PXAT (SportDesign package)
-part-diagram-802-002.webp)
802-002 - BUMPER
Porsche 2013 (981 Boxster) bumper Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 98150501150
Trim front primed
P288 (Headlamp washer) | P without 636
Supersession
Supersession
# 1
MPN: 98150501151
Trim front primed
P288 (Headlamp washer) | P636 (Park distance control in front and rear)
Supersession
Supersession
# 1
MPN: 98150501152
Trim front primed
P without 288, P without 636
from £883.22
from £883.22
# 1
MPN: 98150501153
Trim front primed
P636 (Park distance control in front and rear) | P without 288
from £883.22
from £883.22
# 2
MPN: 98150570302G2X
COVER FOR TOWING EYE - PRIMED
Supersession
Supersession
This part replaces part number 98150570302
# 3
MPN: 98150552507G2X
SPOILER FRONT - PRIMED
This part replaces part number 98150552507
# 3
MPN: 98150552507OK1
Spoiler front - Matt black
Supersession
Supersession
This part replaces part number 98150552507
# 4
MPN: 98150552700G2X
TRIM SPOILER - PRIMED
P without 089
Supersession
Supersession
This part replaces part number 98150552700
# 4
MPN: 98150552700OK1
TRIM SPOILER - MATT BLACK
P without 089
Supersession
Supersession
This part replaces part number 98150552700
# 4
MPN: 98150552701G2X
TRIM SPOILER - PRIMED
P089 (Exterior package, Black)
from £150.66
from £150.66
This part replaces part number 98150552701
# 5
MPN: 98150545701
SPOILER LIP
from £212.45
from £212.45
# 6
MPN: 98150556908OK1
RETAINING FRAME CENTER - MATT BLACK
from £150.69
from £150.69
This part replaces part number 98150556908
# 6
MPN: 98150556910G2X
RETAINING FRAME CENTER - PRIMED
P089 (Exterior package, Black)
from £144.61
from £144.61
This part replaces part number 98150556910
# 7
MPN: 98150556303OK1
RETAINING FRAME SIDE, LEFT - MATT BLACK
from £50.29
from £50.29
This part replaces part number 98150556303
# 7
MPN: 98150556305G2X
RETAINING FRAME SIDE, LEFT - PRIMED
P089 (Exterior package, Black)
from £114.42
from £114.42
This part replaces part number 98150556305
# 7
MPN: 98150556403OK1
RETAINING FRAME SIDE, RIGHT - MATT BLACK
from £50.29
from £50.29
This part replaces part number 98150556403
# 7
MPN: 98150556405G2X
RETAINING FRAME SIDE, RIGHT - PRIMED
P089 (Exterior package, Black)
from £114.42
from £114.42
This part replaces part number 98150556405
# 8
MPN: 98150579301
BRACE LEFT LEFT UPPER
from £61.01
from £61.01
# 8
MPN: 98150579401
BRACE RIGHT RIGHT UPPER
from £61.01
from £61.01
# 9
MPN: 98150565302OK1
TRIM LEFT RETAINING FRAME - MATT BLACK
P without 089
from £75.41
from £75.41
This part replaces part number 98150565302
# 9
MPN: 98150565303OK1
TRIM LEFT PARKING AID - MATT BLACK
P636 (Park distance control in front and rear) | P638 (ParkAssist, front, rear and reversing camera) | P without 089
from £75.41
from £75.41
This part replaces part number 98150565303
# 9
MPN: 98150565304G2X
TRIM LEFT PARKING AID - PRIMED
P089 (Exterior package, Black)
from £73.63
from £73.63
This part replaces part number 98150565304
# 9
MPN: 98150565402OK1
TRIM RIGHT RETAINING FRAME - MATT BLACK
P without 089
from £75.41
from £75.41
This part replaces part number 98150565402
# 9
MPN: 98150565403OK1
TRIM RIGHT PARKING AID - MATT BLACK
P636 (Park distance control in front and rear) | P638 (ParkAssist, front, rear and reversing camera) | P without 089
from £75.41
from £75.41
This part replaces part number 98150565403
# 9
MPN: 98150565405G2X
TRIM RIGHT PARKING AID - PRIMED
P636 (Park distance control in front and rear) | P638 (ParkAssist, front, rear and reversing camera) | P089 (Exterior package, Black)
from £73.63
from £73.63
This part replaces part number 98150565405
# 10
MPN: 1S0919275 G2L
SENSOR INNER PARKING AID - PRIMED
P636 (Park distance control in front and rear)
This part replaces part number 1S0919275
