porsche 2016 (981 boxster spyder) vibration damper parts diagram

402-000 - VIBRATION DAMPER

Porsche 2016 (981 Boxster Spyder) vibration damper Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                    #
                    Part number
                    Description
                    Key
                    Price
                    # 1
                    MPN: 98134398004
                    Shock Absorbers
                    PX73 (Sports chassis -20 mm, without PASM)
                    Supersession
                    Supersession
                    Genuine Porsche Part (no longer available to order)
                    # 2
                    MPN: 99908413301
                    HEXAGON NUT M14X1,5
                    from £0.65
                    from £0.65
                    HEX. NUT Genuine Porsche Part - New (to order)
                    # 3
                    MPN: 99134312500
                    INSERT
                    from £32.82
                    from £32.82
                    INSERT Genuine Porsche Part - New (to order)
                    # 4
                    MPN: 99134301502
                    SHOCK ABSORBER BEARING
                    from £245.74
                    from £245.74
                    SHOCK ABSORBER MOUNTING Genuine Porsche Part - New (to order)
                    # 5
                    MPN: 99134350103
                    MOUNTING
                    from £80.19
                    from £80.19
                    MOUNTING Genuine Porsche Part - New (to order)
                    # 6
                    MPN: 99134351300
                    COMPENSATION RING
                    SHIM Genuine Porsche Part - New (to order)
                    # 7
                    MPN: 99134351101
                    Underlay upper
                    Supersession
                    Supersession
                    Genuine Porsche Part (no longer available to order)
                    # 8
                    MPN: 99134330105
                    HELPER SPRING
                    PX73 (Sports chassis -20 mm, without PASM)
                    from £27.05
                    from £27.05
                    HELPER SPRING Genuine Porsche Part - New (to order)
                    # 9
                    MPN: 99134350902
                    BELLOWS
                    PX73 (Sports chassis -20 mm, without PASM)
                    BELLOWS Genuine Porsche Part - New (to order)
                    # 10
                    MPN: 98134398006504
                    COIL SPRING - 1 PAIR OF SPRINGS IDENTIFICATION: >>>>RED LILAC LIGHT BLUE
                    PX73 (Sports chassis -20 mm, without PASM)
                    from £198.65
                    from £198.65
                    This part replaces part number 98134398006
                    1 PAIR OF SPRINGS Genuine Porsche Part - New (to order)
                    # 11
                    MPN: 99134356101
                    WASHER
                    from £10.03
                    from £10.03
                    WASHER Genuine Porsche Part - New (to order)
                    # 12
                    MPN: 99134352502
                    Support element lower
                    Supersession
                    Supersession
                    Genuine Porsche Part (no longer available to order)
                    # 13
                    MPN: 99908444701
                    HEXAGON NUT M8
                    hex. nut - M 8 Genuine Porsche Part - New (to order)
                    # 13
                    MPN: PAF003923
                    HEXAGON NUT M8
                    from £0.87
                    from £0.87
                    This part replaces part number 99908444709
                    hex. nut - M 8 Genuine Porsche Part - New (to order)
                    # 14
                    MPN: 99160611100
                    ACCELERATION SENSOR FOR BODYWORK
                    PX73 (Sports chassis -20 mm, without PASM) | P140 (Dynamic engine mounts (PADM))
                    from £175.17
                    from £175.17
                    ACCELERATION SENSOR FOR Genuine Porsche Part - New (to order)
                    # 15
                    MPN: 99161846514
                    CONTROL UNIT
                    PX73 (Sports chassis -20 mm, without PASM) | P140 (Dynamic engine mounts (PADM))
                    from £622.20
                    from £622.20
                    electronic control module Genuine Porsche Part - New (to order)
