porsche 2011 (987 boxster) rear spoiler parts diagram

803-007 - REAR SPOILER

Porsche 2011 (987 Boxster) Rear spoiler Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                    #
                                    Part number
                                    Description
                                    Key
                                    Price
                                    # 1
                                    MPN: 98750460900G2X
                                    SPOILER SPOILER - PRIMED
                                    P without XAL
                                    from £149.74
                                    from £149.74
                                    This part replaces part number 98750460900
                                    PRIMED Genuine Porsche Part - New (to order)
                                    # 1
                                    MPN: 98750498102G2X
                                    SPOILER - PRIMED
                                    PXAL (Aerokit Boxster)
                                    from £2,284.54
                                    from £2,284.54
                                    This part replaces part number 98750498102
                                    PRIMED Genuine Porsche Part - New (to order)
                                    # 2
                                    MPN: 99950749940
                                    SPREADER RIVET 5,0 X 11,5
                                    from £0.65
                                    from £0.65
                                    rivet - 5,0 X 11,5 Genuine Porsche Part - New In stock
                                    # 3
                                    MPN: 98750461301
                                    CARRIER UPPER PART
                                    from £168.36
                                    from £168.36
                                    BRACKET Genuine Porsche Part - New (to order)
                                    # 4
                                    MPN: 98750461500
                                    COVER LEFT CARRIER
                                    from £5.66
                                    from £5.66
                                    COVER Genuine Porsche Part - New (to order)
                                    # 4
                                    MPN: 98750461600
                                    COVER RIGHT CARRIER
                                    from £5.66
                                    from £5.66
                                    COVER Genuine Porsche Part - New (to order)
                                    # 5
                                    MPN: 90037700302
                                    HEXAGON NUT CARRIER M8
                                    Supersession
                                    Supersession
                                    Genuine Porsche Part (no longer available to order)
                                    # 6
                                    MPN: 98750410901
                                    DRIVE UNIT (COMPLETE)
                                    from £1,205.09
                                    from £1,205.09
                                    Driving mechanism Genuine Porsche Part - New (to order)
                                    # 7
                                    MPN: 99921801602
                                    Bolt with washer M 6 X 16 Micro-self-locking
                                    Bolt with washer M 6 X 16 Micro-self-locking
                                    Bolt with washer - Micro-self-locking - M 6 X 16 - Discontinued part Genuine Porsche Part - New (to order)
                                    # 7
                                    MPN: 99921801601
                                    Bolt with washer M 6 X 16 Micro-self-locking
                                    from £6.69
                                    from £6.69
                                    Bolt with washer - Micro-self-locking - M 6 X 16 Genuine Porsche Part - New (to order)
                                    # 8
                                    MPN: 98650425100
                                    SECURING PLATE
                                    from £54.48
                                    from £54.48
                                    SECURING PLATE Genuine Porsche Part - New (to order)
                                    # 9
                                    MPN: 98750441300
                                    GASKET SET TOGGLE CATCH
                                    from £79.24
                                    from £79.24
                                    GASKET SET Genuine Porsche Part - New (to order)
                                    # 10
                                    MPN: 98750441500
                                    WATER DRAINAGE HOSE
                                    from £19.63
                                    from £19.63
                                    WATER DRAIN HOSE Genuine Porsche Part - New (to order)
                                    # 11
                                    MPN: 98750441100
                                    TOGGLE CATCH
                                    from £161.87
                                    from £161.87
                                    ACTUATOR Genuine Porsche Part - New (to order)
                                    # 12
                                    MPN: 99662415100
                                    electric motor
                                    from £327.76
                                    from £327.76
                                    electric motor Genuine Porsche Part - New (to order)
                                    # 13
                                    MPN: 90007436402
                                    HEXAGON BOLT M 5 X 55 MICRO-SELF-LOCKING
                                    from £2.68
                                    from £2.68
                                    SCREW, HEX. HD. - M 5 X 55 - MICRO-SELF-LOCKING Genuine Porsche Part - New (to order)
                                    # 15
                                    MPN: 90007548509
                                    HEXAGON BOLT M 6 X 16
                                    from £1.04
                                    from £1.04
                                    SCREW, HEX. HD Genuine Porsche Part - New (to order)
                                    # 16
                                    MPN: 90003500109
                                    WASHER
                                    from £0.63
                                    from £0.63
                                    WASHER Genuine Porsche Part - New (to order)
                                    # 17
                                    MPN: 99662411701
                                    THROTTLE CONTROL ELEMENT REAR COVER
                                    from £74.61
                                    from £74.61
                                    ACTUATOR Genuine Porsche Part - New (to order)
                                    # 18
                                    MPN: 99950743440
                                    BRACKET FOR CONNECTOR HOUSING
                                    from £1.04
                                    from £1.04
                                    BRACKET FOR CONNECTOR HOUSING Genuine Porsche Part - New (to order)
                                    # 19
                                    MPN: 98751211701
                                    THROTTLE CONTROL ELEMENT
                                    from £157.74
                                    from £157.74
                                    ACTUATOR Genuine Porsche Part - New (to order)
                                    # 20
                                    MPN: 98751224100G2X
                                    Rear spoiler - primed
                                    Spyder, P778 (Boxster Spyder)
                                    from £908.91
                                    from £908.91
                                    This part replaces part number 98751224100
                                    REAR SPOILER (SPYDER PR:778) primed Genuine Porsche Part - New (to order)
                                    # 21
                                    MPN: 999073268A2
                                    FILLISTER HD. BOLT M5X12
                                    Spyder, P778 (Boxster Spyder)
                                    from £0.91
                                    from £0.91
                                    fillister hd. screw - M5X12 - Mount - dashboard - with: - body shell Genuine Porsche Part - New (to order)
                                    # 22
                                    MPN: N 90663603
                                    HEX. NUT WITH WASHER M5
                                    Spyder, P778 (Boxster Spyder)
                                    from £1.15
                                    from £1.15
                                    HEX. NUT WITH WASHER Genuine Porsche Part - New In stock
                                    PREV.TORQUE TYPE M5 Genuine Lamborghini - New In stock