# 10
MPN: 1S0919275A
SENSOR OUTER PARKING AID
P636 (Park distance control in front and rear) | P638 (ParkAssist, front, rear and reversing camera)
from £115.91
from £115.91
# 11
MPN: 7PP919133
SEAL SENSOR PARKING AID
P635 (Park distance control) | P636 (Park distance control in front and rear) | P638 (ParkAssist, front, rear and reversing camera)
from £2.21
from £2.21
# 12
MPN: 98750571900
FIXING
Supersession
Supersession
# 13
MPN: 99907322709
PANEL SCREW ST4,8X19
Supersession
Supersession
# 14
MPN: 98150553500
RETAINING STRIP SIDE, LEFT
from £10.67
from £10.67
# 14
MPN: 98150553600
RETAINING STRIP SIDE, RIGHT
from £10.67
from £10.67
# 15
MPN: 99907324109
PANEL SCREW ST4,8X19-C
from £0.82
from £0.82
# 16
MPN: 99950730902
panel nut ST4,8
Supersession
Supersession
# 17
MPN: 99991924601
FILLISTER HD. BOLT 6,0X18,0-Q
from £6.90
from £6.90
# 18
MPN: 99919019130
POP RIVET A3,2X17,0 RETAINING PLATE
from £2.32
from £2.32
# 19
MPN: 99959194140
SPREADER RIVET ST4,2
from £0.91
from £0.91
# 21
MPN: 98150570700
BRACKET DISTANCE PIECE
from £9.84
from £9.84
# 22
MPN: 981701051141E0
ASSEMBLY KIT ECE LICENCE PLATE HOLDER - BLACK
P211 (Licence plate holder version 3) | P without 075
from £27.14
from £27.14
This part replaces part number 98170105114
# 22
MPN: 981701051181E0
ASSEMBLY KIT RDW LICENCE PLATE HOLDER - BLACK
P210 (Licence plate holder version 2)
from £27.14
from £27.14
This part replaces part number 98170105118
# 23
MPN: 981701051201E0
ASSEMBLY KIT CHINA LICENCE PLATE HOLDER - BLACK
P211 (Licence plate holder version 3) | P075 (Chinese version)
from £27.14
from £27.14
This part replaces part number 98170105120
# 24
MPN: 981701051161E0
ASSEMBLY KIT JAPAN LICENCE PLATE HOLDER - BLACK
P209 (Licence plate holder version 1) | P without 456
from £27.14
from £27.14
This part replaces part number 98170105116
# 24
MPN: 981701051191E0
ASSEMBLY KIT JAPAN LICENCE PLATE HOLDER ACC - BLACK
P209 (Licence plate holder version 1) | P456 (Automatic distance control (ACC))
from £27.14
from £27.14
This part replaces part number 98170105119
# 25
MPN: 95850553500
SENSOR MODULE TEMPERATURE SENSOR
from £27.94
from £27.94
# 26
MPN: 98150566102
RETAINING PLATE LEFT HEADLIGHT WASHER SYSTEM ALSO USE: 1X 000 043 300 47
P288 (Headlamp washer)
Supersession
Supersession
# 26
MPN: 98150566202
RETAINING PLATE RIGHT HEADLIGHT WASHER SYSTEM ALSO USE: 1X 000 043 300 47
P288 (Headlamp washer)
from £25.89
from £25.89
# 27
MPN: 981575141081E0
AIR GUIDE CENTER - BLACK
from £271.06
from £271.06
This part replaces part number 98157514108
# 27
MPN: 981575141131E0
AIR GUIDE CENTER ACC - BLACK
from £271.06
from £271.06
This part replaces part number 98157514113
# 28
MPN: 98157552100
GUIDE FUNNEL LEFT FANFARE
from £18.85
from £18.85
# 28
MPN: 98157552200
GUIDE FUNNEL RIGHT FANFARE
from £17.90
from £17.90
# 29
MPN: 00004330047
ADHESIVE SET ADHESIVE INCLUDED EMULSION TUBE 5 POINT BRACKET HEADLIGHT WASHER SYSTEM
Supersession
Supersession
# 29
-
USE IF REQUIRED:
# 30
MPN: 00004330048
TOOL SET FOR ADHESIVE
from £123.21
from £123.21
-part-diagram-802-010.webp "PORSCHE 2013 (981 BOXSTER) BUMPER REAR PARTS DIAGRAM")
-part-diagram-802-011.webp "PORSCHE 2013 (981 BOXSTER) BUMPER REAR PARTS DIAGRAM")
-part-diagram-802-012.webp "PORSCHE 2013 (981 BOXSTER) BUMPER REAR PARTS DIAGRAM")
-part-diagram-802-020.webp "PORSCHE 2013 (981 BOXSTER) BUMPER CARRIER FRONT PARTS DIAGRAM")
-part-diagram-802-030.webp "PORSCHE 2013 (981 BOXSTER) BUMPER CARRIER REAR PARTS DIAGRAM")
-part-diagram-803-000.webp "PORSCHE 2013 (981 BOXSTER) COVER FRONT PARTS DIAGRAM")
-part-diagram-803-005.webp "PORSCHE 2013 (981 BOXSTER) COVER REAR PARTS DIAGRAM")
-part-diagram-803-007.webp "PORSCHE 2013 (981 BOXSTER) REAR SPOILER PARTS DIAGRAM")
