P3FU (Porsche large roof system)
porsche 2003 (cayenne e1 9pa) glass roof parts diagram

811-005 - glass roof

Porsche 2003 (Cayenne E1 9PA) Glass roof Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                                #
                                                                                Part number
                                                                                Description
                                                                                Price
                                                                                # 1
                                                                                MPN: 95556200400
                                                                                WIND DEFLECTOR
                                                                                from £678.05
                                                                                from £678.05
                                                                                # 2
                                                                                MPN: 95556291600
                                                                                1 SET ATTACHMENT PARTS WIND DEFLECTOR
                                                                                from £87.90
                                                                                from £87.90
                                                                                # 2
                                                                                MPN: 95556290000
                                                                                GATE GUIDE WIND DEFLECTOR SEE WORKSHOP MANUAL SEE MAIN GROUP 6 60-3555
                                                                                from £97.45
                                                                                from £97.45
                                                                                # 3
                                                                                MPN: 95556290600
                                                                                TRIM LEFT A. RIGHT WIND DEFLECTOR
                                                                                from £12.77
                                                                                from £12.77
                                                                                # 4
                                                                                MPN: 95556290700
                                                                                SOFT TOP CATCH LEFT A. RIGHT
                                                                                from £244.29
                                                                                from £244.29
                                                                                # 5
                                                                                MPN: 95556400200
                                                                                GLASS ROOF FRONT
                                                                                from £980.71
                                                                                from £980.71
                                                                                # 6
                                                                                MPN: 95556291300
                                                                                SEAL
                                                                                from £87.08
                                                                                from £87.08
                                                                                # 7
                                                                                MPN: 95556272100
                                                                                SCREW M5 X 12,5
                                                                                from £17.10
                                                                                from £17.10
                                                                                # 8
                                                                                MPN: 95556205600
                                                                                COVER CENTER
                                                                                from £980.71
                                                                                from £980.71
                                                                                # 9
                                                                                MPN: 95556291400
                                                                                SEAL
                                                                                from £87.08
                                                                                from £87.08
                                                                                # 10
                                                                                MPN: 95556272200
                                                                                SCREW
                                                                                # 11
                                                                                MPN: 95556291500
                                                                                SEAL
                                                                                from £87.08
                                                                                from £87.08
                                                                                # 12
                                                                                MPN: 95556251900
                                                                                WATER DRAIN PIPE
                                                                                from £355.61
                                                                                from £355.61
                                                                                # 13
                                                                                MPN: 95556243900
                                                                                SEAL
                                                                                from £131.36
                                                                                from £131.36
                                                                                # 14
                                                                                MPN: 958898738
                                                                                REPAIR SET FRAME GLASS ROOF SEE WORKSHOP MANUAL RL 600619 ALSO USE: 000 043 305 72 CONTAINS ADDITIONAL POSITIONS: 10, 13, 25, 26, 27, 28
                                                                                from £4,379.76
                                                                                from £4,379.76
                                                                                # 14
                                                                                MPN: 95556245000
                                                                                FRAME WITH: COVER ALSO USE: 1X 000 043 206 76 SEE WORKSHOP MANUAL RL 600619
                                                                                from £4,342.16
                                                                                from £4,342.16
                                                                                # 14
                                                                                MPN: 00004330572
                                                                                PRIMER FOR ADHESIVE TAPE
                                                                                from £58.20
                                                                                from £58.20
                                                                                # 15
                                                                                MPN: N 90878601
                                                                                HEXAGON COLLAR NUT SELF-LOCKING M6
                                                                                # 16
                                                                                MPN: 95556242300
                                                                                SEAL OUTER
                                                                                from £205.91
                                                                                from £205.91
                                                                                # 17
                                                                                MPN: 95556244000
                                                                                SEAL INNER
                                                                                from £131.36
                                                                                from £131.36
                                                                                # 18
                                                                                MPN: 95556245900
                                                                                SEAL ALSO USE: 000 043 206 76 SEE WORKSHOP MANUAL RL 600619
                                                                                from £105.08
                                                                                from £105.08
                                                                                # 18
                                                                                MPN: 00004320676
                                                                                SEALANT
                                                                                # 20
                                                                                MPN: 95556291200
                                                                                1 SET ATTACHMENT PARTS 6 PCS CONTROL UNIT
                                                                                from £27.01
                                                                                from £27.01
                                                                                # 21
                                                                                MPN: 95561202500
                                                                                WIRE SET
                                                                                # 22
                                                                                MPN: 95562471300
                                                                                ELECTRIC DRIVE
                                                                                from £495.99
                                                                                from £495.99
