porsche 2016 (981 boxster spyder) crankshaft parts diagram

102-000 - crankshaft

Porsche 2016 (981 Boxster Spyder) Crankshaft Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                            #
                                            Part number
                                            Description
                                            Key
                                            Price
                                            # 1
                                            MPN: 9A110207720
                                            crankshaft
                                            from £3,591.66
                                            from £3,591.66
                                            crankshaft Genuine Porsche Part - New (to order)
                                            # 2
                                            MPN: 90009503100
                                            SPRING PIN 6X16
                                            from £0.56
                                            from £0.56
                                            SPRING PIN - 6 X 16 Genuine Porsche Part - New (to order)
                                            # 3
                                            MPN: 90030201600
                                            CYLINDER PIN 6,0X16
                                            from £1.20
                                            from £1.20
                                            DOWEL PIN Genuine Porsche Part - New (to order)
                                            # 4
                                            MPN: 9A110122202
                                            SHAFT OIL SEAL 52X72X9
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 5
                                            MPN: 99710121201
                                            SHAFT OIL SEAL 85X105X11
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 6
                                            MPN: 9A110391402
                                            CONROD COMPRISING: CONROD 6 PCS
                                            from £1,344.29
                                            from £1,344.29
                                            CONNECTING ROD Genuine Porsche Part - New (to order)
                                            # 7
                                            -
                                            BUSH - CONNECTING ROD D = 22 * SINGLE PARTS NO AVAILABLE * ALTERNATIVELY, YOU CAN USE: 9A1 103 914 02
                                            # 8
                                            MPN: 9A110311502
                                            bolt - connecting rod M10X1,25X51
                                            BOLT - CONNECTING ROD Genuine Porsche Part - New (to order)
                                            # 9
                                            MPN: 9A110305303
                                            connecting rod bearing shell Identification: >>>>red
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 9
                                            MPN: 9A110305304
                                            connecting rod bearing shell Identification: >>>>yellow
                                            from £9.40
                                            from £9.40
                                            CONNECTING ROD BEARING SHELL Genuine Porsche Part - New (to order)
                                            # 9
                                            MPN: 9A110305305
                                            connecting rod bearing shell Identification: >>>>blue
                                            from £10.53
                                            from £10.53
                                            This part replaces part number 9A110305302
                                            CONNECTING ROD BEARING SHELL Genuine Porsche Part - New (to order)
                                            # 10
                                            MPN: 9A110106400
                                            crankshaft bearing Identification: >>>>red
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 10
                                            MPN: 9A110106401
                                            crankshaft bearing Identification: >>>>yellow
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 10
                                            MPN: 9A110106402
                                            crankshaft bearing Identification: >>>>blue
                                            from £13.21
                                            from £13.21
                                            CRANKSHAFT BEARING Genuine Porsche Part - New (to order)
                                            # 11
                                            MPN: 9A110106300
                                            crankshaft bearing with: Partial-groove Identification: >>>>red
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 11
                                            MPN: 9A110106301
                                            crankshaft bearing with: Partial-groove Identification: >>>>yellow
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 11
                                            MPN: 9A110106302
                                            crankshaft bearing with: Partial-groove Identification: >>>>blue
                                            CRANKSHAFT BEARING Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: 9A110105203
                                            crankshaft bearing Identification: >>>>red
                                            from £12.98
                                            from £12.98
                                            CRANKSHAFT BEARING Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: 9A110105204
                                            crankshaft bearing Identification: >>>>yellow
                                            from £12.82
                                            from £12.82
                                            CRANKSHAFT BEARING Genuine Porsche Part - New (to order)
                                            # 12
                                            MPN: 9A110105205
                                            crankshaft bearing Identification: >>>>blue
                                            CRANKSHAFT BEARING Genuine Porsche Part - New (to order)
                                            # 13
                                            MPN: 99610113200
                                            THRUST WASHER D = 63
                                            Supersession
                                            Supersession
                                            Genuine Porsche Part (no longer available to order)
                                            # 14
                                            MPN: 98111401280
                                            DUAL-MASS FLYWHEEL
                                            from £840.98
                                            from £840.98
                                            DUAL-MASS FLYWHEEL Genuine Porsche Part - New (to order)
                                            # 15
                                            MPN: N 90665101
                                            SOCKET HEAD BOLT WITH INNER M10X1X29 MULTIPOINT HEAD
                                            from £2.21
                                            from £2.21
                                            Genuine Porsche Part (no longer available to order)
                                            SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD Genuine Bentley Part - New (to order)
                                            TRIPLE SQUARE BOLT Genuine Lamborghini - New (to order)
                                            # 16
                                            MPN: 9A110214603
                                            PULLEY WITH: VIBRATION DAMPER
                                            from £212.41
                                            from £212.41
                                            PULLEY Genuine Porsche Part - New (to order)
                                            # 17
                                            MPN: 90038512702
                                            HEXAGON HEAD BOLT BM8X1X25
                                            from £0.91
                                            from £0.91
                                            HEXAGON HEAD BOLT Genuine Porsche Part - New In stock
                                            # 18
                                            -
                                            V-BELT SEE ILLUSTRATION: 101-010
                                            # 19
                                            MPN: 99160611202
                                            SPEED SENSOR ALSO USE: 1X 991 606 912 00 WHEN USING: 981 300 020 22 981 300 020 BX 981 300 020 23 981 300 020 CX
                                            from £130.00
                                            from £130.00
                                            SPEED SENSOR Genuine Porsche Part - New (to order)
                                            # 19
                                            MPN: 99160611202
                                            SPEED SENSOR WHEN USING: 981 300 020 24 981 300 020 DX
                                            from £130.00
                                            from £130.00
                                            SPEED SENSOR Genuine Porsche Part - New (to order)
                                            # 20
                                            MPN: N 10546403
                                            Hexagon socket head M6X16 bolt
                                            from £1.03
                                            from £1.03
                                            hexagonal socket head - screw - M 6 X 18 Genuine Porsche Part - New In stock
                                            HEXAGON SOCKET HEAD BOLT Genuine Bentley Part - New (to order)
                                            HEXALOBULAR SOCKETM6X16 Genuine Lamborghini - New (to order)
                                            # 21
                                            MPN: 99160691200
                                            SHIM SPEED SENSOR
                                            from £1.87
                                            from £1.87
                                            SPACER WASHER Genuine Porsche Part - New (to order)