-part-diagram-804-000.webp "PORSCHE 2013 (981 BOXSTER) DOOR SHELL WITH INSTALLATION PARTS DOOR LOCK PARTS DIAGRAM")
-part-diagram-804-010.webp "PORSCHE 2013 (981 BOXSTER) DOOR SEAL AND TRIM PARTS DIAGRAM")
-part-diagram-804-020.webp "PORSCHE 2013 (981 BOXSTER) DOOR HANDLE, EXTERIOR PARTS DIAGRAM")
-part-diagram-804-030.webp "PORSCHE 2013 (981 BOXSTER) WINDOW REGULATOR PARTS DIAGRAM")
-part-diagram-805-000.webp "PORSCHE 2013 (981 BOXSTER) WINDSCREEN SIDE WINDOW PARTS DIAGRAM")
-part-diagram-807-000.webp "PORSCHE 2013 (981 BOXSTER) LUGGAGE BOOT TRIMS FRONT PARTS DIAGRAM")
-part-diagram-807-005.webp "PORSCHE 2013 (981 BOXSTER) LUGGAGE BOOT TRIMS REAR PARTS DIAGRAM")
-part-diagram-807-010.webp "PORSCHE 2013 (981 BOXSTER) FLOORING PARTS DIAGRAM")
-part-diagram-807-015.webp "PORSCHE 2013 (981 BOXSTER) TRIM INNER SILL PARTS DIAGRAM")
-part-diagram-807-020.webp "PORSCHE 2013 (981 BOXSTER) SIDE PANEL TRIM B-PILLAR PARTS DIAGRAM")
-part-diagram-807-025.webp "PORSCHE 2013 (981 BOXSTER) TRIMS ENGINE BAY PARTS DIAGRAM")
-part-diagram-807-030.webp "PORSCHE 2013 (981 BOXSTER) TRIMS ROLL BAR PARTS DIAGRAM")
-part-diagram-807-055.webp "PORSCHE 2013 (981 BOXSTER) A-PILLAR WINDSHIELD FRAME PARTS DIAGRAM")
-part-diagram-807-065.webp "PORSCHE 2013 (981 BOXSTER) SUN VIZORS D >>- MJ 2014 PARTS DIAGRAM")
-part-diagram-807-067.webp "PORSCHE 2013 (981 BOXSTER) SUN VIZORS D - MJ 2015>> PARTS DIAGRAM")
-part-diagram-807-068.webp "PORSCHE 2013 (981 BOXSTER) SUN VIZORS PARTS DIAGRAM")
-part-diagram-807-080.webp "PORSCHE 2013 (981 BOXSTER) BODY SOUND ABSORBER PARTS DIAGRAM")
-part-diagram-808-000.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES LEATHERETTE PARTS DIAGRAM")
-part-diagram-808-001.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES LEATHERETTE LEATHER PACKAGE PARTS DIAGRAM")
-part-diagram-808-005.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES SLUSH TECHNOLOGY PARTS DIAGRAM")
-part-diagram-808-006.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES SLUSH TECHNOLOGY LEATHER PACKAGE PARTS DIAGRAM")
-part-diagram-808-010.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES LEATHER PARTS DIAGRAM")
-part-diagram-808-015.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES LEATHER PARTS DIAGRAM")
-part-diagram-808-020.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES TRIM LEATHER PARTS DIAGRAM")
-part-diagram-808-025.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES TRIM LEATHER PARTS DIAGRAM")
-part-diagram-808-030.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES TRIM CARBON PARTS DIAGRAM")
-part-diagram-808-035.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES TRIM CARBON PARTS DIAGRAM")
-part-diagram-808-040.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES TRIM MAHAGONI PARTS DIAGRAM")
-part-diagram-808-045.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES TRIM MAHAGONI PARTS DIAGRAM")
-part-diagram-808-050.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES TRIM ALUMINIUM, BRUSHED PARTS DIAGRAM")
-part-diagram-808-055.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL ACCESSORIES TRIM ALUMINIUM, BRUSHED PARTS DIAGRAM")
-part-diagram-808-060.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL LEATHER ACCESSORIES TRIM PAINTED PARTS DIAGRAM")
-part-diagram-808-065.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL LEATHER ACCESSORIES TRIM COLOUR CODED PAINTED PARTS DIAGRAM")
-part-diagram-808-070.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL LEATHER ALCANTARA TRIM GALVANO SILVER PARTS DIAGRAM")
-part-diagram-808-075.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL LEATHER ALCANTARA TRIM ALUMINIUM, BRUSHED BLACK PARTS DIAGRAM")
-part-diagram-808-080.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL LEATHER ALCANTARA TRIM LEATHER PARTS DIAGRAM")