                                                                                # 23
                                                                                MPN: 95556291200
                                                                                1 SET ATTACHMENT PARTS 6 PCS M5 X 30
                                                                                from £27.01
                                                                                from £27.01
                                                                                # 24
                                                                                MPN: 955562716003X6
                                                                                ROLLER BLIND - SAND BEIGE
                                                                                This part replaces part number 95556271600
                                                                                # 24
                                                                                MPN: 955562716003V5
                                                                                ROLLER BLIND - STEEL GREY
                                                                                This part replaces part number 95556271600
                                                                                # 24
                                                                                MPN: 955562716003Y7
                                                                                ROLLER BLIND - PALM GREEN
                                                                                from £780.58
                                                                                from £780.58
                                                                                This part replaces part number 95556271600
                                                                                # 24
                                                                                MPN: 955562716003W4
                                                                                ROLLER BLIND - BLACK
                                                                                This part replaces part number 95556271600
                                                                                # 24
                                                                                MPN: 95556211500
                                                                                STOP LEFT A. RIGHT ROLLER BLIND
                                                                                from £53.20
                                                                                from £53.20
                                                                                # 25
                                                                                MPN: 95556290800
                                                                                1 SET GLIDE PIECES LEFT A. RIGHT ROLLER BLIND
                                                                                from £50.94
                                                                                from £50.94
                                                                                # 26
                                                                                MPN: 95556291900
                                                                                THRUST PIECE LEFT
                                                                                from £27.18
                                                                                from £27.18
                                                                                # 26
                                                                                MPN: 95556291800
                                                                                THRUST PIECE RIGHT
                                                                                from £27.18
                                                                                from £27.18
                                                                                # 27
                                                                                MPN: 95556290900
                                                                                CORNER PART LEFT A. RIGHT
                                                                                from £16.36
                                                                                from £16.36
                                                                                # 28
                                                                                MPN: 95556241300
                                                                                LOCKING SEGMENT 4 PCS
                                                                                from £59.46
                                                                                from £59.46
                                                                                # 30
                                                                                MPN: 95562471300
                                                                                ELECTRIC DRIVE LEFT A. RIGHT GATE GUIDE
                                                                                from £495.99
                                                                                from £495.99
                                                                                # 31
                                                                                MPN: 95556290400
                                                                                TOGGLE CATCH LEFT A. RIGHT WIND DEFLECTOR
                                                                                from £148.54
                                                                                from £148.54
                                                                                # 32
                                                                                MPN: 95556291000
                                                                                COVER LEFT A. RIGHT TOGGLE CATCH
                                                                                from £37.36
                                                                                from £37.36
                                                                                # 34
                                                                                MPN: 95556291700
                                                                                REPAIR SET SEALING STRIP
                                                                                from £15.34
                                                                                from £15.34
                                                                                # 34
                                                                                MPN: 00004330049
                                                                                ACTIVATOR 113 ML
                                                                                # 35
                                                                                MPN: 95556202900
                                                                                WATER DRAINAGE HOSE LEFT
                                                                                from £38.16
                                                                                from £38.16
                                                                                # 35
                                                                                MPN: 95556203000
                                                                                Water drainage hose right rear
                                                                                from £38.16
                                                                                from £38.16
                                                                                # 36
                                                                                MPN: 95556220103
                                                                                WATER DRAINAGE HOSE LEFT FRONT
                                                                                from £76.56
                                                                                from £76.56
                                                                                # 36
                                                                                MPN: 95556220203
                                                                                WATER DRAINAGE HOSE RIGHT FRONT
                                                                                from £78.48
                                                                                from £78.48
                                                                                # 37
                                                                                MPN: 95556403500
                                                                                DRAIN TUBE
                                                                                from £5.40
                                                                                from £5.40
                                                                                # 38
                                                                                MPN: 95562826000
                                                                                HOSE BRACKET
                                                                                from £0.47
                                                                                from £0.47
                                                                                # 39
                                                                                MPN: N 90476101
                                                                                CABLE TIES
                                                                                from £2.31
                                                                                from £2.31
                                                                                # 40
                                                                                MPN: 00004320756
                                                                                GREASE 50 ML POLYLUB GLY 151
                                                                                from £27.33
                                                                                from £27.33
                                                                                # 41
                                                                                MPN: 95556211500
                                                                                STOP LEFT A. RIGHT ROLLER BLIND
                                                                                from £53.20
                                                                                from £53.20
