porsche 2010 (cayenne e1 9pa) base engine short block parts diagram

101-016 - Base engine Short block

Porsche 2010 (Cayenne E1 9PA) Base engine Short block Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 1
MPN: 94610092160
BASE ENGINE COMPRISING: VALVE COVER CYLINDER HEAD CRANK DRIVE OIL SUMP VALVE ADJUSTER INSTALLATION KIT BUT WITHOUT: GASKETS ALSO USE: 1X 946 111 041 02 1X 946 111 042 02 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 1X 948 110 615 00
CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) with, P338 (Rear-wheel drive)
from £19,398.49
from £19,398.49
long block Genuine Porsche Part - New (to order)
# 1
MPN: 946100921RX
BASE ENGINE COMPRISING: VALVE COVER CYLINDER HEAD CRANK DRIVE OIL SUMP VALVE ADJUSTER INSTALLATION KIT BUT WITHOUT: GASKETS ALSO USE: 1X 946 111 041 02 1X 946 111 042 02 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 1X 948 110 615 00
CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) with, P338 (Rear-wheel drive)
from £13,578.93
from £13,578.93
Short Engine Genuine Porsche Part - New (to order)
# 1
MPN: 94610092165
BASE ENGINE COMPRISING: VALVE COVER CYLINDER HEAD CRANK DRIVE OIL SUMP VALVE ADJUSTER INSTALLATION KIT BUT WITHOUT: GASKETS ALSO USE: 1X 946 111 041 02 1X 946 111 042 02 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 1X 948 110 615 00
CXNA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CXNA and installed 05/2013-05/2014) CXNA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CXNA and installed 05/2014-05/2016) with, P338 (Rear-wheel drive)
from £19,398.49
from £19,398.49
long block Genuine Porsche Part - New (to order)
# 1
MPN: 946100921SX
BASE ENGINE COMPRISING: VALVE COVER CYLINDER HEAD CRANK DRIVE OIL SUMP VALVE ADJUSTER INSTALLATION KIT BUT WITHOUT: GASKETS ALSO USE: 1X 946 111 041 02 1X 946 111 042 02 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 1X 948 110 615 00
CXNA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CXNA and installed 05/2013-05/2014) CXNA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CXNA and installed 05/2014-05/2016) with, P338 (Rear-wheel drive)
from £13,578.93
from £13,578.93
Short Engine Genuine Porsche Part - New (to order)
# 1
MPN: 94610094160
BASE ENGINE COMPRISING: VALVE COVER CYLINDER HEAD CRANK DRIVE OIL SUMP VALVE ADJUSTER INSTALLATION KIT BUT WITHOUT: GASKETS ALSO USE: 1X 946 111 041 02 1X 946 111 042 02 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 1X 948 110 615 00
CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) with, P339 (All-wheel drive)
from £15,590.25
from £15,590.25
long block Genuine Porsche Part - New (to order)
# 1
MPN: 946100941RX
BASE ENGINE COMPRISING: VALVE COVER CYLINDER HEAD CRANK DRIVE OIL SUMP VALVE ADJUSTER INSTALLATION KIT BUT WITHOUT: GASKETS ALSO USE: 1X 946 111 041 02 1X 946 111 042 02 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 1X 948 110 615 00
CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) with, P339 (All-wheel drive)
from £10,913.21
from £10,913.21
Short Engine Genuine Porsche Part - New (to order)
# 1
MPN: 94610094165
BASE ENGINE COMPRISING: VALVE COVER CYLINDER HEAD CRANK DRIVE OIL SUMP VALVE ADJUSTER INSTALLATION KIT BUT WITHOUT: GASKETS ALSO USE: 1X 946 111 041 02 1X 946 111 042 02 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 1X 948 110 615 00
CXNA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CXNA and installed 05/2013-05/2014) CXNA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CXNA and installed 05/2014-05/2016) with, P339 (All-wheel drive)
long block Genuine Porsche Part - New (to order)
# 1
MPN: 946100941SX
BASE ENGINE COMPRISING: VALVE COVER CYLINDER HEAD CRANK DRIVE OIL SUMP VALVE ADJUSTER INSTALLATION KIT BUT WITHOUT: GASKETS ALSO USE: 1X 946 111 041 02 1X 946 111 042 02 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 1X 948 110 615 00
CXNA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CXNA and installed 05/2013-05/2014) CXNA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CXNA and installed 05/2014-05/2016) with, P339 (All-wheel drive)
long block Genuine Porsche Part - New (to order)
# 1
MPN: 94810653300
SEAL INSTALLATION KIT FOR BASE ENGINE ALSO USE: 2X 948 106 124 02 2X 948 106 154 01 2X 999 707 586 40 2X 999 701 825 40 1X 948 107 437 20 1X 948 107 438 20 6X 999 707 606 40 6X 999 704 020 90 6X 946 110 146 02
from £5.58
from £5.58
GASKET Genuine Porsche Part - New (to order)
# 2
MPN: 94610092050