-part-diagram-808-085.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL LEATHER ALCANTARA TRIM CARBON PARTS DIAGRAM")
-part-diagram-808-090.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL LEATHER ALCANTARA TRIM ALUMINIUM, BRUSHED PARTS DIAGRAM")
-part-diagram-808-095.webp "PORSCHE 2013 (981 BOXSTER) DOOR PANEL LEATHER ALCANTARA TRIM COLOUR CODED PAINTED PARTS DIAGRAM")
-part-diagram-809-000.webp "PORSCHE 2013 (981 BOXSTER) INSTRUMENT PANEL TRIM UPPER PART FASTENERS PARTS DIAGRAM")
-part-diagram-809-005.webp "PORSCHE 2013 (981 BOXSTER) ACCESSORIES INSTRUMENT PANEL TRIM UPPER PART PARTS DIAGRAM")
-part-diagram-809-010.webp "PORSCHE 2013 (981 BOXSTER) GLOVE BOX AND TRIM (DRIVERS SIDE) PARTS DIAGRAM")
-part-diagram-809-015.webp "PORSCHE 2013 (981 BOXSTER) RETAINING FRAME DASHBOARD PARTS DIAGRAM")
-part-diagram-809-020.webp "PORSCHE 2013 (981 BOXSTER) CENTRE CONSOLE PARTS DIAGRAM")
-part-diagram-809-050.webp "PORSCHE 2013 (981 BOXSTER) INTERIOR MIRROR EXTERIOR MIRROR PARTS DIAGRAM")
-part-diagram-810-000.webp "PORSCHE 2013 (981 BOXSTER) INSCRIPTIONS/LETTERING TRIM PARTS DIAGRAM")
-part-diagram-811-000.webp "PORSCHE 2013 (981 BOXSTER) CONVERTIBLE TOP COVERING LINER PARTS DIAGRAM")
-part-diagram-811-005.webp "PORSCHE 2013 (981 BOXSTER) TOP FRAME FRONT ROOF FRAME CATCH PARTS DIAGRAM")
-part-diagram-811-010.webp "PORSCHE 2013 (981 BOXSTER) TOP FRAME INDIVIDUAL PARTS PARTS DIAGRAM")
-part-diagram-811-015.webp "PORSCHE 2013 (981 BOXSTER) CONVERTIBLE TOP SEAL WATER COLLECTING TRAY PARTS DIAGRAM")
-part-diagram-811-020.webp "PORSCHE 2013 (981 BOXSTER) CONVERTIBLE TOP WIRE SET PARTS DIAGRAM")
-part-diagram-811-050.webp "PORSCHE 2013 (981 BOXSTER) FLAP SIDE CONVERTIBLE TOP PARTS DIAGRAM")
-part-diagram-811-055.webp "PORSCHE 2013 (981 BOXSTER) WINDBREAK PARTS DIAGRAM")
-part-diagram-812-000.webp "PORSCHE 2013 (981 BOXSTER) THREE-POINT SAFETY BELT PARTS DIAGRAM")
-part-diagram-812-005.webp "PORSCHE 2013 (981 BOXSTER) ROLL BAR PARTS DIAGRAM")
-part-diagram-812-050.webp "PORSCHE 2013 (981 BOXSTER) AIRBAG PARTS DIAGRAM")
-part-diagram-813-000.webp "PORSCHE 2013 (981 BOXSTER) HEATER SUPPLY PIPE RETURN LINE PARTS DIAGRAM")
-part-diagram-813-005.webp "PORSCHE 2013 (981 BOXSTER) AIR GUIDE PARTS DIAGRAM")
-part-diagram-813-010.webp "PORSCHE 2013 (981 BOXSTER) AIR DISTRIBUTION HOUSING AND INDIVIDUAL PARTS PARTS DIAGRAM")
-part-diagram-813-015.webp "PORSCHE 2013 (981 BOXSTER) COMPRESSOR AIR CONDITIONING PARTS DIAGRAM")
-part-diagram-813-020.webp "PORSCHE 2013 (981 BOXSTER) REFRIGERANT CIRCUIT FRONT PARTS DIAGRAM")
-part-diagram-813-025.webp "PORSCHE 2013 (981 BOXSTER) REFRIGERANT CIRCUIT UNDERBODY AND REAR END PARTS DIAGRAM")
-part-diagram-817-000.webp "PORSCHE 2013 (981 BOXSTER) SEAT FRONT (COMPLETE) SPORTS SEAT NO LONGER AVAILABLE TRIM COVER D - MJ 2012>> PARTS DIAGRAM")
-part-diagram-817-002.webp "PORSCHE 2013 (981 BOXSTER) FOAM PART SEAT AND BACKREST COVER SPORTS SEAT D - MJ 2012>> PARTS DIAGRAM")
-part-diagram-817-004.webp "PORSCHE 2013 (981 BOXSTER) BACKREST SHELL SPORTS SEAT ACCESSORIES D - MJ 2012>> PARTS DIAGRAM")
-part-diagram-817-006.webp "PORSCHE 2013 (981 BOXSTER) BACKREST FRAME LUMBAR SUPPORT SPORTS SEAT ACCESSORIES D - MJ 2012>> PARTS DIAGRAM")
-part-diagram-817-008.webp "PORSCHE 2013 (981 BOXSTER) SEAT FRAME SPORTS SEAT ACCESSORIES BRACKET FIRE EXTINGUISHERS PARTS DIAGRAM")
-part-diagram-817-009.webp "PORSCHE 2013 (981 BOXSTER) SEAT PADDING FRAME SPORTS SEAT PARTS DIAGRAM")
-part-diagram-817-010.webp "PORSCHE 2013 (981 BOXSTER) WIRING LOOMS SWITCH CONTROL UNIT ELECTRIC MOTOR SPORTS SEAT D - MJ 2012>> PARTS DIAGRAM")
-part-diagram-817-012.webp "PORSCHE 2013 (981 BOXSTER) HEATER ELEMENT BACKREST BOLSTER HEATER ELEM. SEAT CUSHION PARTS DIAGRAM")
