4800 (4.5 Litre 8 Cyliner Engine (340 Horsepower / 250 Kilowatt with Engine Code: 4800 and installed 05/2002-05/2006) | 4850 (4.5 Litre 8 Cyliner Engine (450 Horsepower / 331 Kilowatt with Engine Code: 4850 and installed 05/2002-05/2006)
porsche 2003 (cayenne e1 9pa) engine control parts diagram

103-015 - ENGINE CONTROL

Porsche 2003 (Cayenne E1 9PA) engine control Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                        #
                        Part number
                        Description
                        Price
                        # 1
                        MPN: 94810516902
                        TIMING CHAIN
                        from £206.24
                        from £206.24
                        # 2
                        MPN: 94810506802
                        SLIDE RAIL
                        Supersession
                        Supersession
                        # 3
                        MPN: 94810518101
                        CHAIN SPROCKET OUTLET CAMSHAFT
                        from £66.54
                        from £66.54
                        # 4
                        MPN: 94810418101
                        HEXAGON SOCKET HEAD BOLT M 12 X 1,5 X 140
                        from £6.56
                        from £6.56
                        # 5
                        MPN: 94810506502
                        TENSIONER BLADE
                        Supersession
                        Supersession
                        # 6
                        MPN: 94810518002
                        CHAIN TENSIONER
                        from £110.99
                        from £110.99
                        # 7
                        MPN: 99901502201
                        THREADED STUD M 10 X 25
                        from £4.52
                        from £4.52
                        # 8
                        MPN: 99901502101
                        THREADED STUD M 8 X 25
                        from £2.17
                        from £2.17
                        # 9
                        MPN: 94810516602
                        SLIDE RAIL
                        Supersession
                        Supersession
                        # 10
                        MPN: 94810502302
                        SLIDE RAIL
                        from £65.49
                        from £65.49
                        # 11
                        MPN: 90038504209
                        TORX SCREW BM 8 X 35
                        TORX SCREW BM 8 X 35
                        # 11
                        MPN: 90038504201
                        TORX SCREW BM 8 X 35
                        Supersession
                        Supersession
                        # 12
                        MPN: 90012314130
                        SEAL RING A 25 X 30
                        from £1.29
                        from £1.29