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 23 1X 946 111 041 02 1X 946 111 042 02 6X 999 170 130 90 10X N 906 651 01
CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) with, P338 (Rear-wheel drive)
from £12,352.63
from £12,352.63
Short Engine Genuine Porsche Part - New (to order)
# 2
MPN: 946100920TX
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 23 1X 946 111 041 02 1X 946 111 042 02 6X 999 170 130 90 10X N 906 651 01
CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) with, P338 (Rear-wheel drive)
from £6,798.70
from £6,798.70
SHORT BLOCK 3.6L Genuine Porsche Part - New (to order)
# 2
MPN: 94610092055
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 23 1X 946 111 041 02 1X 946 111 042 02 6X 999 170 130 90 10X N 906 651 01
CXNA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CXNA and installed 05/2013-05/2014) CXNA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CXNA and installed 05/2014-05/2016) with, P338 (Rear-wheel drive)
from £12,352.63
from £12,352.63
Short Engine Genuine Porsche Part - New (to order)
# 2
MPN: 946100920UX
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 23 1X 946 111 041 02 1X 946 111 042 02 6X 999 170 130 90 10X N 906 651 01
CXNA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CXNA and installed 05/2013-05/2014) CXNA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CXNA and installed 05/2014-05/2016) with, P338 (Rear-wheel drive)
from £6,798.70
from £6,798.70
SHORT BLOCK 3.6L Genuine Porsche Part - New (to order)
# 2
MPN: 94610094050
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 23 1X 946 111 041 02 1X 946 111 042 02 6X 999 170 130 90 10X N 906 651 01 4X 999 707 641 40 2X 948 101 223 41
CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) with, P339 (All-wheel drive)
from £12,352.63
from £12,352.63
Short Engine Genuine Porsche Part - New (to order)
# 2
MPN: 946100940TX
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 23 1X 946 111 041 02 1X 946 111 042 02 6X 999 170 130 90 10X N 906 651 01 4X 999 707 641 40 2X 948 101 223 41
CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) with, P339 (All-wheel drive)
from £6,798.70
from £6,798.70
SHORT BLOCK 3.6L Genuine Porsche Part - New (to order)
# 2
MPN: 94610094055
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 23 1X 946 111 041 02 1X 946 111 042 02 6X 999 170 130 90 10X N 906 651 01 4X 999 707 641 40 2X 948 101 223 41
CXNA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CXNA and installed 05/2013-05/2014) CXNA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CXNA and installed 05/2014-05/2016) with, P339 (All-wheel drive)
from £12,352.63
from £12,352.63
Short Engine Genuine Porsche Part - New (to order)
# 2
MPN: 946100940UX
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 23 1X 946 111 041 02 1X 946 111 042 02 6X 999 170 130 90 10X N 906 651 01 4X 999 707 641 40 2X 948 101 223 41
CXNA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CXNA and installed 05/2013-05/2014) CXNA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CXNA and installed 05/2014-05/2016) with, P339 (All-wheel drive)
from £6,798.70
from £6,798.70
SHORT BLOCK 3.6L Genuine Porsche Part - New (to order)
# 2
MPN: 94810191020
SEALING FLANGE INSTALLATION KIT FOR SHORT BLOCK ALSO USE: 1X 948 106 533 00 2X 948 106 124 02 2X 948 106 154 01 2X 999 707 586 40 2X 999 701 825 40 1X 948 107 437 20 1X 948 107 438 20 6X 999 707 606 40 6X 999 704 020 90 6X 946 110 146 02
from £158.94
from £158.94
SEALING FLANGE Genuine Porsche Part - New (to order)
# 2
MPN: 99970757540
O-RING INSTALLATION KIT FOR SHORT BLOCK ALSO USE: 1X 999 707 481 40 1X 948 101 130 21 1X 948 101 125 20 1X 948 101 127 20 1X 948 101 129 21 000 043 204 35 1X 946 104 173 03 1X 946 104 174 03 16X 948 104 181 10
from £4.52
from £4.52
O-RING Genuine Porsche Part - New In stock
# 2
MPN: 94610593500
SEAL INSTALLATION KIT FOR SHORT BLOCK ALSO USE: 1X 946 105 936 00 2X 948 105 938 00 6X 948 105 937 02 20X 999 073 905 31 2X 999 073 908 31 1X 948 105 169 10 1X 948 105 023 12 1X 946 105 068 00 1X 948 105 065 10 1X 946 105 180 00 2X 948 105 166 12 1X 999 0
from £30.38
from £30.38
GASKET Genuine Porsche Part - New In stock
# 2
MPN: 94810722200
OIL FILTER INSERT INSTALLATION KIT FOR SHORT BLOCK ALSO USE: 000 043 305 33 22X 999 073 905 31 1X 948 107 322 00 2X 999 707 567 40 1X 999 707 547 40 1X 999 707 585 40 1X 999 707 568 40 1X 038 103 196 B 1X 946 107 275 21 1X 946 107 252 01
Supersession
Supersession
Genuine Porsche Part (no longer available to order)
