porsche 2017 (718 boxster) manual gearbox parts diagram

302-010 - MANUAL GEARBOX

Porsche 2017 (718 Boxster) MANUAL GEARBOX Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    -
    RELAY LEVER
    see illustration: 701-000
    # 2
    -
    BRACKET
    see illustration: 701-000
    # 3
    -
    BRACKET
    see illustration: 701-000
    # 4
    MPN: 90037700303
    HEX. NUT
    M8
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # 5
    MPN: 90038509801
    TORX SCREW
    BM8X25
    TORX SCREW Genuine Porsche Part - New (to order)
    # 6
    MPN: 98160630300
    SENSOR MODULE
    Sender for gearbox neutral | position
    from £133.52
    from £133.52
    SENSOR MODULE Genuine Porsche Part - New (to order)
    # 7
    MPN: 98160680100
    SCREW, CHEESE HD.
    M6X18
    from £0.99
    from £0.99
    SCREW, CHEESE HD Genuine Porsche Part - New (to order)
    # 8
    MPN: 98160642000
    TEMPERATURE SENSOR
    from £25.17
    from £25.17
    TEMPERATURE SENSOR Genuine Porsche Part - New (to order)
    # 9
    MPN: 90012311120
    SEAL RING
    A14X20
    SEAL RING Genuine Porsche Part - New (to order)
    # 10
    MPN: 01E941521B
    back-up light switch
    REVERSE LIGHT SWITCH
    from £19.68
    from £19.68
    back-up light switch Genuine Porsche Part - New (to order)
    # 11
    MPN: 7PP905381B
    INDUCTIVE SENDER
    SPEED SENSOR
    from £111.70
    from £111.70
    INDUCTIVE SENDER Genuine Porsche Part - New (to order)
    # 12
    MPN: 98160680500
    O-RING
    14,4X1,98
    from £5.26
    from £5.26
    O-RING Genuine Porsche Part - New (to order)
    # 13
    MPN: 98160680300
    SCREW, ROUND HD.
    M6X14
    from £2.25
    from £2.25
    SCREW, ROUND HD Genuine Porsche Part - New (to order)
    # 14
    MPN: 00004320923
    SEALING GREASE FOR
    50 GR. | seal LIQUI MOLY | PU 53/WDR
    from £14.29
    from £14.29
    sealing grease for - seal - LIQUI MOLY - PU 53 / WDR - 50 GR. Genuine Porsche Part - New (to order)