-part-diagram-817-015.webp "PORSCHE 2013 (981 BOXSTER) SPORTS SEAT PLUS (COMPLETE) NO LONGER AVAILABLE TRIM COVER TRIM FOR SEAT FRONT PARTS DIAGRAM")
-part-diagram-817-017.webp "PORSCHE 2013 (981 BOXSTER) FOAM PART SEAT AND BACKREST COVER SPORTS SEAT PLUS D - MJ 2012>> PARTS DIAGRAM")
-part-diagram-817-019.webp "PORSCHE 2013 (981 BOXSTER) BACKREST SHELL SPORTS SEAT PLUS ACCESSORIES PARTS DIAGRAM")
-part-diagram-817-021.webp "PORSCHE 2013 (981 BOXSTER) BACKREST FRAME SPORTS SEAT PLUS ACCESSORIES D - MJ 2012>> PARTS DIAGRAM")
-part-diagram-817-022.webp "PORSCHE 2013 (981 BOXSTER) LUMBAR SUPPORT ACCESSORIES PARTS DIAGRAM")
-part-diagram-817-023.webp "PORSCHE 2013 (981 BOXSTER) SEAT FRAME SPORTS SEAT PLUS ACCESSORIES REPAIR SET SEAT OCCUPIED RECOGNITION TRIM FOR SWITCH PARTS DIAGRAM")
817-023 Seat frame Sports seat Plus Accessories repair set seat occupied recognition Trim for switch -part-diagram-817-024.webp "PORSCHE 2013 (981 BOXSTER) SEAT PADDING FRAME SPORTS SEAT PLUS REPAIR SET SEAT OCCUPIED RECOGNITION D - MJ 2012>> PARTS DIAGRAM")
-part-diagram-817-025.webp "PORSCHE 2013 (981 BOXSTER) WIRING LOOMS SWITCH CONTROL UNIT ELECTRIC MOTOR SPORTS SEAT D - MJ 2012>> PARTS DIAGRAM")
-part-diagram-817-060.webp "PORSCHE 2013 (981 BOXSTER) BUCKET SEAT FOR VEHICLE WITH FOLD-DOWN SEAT BACKREST (COMPLETE) NO LONGER AVAILABLE PARTS DIAGRAM")
-part-diagram-817-062.webp "PORSCHE 2013 (981 BOXSTER) FOAM PART SEAT AND BACKREST COVER SEAT AND BACKREST SURFACE BUCKET SEAT FOLDING PARTS DIAGRAM")
-part-diagram-817-064.webp "PORSCHE 2013 (981 BOXSTER) BUCKET SEAT FOLDING SEAT FRAME ACCESSORIES PARTS DIAGRAM")
-part-diagram-817-066.webp "PORSCHE 2013 (981 BOXSTER) BACKREST SHELL FOLDING BUCKET SEAT ACCESSORIES PARTS DIAGRAM")
-part-diagram-898-000.webp "PORSCHE 2013 (981 BOXSTER) REPAIR SET 1 SET OF LOCK CYLINDERS WITH HANDHELD TRANS. & EMERG. KEY PARTS DIAGRAM")
-part-diagram-901-000.webp "PORSCHE 2013 (981 BOXSTER) IGNITION SYSTEM PARTS DIAGRAM")
-part-diagram-901-003.webp "PORSCHE 2013 (981 BOXSTER) CONTROL UNITS PARTS DIAGRAM")
-part-diagram-901-004.webp "PORSCHE 2013 (981 BOXSTER) CONTROL UNITS CONTROL UNIT (BCM) FOR CONV. SYSTEM & OB POWER SUPPLY FRONT END REAR END HANDHELD TRANSMITTER IGNITION/STARTER SWITCH AERIAL FOR VEHICLES WITH RADIO CONTROLLED GARAGE DOOR OPENER SENSOR FOR INTERIOR MONITORING PARTS DIAGRAM")
-part-diagram-901-005.webp "PORSCHE 2013 (981 BOXSTER) CONTROL UNIT CRASH SENSOR FOR AIRBAG AIRBAG PARTS DIAGRAM")
-part-diagram-902-000.webp "PORSCHE 2013 (981 BOXSTER) CENTRAL ELECTRICS DASHBOARD PARTS DIAGRAM")
-part-diagram-902-001.webp "PORSCHE 2013 (981 BOXSTER) CENTRAL ELECTRICS REAR LUGGAGE COMPARTMENT PARTS DIAGRAM")
-part-diagram-902-005.webp "PORSCHE 2013 (981 BOXSTER) STARTER ALTERNATOR EARTH LINE PARTS DIAGRAM")
-part-diagram-902-006.webp "PORSCHE 2013 (981 BOXSTER) BATTERY POTENTIAL DISTRIBUTOR PARTS DIAGRAM")
-part-diagram-902-010.webp "PORSCHE 2013 (981 BOXSTER) WIRING LOOMS PASSENGER COMPARTMENT AND PART SECTION WIRING HARNESS PARTS DIAGRAM")
-part-diagram-902-011.webp "PORSCHE 2013 (981 BOXSTER) WIRING LOOMS FRONT DASHBOARD TRIM COVER STEERING FRONT AXLE PARTS DIAGRAM")
-part-diagram-902-015.webp "PORSCHE 2013 (981 BOXSTER) WIRING LOOMS DOORS CENTRE CONSOLE GLOVE BOX CONTROL UNITS DOORS STOPWATCH PARTS DIAGRAM")
-part-diagram-902-020.webp "PORSCHE 2013 (981 BOXSTER) WIRING LOOMS REAR TRIM ENGINE GEARBOX REAR AXLE PARTS DIAGRAM")
-part-diagram-902-050.webp "PORSCHE 2013 (981 BOXSTER) FIBRE OPTIC WAVE CONDUCTOR PARTS DIAGRAM")
-part-diagram-902-060.webp "PORSCHE 2013 (981 BOXSTER) WIRING LOOMS AIRBAG SEAT BELTS PARTS DIAGRAM")
-part-diagram-903-000.webp "PORSCHE 2013 (981 BOXSTER) FANFARE SIGNAL HORN ALARM SYSTEM PARTS DIAGRAM")
