porsche 2003 (cayenne e1 9pa) compressor parts diagram

813-070 - COMPRESSOR

Porsche 2003 (Cayenne E1 9PA) Compressor Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Price
    # 1
    MPN: 95812601201
    COMPRESSOR
    PD9J (6-cylinder petrol engine, 3.2 l/177 kW (24 valves))
    from £1,748.22
    from £1,748.22
    This part replaces part number 95512601100 - and 1 more. Click to view details
    # 1
    MPN: 94812601101
    COMPRESSOR
    PD9K (8-cylinder petrol engine, 4.5 l/250 kW (V 8)) | PD9L (8-cylinder petrol engine, 4.5 l/330 kW (V 8) biturbo)
    # 2
    MPN: N 90660201
    HEXAGON HEAD BOLT (COMBI)
    PD9J (6-cylinder petrol engine, 3.2 l/177 kW (24 valves))
    from £3.71
    from £3.71
    # 2
    MPN: 90038501409
    TORX SCREW M 8 X 95
    PD9K (8-cylinder petrol engine, 4.5 l/250 kW (V 8)) | PD9L (8-cylinder petrol engine, 4.5 l/330 kW (V 8) biturbo)
    from £1.82
    from £1.82
    # 3
    MPN: N 10672701
    HEX COLLARED BOLT
    PD9J (6-cylinder petrol engine, 3.2 l/177 kW (24 valves))
    from £4.35
    from £4.35
    # 3
    MPN: 90038503109
    TORX SCREW M 10 X 90
    PD9K (8-cylinder petrol engine, 4.5 l/250 kW (V 8)) | PD9L (8-cylinder petrol engine, 4.5 l/330 kW (V 8) biturbo)
    # 4
    MPN: 95512601200
    BRACKET FOR COMPRESSOR LHD
    PD9J (6-cylinder petrol engine, 3.2 l/177 kW (24 valves)) | PL0L (Left-hand drive version)
    from £9.72
    from £9.72
    # 4
    MPN: 95512601210
    BRACKET FOR COMPRESSOR RHD
    PD9J (6-cylinder petrol engine, 3.2 l/177 kW (24 valves)) | PL0R (Right-hand drive version)
    from £9.72
    from £9.72
    # 4
    MPN: 94834713702
    BRACKET
    PD9K (8-cylinder petrol engine, 4.5 l/250 kW (V 8)) | PD9L (8-cylinder petrol engine, 4.5 l/330 kW (V 8) biturbo)
    from £7.62
    from £7.62
    # 5
    MPN: 99965119940
    CABLE HOLDER
    from £0.91
    from £0.91
    # 6
    MPN: 95514750100
    CENTRE SLEEVE
    CENTRE SLEEVE
    # 6
    MPN: 95514750101
    CENTRE SLEEVE 11,15 X 6,5
