER - 35 X 45 X 2,3 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217312
                                                    FITTED WASHER 35 X 45 X 2,4
                                                    from £7.60
                                                    from £7.60
                                                    FITT WASHER - 35 X 45 X 2,4 Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: 99630217313
                                                    FITTED WASHER 35 X 45 X 2,5
                                                    from £7.60
                                                    from £7.60
                                                    FITT WASHER - 35 X 45 X 2,5 Genuine Porsche Part - New (to order)
                                                    # 25
                                                    MPN: 99630281000
                                                    SECURING RING 35 X 2,25
                                                    from £4.73
                                                    from £4.73
                                                    LOCK RING - 35 X 2,25 Genuine Porsche Part - New (to order)
                                                    # 25
                                                    MPN: 99630281001
                                                    SECURING RING 35 X 2,30
                                                    from £4.73
                                                    from £4.73
                                                    LOCK RING - 35 X 2,30 Genuine Porsche Part - New (to order)
                                                    # 25
                                                    MPN: 99630281002
                                                    SECURING RING 35 X 2,35
                                                    from £11.28
                                                    from £11.28
                                                    LOCK RING - 35 X 2,35 Genuine Porsche Part - New (to order)
                                                    # 25
                                                    MPN: 99630281003
                                                    SECURING RING 35 X 2,40
                                                    from £4.73
                                                    from £4.73
                                                    LOCK RING - 35 X 2,40 Genuine Porsche Part - New (to order)
                                                    # 25
                                                    MPN: 99630281004
                                                    SECURING RING 35 X 2,45
                                                    from £4.73
                                                    from £4.73
                                                    LOCK RING - 35 X 2,45 Genuine Porsche Part - New (to order)