-part-diagram-903-004.webp "PORSCHE 2013 (981 BOXSTER) INTERIOR LIGHT DOOR WARNING LIGHT FOOTWELL LIGHT LUGGAGE COMPARTMENT LAMP GLOVE BOX LIGHT LIGHT EXTERIOR MIRROR PARTS DIAGRAM")
-part-diagram-903-005.webp "PORSCHE 2013 (981 BOXSTER) SWITCH CONTROL PANEL AIR CONDITIONING PARTS DIAGRAM")
-part-diagram-903-006.webp "PORSCHE 2013 (981 BOXSTER) CONSOLE ROOF PARTS DIAGRAM")
-part-diagram-903-010.webp "PORSCHE 2013 (981 BOXSTER) STEERING COLUMN SWITCH PARTS DIAGRAM")
-part-diagram-904-000.webp "PORSCHE 2013 (981 BOXSTER) WINDSCREEN WIPER SYSTEM, COMPL RAIN SENSOR PARTS DIAGRAM")
-part-diagram-904-010.webp "PORSCHE 2013 (981 BOXSTER) WINDSCREEN WASHER SYSTEM PARTS DIAGRAM")
-part-diagram-904-020.webp "PORSCHE 2013 (981 BOXSTER) HEADLIGHT WASHER SYSTEM PARTS DIAGRAM")
-part-diagram-905-000.webp "PORSCHE 2013 (981 BOXSTER) HEADLIGHTS ADDITIONAL HEADLIGHT TURN SIGNAL INDICATOR SIDE MARKER LIGHT TURN SIGNAL REPEATER PARTS DIAGRAM")
905-000 Headlights Additional headlight Turn signal indicator side marker light Turn signal repeater -part-diagram-905-001.webp "PORSCHE 2013 (981 BOXSTER) HEADLIGHTS ADDITIONAL HEADLIGHT TURN SIGNAL INDICATOR SIDE MARKER LIGHT TURN SIGNAL REPEATER PARTS DIAGRAM")
-part-diagram-905-002.webp "PORSCHE 2013 (981 BOXSTER) HEADLIGHTS WITH: (CORNERING LIGHT) DYNAMIC ADDITIONAL HEADLIGHT TURN SIGNAL INDICATOR SIDE MARKER LIGHT TURN SIGNAL REPEATER PARTS DIAGRAM")
-part-diagram-905-005.webp "PORSCHE 2013 (981 BOXSTER) REAR LIGHT LICENCE PLATE LIGHT ADDITIONAL BRAKE LIGHT REAR FOG LIGHT PARTS DIAGRAM")
-part-diagram-906-000.webp "PORSCHE 2013 (981 BOXSTER) COMBI-INSTRUMENT STOPWATCH PARTS DIAGRAM")
-part-diagram-906-001.webp "PORSCHE 2013 (981 BOXSTER) COMBI-INSTRUMENT DIAL COLOURED PARTS DIAGRAM")
-part-diagram-911-000.webp "PORSCHE 2013 (981 BOXSTER) CONTROL PANEL NAVIGATION SYSTEM RADIO UNIT RECEIVER UNIT TV MICROPHONE PARTS DIAGRAM")
-part-diagram-911-001.webp "PORSCHE 2013 (981 BOXSTER) ELECTRIC PARTS FOR NAVIGATION SYSTEM PREPARATION JAPAN PARTS DIAGRAM")
-part-diagram-911-002.webp "PORSCHE 2013 (981 BOXSTER) AERIAL AMPLIFIER AERIAL CONNECTING LINE PARTS DIAGRAM")
-part-diagram-911-005.webp "PORSCHE 2013 (981 BOXSTER) LOUDSPEAKER PARTS DIAGRAM")
-part-diagram-911-010.webp "PORSCHE 2013 (981 BOXSTER) AMPLIFIERS TELEPHONE PARTS DIAGRAM")
-part-diagram-001-000.webp "PORSCHE 2013 (981 BOXSTER) TOOL JACK PARTS DIAGRAM")
-part-diagram-001-005.webp "PORSCHE 2013 (981 BOXSTER) SIGNS/NOTICES PARTS DIAGRAM")
-part-diagram-003-010.webp "PORSCHE 2013 (981 BOXSTER) SIGNS/NOTICES PARTS DIAGRAM")
-part-diagram-003-020.webp "PORSCHE 2013 (981 BOXSTER) SIGNS/NOTICES PARTS DIAGRAM")
-part-diagram-004-000.webp "PORSCHE 2013 (981 BOXSTER) PAINT TOUCH-UP APPLICATOR PAINTS PARTS DIAGRAM")
-part-diagram-101-000.webp "PORSCHE 2013 (981 BOXSTER) REPLACEMENT ENGINE BUT WITHOUT: CLUTCH PLATE - PDK - GEARBOX BUT WITHOUT: FLYWHEEL MANUAL GEARBOX INCLUDED COMPRESSOR AIR CONDITIONING PARTS DIAGRAM")
-part-diagram-101-005.webp "PORSCHE 2013 (981 BOXSTER) CRANKCASE HOUSING PARTS DIAGRAM")
-part-diagram-101-010.webp "PORSCHE 2013 (981 BOXSTER) BELT TENSIONER DAMPER V-BELT PARTS DIAGRAM")
-part-diagram-102-000.webp "PORSCHE 2013 (981 BOXSTER) CRANKSHAFT PARTS DIAGRAM")
-part-diagram-102-005.webp "PORSCHE 2013 (981 BOXSTER) PISTON PARTS DIAGRAM")
-part-diagram-103-000.webp "PORSCHE 2013 (981 BOXSTER) CYLINDER HEAD WITH: INLET/OUTLET VALVE CYLINDER HEAD GASKET VALVE COVER PARTS DIAGRAM")
-part-diagram-103-005.webp "PORSCHE 2013 (981 BOXSTER) CYLINDER HEAD ACCESSORIES INLET/OUTLET VALVE PARTS DIAGRAM")
-part-diagram-103-010.webp "PORSCHE 2013 (981 BOXSTER) CAMSHAFT HYDRAULIC TAPPET CAMSHAFT ADJUSTER UNIT PARTS DIAGRAM")
-part-diagram-103-015.webp "PORSCHE 2013 (981 BOXSTER) ENGINE CONTROL TIMING CHAIN W/ TENSION RAIL PARTS DIAGRAM")
-part-diagram-104-000.webp "PORSCHE 2013 (981 BOXSTER) OIL PUMP PARTS DIAGRAM")
