P288 (Headlamp washer)
-part-diagram-904-020.webp)
904-020 - HEADLIGHT WASHER SYSTEM
Porsche 2013 (981 Boxster) headlight washer system Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 95862450200
PUMP FOR HEADLIGHT- WASHER SYSTEM
P288 (Headlamp washer)
from £66.42
from £66.42
# 2
MPN: 431955465A
SEAL
P288 (Headlamp washer)
from £2.30
from £2.30
# 2
MPN: 00004320479
HOSE 8X3
from £11.55
from £11.55
# 3
-
SHORTEN TO: 905 MM
# 4
MPN: 8E0955665
ELBOW FITTING
P288 (Headlamp washer)
from £8.17
from £8.17
# 5
MPN: 99762820500
COUPLING
P288 (Headlamp washer)
from £11.59
from £11.59
# 6
MPN: 99162820800
HOSE CONNECTOR
P288 (Headlamp washer)
# 6
MPN: 00004320479
HOSE 8X3
P288 (Headlamp washer)
from £11.55
from £11.55
# 7
-
SHORTEN TO: 600 MM
# 8
-
SHORTEN TO: 1340 MM
# 9
-
SHORTEN TO: 75 MM
# 10
MPN: 113955975B
T-PIECE
P288 (Headlamp washer)
from £6.89
from £6.89
# 11
MPN: 99762816301
JET CHROMED INCLUDED NOZZLE HEAD
P288 (Headlamp washer) | P without 011
from £61.36
from £61.36
# 11
MPN: 99162816700
JET MATT BLACK INCLUDED NOZZLE HEAD
P288 (Headlamp washer) | P011 (Special model GTS (981/991))
Supersession
Supersession
# 12
MPN: 99762826300
NOZZLE HEAD CHROMED
P288 (Headlamp washer) | P without 011
from £15.52
from £15.52
# 12
MPN: 99162826500
NOZZLE HEAD MATT BLACK
P288 (Headlamp washer) | P011 (Special model GTS (981/991))
# 13
MPN: 99950716401
CABLE FASTENER
P288 (Headlamp washer)
from £2.70
from £2.70
# 13
MPN: 99762898102
CAP PRIMED TO BE USED FOR ITEM: 11,12
P288 (Headlamp washer) | PXUB (Cover on headlight cleaning system, painted)
from £23.98
from £23.98