-part-diagram-104-002.webp "PORSCHE 2013 (981 BOXSTER) OIL SUMP PARTS DIAGRAM")
-part-diagram-104-005.webp "PORSCHE 2013 (981 BOXSTER) ENGINE (OIL PRESS./LUBRICA.) PARTS DIAGRAM")
-part-diagram-104-010.webp "PORSCHE 2013 (981 BOXSTER) CRANKCASE HOUSING OIL SEPARATOR TANK VENTILATION VACUUM PUMP PARTS DIAGRAM")
-part-diagram-105-000.webp "PORSCHE 2013 (981 BOXSTER) COOLANT PUMP THERMOSTAT HOUSING PARTS DIAGRAM")
-part-diagram-105-003.webp "PORSCHE 2013 (981 BOXSTER) ASSEMBLY CARRIER WATER PIPE PARTS DIAGRAM")
-part-diagram-105-005.webp "PORSCHE 2013 (981 BOXSTER) JUNCTION WATER PIPE DISTRIBUTOR FOR COOLANT COOLANT COOLING SYSTEM PARTS DIAGRAM")
-part-diagram-105-010.webp "PORSCHE 2013 (981 BOXSTER) COOLANT COOLING SYSTEM 1 PARTS DIAGRAM")
-part-diagram-105-015.webp "PORSCHE 2013 (981 BOXSTER) COOLANT COOLING SYSTEM 2 COOLER FOR COOLANT FAN PARTS DIAGRAM")
-part-diagram-105-017.webp "PORSCHE 2013 (981 BOXSTER) COOLER FOR COOLANT CENTER PARTS DIAGRAM")
-part-diagram-105-020.webp "PORSCHE 2013 (981 BOXSTER) COOLANT COOLING SYSTEM RESERVOIR PARTS DIAGRAM")
-part-diagram-106-000.webp "PORSCHE 2013 (981 BOXSTER) AIR FILTER PARTS DIAGRAM")
-part-diagram-107-005.webp "PORSCHE 2013 (981 BOXSTER) FUEL COLLECTION PIPE HIGH PRESSURE PUMP PARTS DIAGRAM")
-part-diagram-107-010.webp "PORSCHE 2013 (981 BOXSTER) INTAKE AIR DISTRIBUTOR THROTTLE VALVE ADAPTER PARTS DIAGRAM")
-part-diagram-107-015.webp "PORSCHE 2013 (981 BOXSTER) VACUUM SYSTEM ENGINE PARTS DIAGRAM")
-part-diagram-109-000.webp "PORSCHE 2013 (981 BOXSTER) ENGINE LIFTING TACKLE PARTS DIAGRAM")
-part-diagram-201-000.webp "PORSCHE 2013 (981 BOXSTER) FUEL TANK PARTS DIAGRAM")
-part-diagram-201-005.webp "PORSCHE 2013 (981 BOXSTER) FUEL SYSTEM FRONT PARTS DIAGRAM")
-part-diagram-201-020.webp "PORSCHE 2013 (981 BOXSTER) ACTIVATED CHARCOAL CONTAINER PARTS DIAGRAM")
-part-diagram-202-000.webp "PORSCHE 2013 (981 BOXSTER) EXHAUST SYSTEM PARTS DIAGRAM")
-part-diagram-202-005.webp "PORSCHE 2013 (981 BOXSTER) EXHAUST SYSTEM SPORT PARTS DIAGRAM")
-part-diagram-202-015.webp "PORSCHE 2013 (981 BOXSTER) EXHAUST SYSTEM SPORT PARTS DIAGRAM")
-part-diagram-301-000.webp "PORSCHE 2013 (981 BOXSTER) COUPLING PARTS DIAGRAM")
-part-diagram-301-005.webp "PORSCHE 2013 (981 BOXSTER) CLUTCH SLAVE CYLINDER PARTS DIAGRAM")
-part-diagram-302-000.webp "PORSCHE 2013 (981 BOXSTER) MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-302-005.webp "PORSCHE 2013 (981 BOXSTER) MANUAL GEARBOX INDIVIDUAL PARTS LIMITED SLIP DIFFERENTIAL DRIVE FLANGE PARTS DIAGRAM")
-part-diagram-302-010.webp "PORSCHE 2013 (981 BOXSTER) MANUAL GEARBOX INDIVIDUAL PARTS PARTS DIAGRAM")
-part-diagram-302-015.webp "PORSCHE 2013 (981 BOXSTER) MANUAL GEARBOX SELECTOR MECHANISM SELECTOR SHAFT PARTS DIAGRAM")
-part-diagram-302-020.webp "PORSCHE 2013 (981 BOXSTER) MANUAL GEARBOX HEAT EXCHANGER OIL PIPE WATER PIPE PARTS DIAGRAM")
-part-diagram-306-000.webp "PORSCHE 2013 (981 BOXSTER) GEARBOX MOUNTING FASTENERS ENGINE PARTS DIAGRAM")
-part-diagram-320-000.webp "PORSCHE 2013 (981 BOXSTER) - PDK - GEARBOX PARTS DIAGRAM")
-part-diagram-320-005.webp "PORSCHE 2013 (981 BOXSTER) - PDK - GEARBOX INDIVIDUAL PARTS PARTS DIAGRAM")
-part-diagram-320-010.webp "PORSCHE 2013 (981 BOXSTER) - PDK - GEARBOX CLUTCH FOR DUAL CLUTCH GEARBOX PARTS DIAGRAM")
-part-diagram-360-000.webp "PORSCHE 2013 (981 BOXSTER) - PDK - GEARBOX HEAT EXCHANGER OIL PIPE WATER PIPE PARTS DIAGRAM")
-part-diagram-401-000.webp "PORSCHE 2013 (981 BOXSTER) CROSS MEMBER WISHBONE PARTS DIAGRAM")
-part-diagram-401-005.webp "PORSCHE 2013 (981 BOXSTER) WHEEL CARRIER WHEEL HUB PARTS DIAGRAM")
-part-diagram-402-000.webp "PORSCHE 2013 (981 BOXSTER) VIBRATION DAMPER PARTS DIAGRAM")
-part-diagram-402-005.webp "PORSCHE 2013 (981 BOXSTER) ANTI-ROLL BAR PARTS DIAGRAM")
-part-diagram-403-000.webp "PORSCHE 2013 (981 BOXSTER) STEERING GEAR TRACK ROD TIE ROD END BELLOWS PARTS DIAGRAM")
-part-diagram-403-004.webp "PORSCHE 2013 (981 BOXSTER) STEERING WHEEL PARTS DIAGRAM")
-part-diagram-403-005.webp "PORSCHE 2013 (981 BOXSTER) STEERING WHEEL PARTS DIAGRAM")
-part-diagram-403-006.webp "PORSCHE 2013 (981 BOXSTER) STEERING COLUMN INTERMEDIATE STEERING SHAFT PARTS DIAGRAM")
-part-diagram-501-000.webp "PORSCHE 2013 (981 BOXSTER) REAR AXLE WHEEL CARRIER WHEEL HUB PARTS DIAGRAM")
-part-diagram-501-001.webp "PORSCHE 2013 (981 BOXSTER) REAR AXLE SIDE PART CARRIER GUIDE PARTS DIAGRAM")
-part-diagram-501-003.webp "PORSCHE 2013 (981 BOXSTER) ANTI-ROLL BAR PARTS DIAGRAM")
-part-diagram-501-005.webp "PORSCHE 2013 (981 BOXSTER) DRIVE SHAFT WHEEL HUB PARTS DIAGRAM")
-part-diagram-502-000.webp "PORSCHE 2013 (981 BOXSTER) SHOCK ABSORBERS COIL SPRING PARTS DIAGRAM")
-part-diagram-601-000.webp "PORSCHE 2013 (981 BOXSTER) WHEELS/TYRES PARTS DIAGRAM")
-part-diagram-601-005.webp "PORSCHE 2013 (981 BOXSTER) TYRE PRESSURE CONTROL SYSTEM PARTS DIAGRAM")
-part-diagram-602-000.webp "PORSCHE 2013 (981 BOXSTER) DISC BRAKE FRONT AXLE PARTS DIAGRAM")
-part-diagram-603-000.webp "PORSCHE 2013 (981 BOXSTER) DISC BRAKE REAR AXLE PARTS DIAGRAM")
-part-diagram-603-005.webp "PORSCHE 2013 (981 BOXSTER) PARKING BRAKE PARTS DIAGRAM")
-part-diagram-604-000.webp "PORSCHE 2013 (981 BOXSTER) BRAKE MASTER CYLINDER BRAKE SERVO PARTS DIAGRAM")
-part-diagram-604-005.webp "PORSCHE 2013 (981 BOXSTER) BRAKE LINE FRONT FRONT END PARTS DIAGRAM")
-part-diagram-604-010.webp "PORSCHE 2013 (981 BOXSTER) BRAKE LINE CENTER UNDERBODY REAR PARTS DIAGRAM")
-part-diagram-604-015.webp "PORSCHE 2013 (981 BOXSTER) VACUUM LINE FRONT BRAKE SERVO CENTER REAR PARTS DIAGRAM")
-part-diagram-605-000.webp "PORSCHE 2013 (981 BOXSTER) HYDRAULIC UNIT ANTI-LOCKING BRAKE SYST. -ABS- PARTS DIAGRAM")
-part-diagram-701-000.webp "PORSCHE 2013 (981 BOXSTER) SELECTOR MECHANISM MANUAL GEARBOX PARTS DIAGRAM")
-part-diagram-701-001.webp "PORSCHE 2013 (981 BOXSTER) SELECTOR LEVER - PDK - PARTS DIAGRAM")
-part-diagram-702-000.webp "PORSCHE 2013 (981 BOXSTER) BRAKE AND CLUTCH PEDALS CLUSTER PARTS DIAGRAM")
-part-diagram-702-008.webp "PORSCHE 2013 (981 BOXSTER) HYDRAULIC COUPLING ACTUATION CLUTCH MASTER CYLINDER CLUTCH SLAVE CYLINDER PIPE/HOSE LINE PARTS DIAGRAM")
-part-diagram-702-010.webp "PORSCHE 2013 (981 BOXSTER) ACCELERATOR PEDAL PARTS DIAGRAM")
-part-diagram-801-000.webp "PORSCHE 2013 (981 BOXSTER) CAR BODY PARTS DIAGRAM")
-part-diagram-801-002.webp "PORSCHE 2013 (981 BOXSTER) BUNGS PARTS DIAGRAM")
-part-diagram-801-005.webp "PORSCHE 2013 (981 BOXSTER) FRONT END (COMPLETE) PARTS DIAGRAM")
-part-diagram-801-010.webp "PORSCHE 2013 (981 BOXSTER) FRONT END INDIVIDUAL PARTS PARTS DIAGRAM")
-part-diagram-801-015.webp "PORSCHE 2013 (981 BOXSTER) DOME STRUT PARTS DIAGRAM")
-part-diagram-801-020.webp "PORSCHE 2013 (981 BOXSTER) FLOOR PLATES CENTER PARTS DIAGRAM")
-part-diagram-801-035.webp "PORSCHE 2013 (981 BOXSTER) REAR END PARTS DIAGRAM")
-part-diagram-801-040.webp "PORSCHE 2013 (981 BOXSTER) WING PARTS DIAGRAM")
-part-diagram-801-045.webp "PORSCHE 2013 (981 BOXSTER) SCUTTLE PARTS DIAGRAM")
-part-diagram-801-050.webp "PORSCHE 2013 (981 BOXSTER) SIDE PART PARTS DIAGRAM")
-part-diagram-801-070.webp "PORSCHE 2013 (981 BOXSTER) TRIM UNDERBODY PARTS DIAGRAM")
-part-diagram-801-075.webp "PORSCHE 2013 (981 BOXSTER) TRIMS WHEEL HOUSING PARTS DIAGRAM")
-part-diagram-801-090.webp "PORSCHE 2013 (981 BOXSTER) SIDE MEMBER TRIM AND AIR GUIDE FAN ENGINE BAY PARTS DIAGRAM")
-part-diagram-802-000.webp "PORSCHE 2013 (981 BOXSTER) BUMPER FRONT PARTS DIAGRAM")
-part-diagram-802-001.webp "PORSCHE 2013 (981 BOXSTER) BUMPER PARTS DIAGRAM")
