porsche 2010 (cayenne e1 9pa) base engine short block parts diagram

101-018 - Base engine Short block

Porsche 2010 (Cayenne E1 9PA) Base engine Short block Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 1
MPN: 94610096060
Base engine comprising: Valve cover Cylinder head Crank drive oil sump valve adjuster Installation kit but without: Gaskets also use: 2X 946 111 181 75 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 2X 999 701 048 40 2X 06L 109 311
P338 (Rear-wheel drive)
from £18,957.50
from £18,957.50
long block Genuine Porsche Part - New (to order)
# 1
MPN: 946100960RX
Base engine comprising: Valve cover Cylinder head Crank drive oil sump valve adjuster Installation kit but without: Gaskets also use: 2X 946 111 181 75 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 2X 999 701 048 40 2X 06L 109 311
P338 (Rear-wheel drive)
from £12,509.61
from £12,509.61
Short Engine Genuine Porsche Part - New (to order)
# 1
MPN: 94610096065
Base engine comprising: Valve cover Cylinder head Crank drive oil sump valve adjuster Installation kit but without: Gaskets also use: 2X 946 111 181 75 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 2X 999 701 048 40 2X 06L 109 311
P339 (All-wheel drive)
from £18,957.50
from £18,957.50
long block Genuine Porsche Part - New (to order)
# 1
MPN: 946100960SX
Base engine comprising: Valve cover Cylinder head Crank drive oil sump valve adjuster Installation kit but without: Gaskets also use: 2X 946 111 181 75 10X N 906 651 01 1X 999 707 582 41 1X 999 707 581 41 2X 999 701 048 40 2X 06L 109 311
P339 (All-wheel drive)
from £12,509.61
from £12,509.61
Short Engine Genuine Porsche Part - New (to order)
# 1
MPN: 94810653300
SEAL INSTALLATION KIT FOR BASE ENGINE ALSO USE: 2X 948 106 124 02 2X 948 106 154 01 2X 999 707 586 40 2X 999 701 825 40 2X 999 707 677 40 2X 999 707 677 41 6X 999 701 187 40 6X 946 110 328 61 6X 946 110 428 61 6X 946 110 146 60
from £5.58
from £5.58
GASKET Genuine Porsche Part - New (to order)
# 2
MPN: 94610096050
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 61 2X 946 111 181 75 6X 999 170 233 90 10X N 906 651 01
P338 (Rear-wheel drive)
from £10,831.28
from £10,831.28
Short Engine Genuine Porsche Part - New (to order)
# 2
MPN: 946100960TX
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 61 2X 946 111 181 75 6X 999 170 233 90 10X N 906 651 01
P338 (Rear-wheel drive)
from £7,581.88
from £7,581.88
PARTIEL MOTOR Genuine Porsche Part - New (to order)
# 2
MPN: 94610096055
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 61 2X 946 111 181 75 6X 999 170 233 90 10X N 906 651 01 4X 999 707 641 40 2X 948 101 223 41
P339 (All-wheel drive)
from £10,831.28
from £10,831.28
Short Engine Genuine Porsche Part - New (to order)
# 2
MPN: 946100960UX
SHORT BLOCK COMPRISING: CRANKCASE HOUSING PISTON CONROD CRANKSHAFT ALSO USE: 1X 946 107 013 61 2X 946 111 181 75 6X 999 170 233 90 10X N 906 651 01 4X 999 707 641 40 2X 948 101 223 41
P339 (All-wheel drive)
from £7,581.88
from £7,581.88
PARTIEL MOTOR Genuine Porsche Part - New (to order)
# 2
MPN: 94810191020
SEALING FLANGE INSTALLATION KIT FOR SHORT BLOCK ALSO USE: 1X 948 106 533 00 2X 948 106 124 02 2X 948 106 154 01 2X 999 707 586 40 2X 999 701 825 40 2X 999 707 677 40 2X 999 707 677 41 6X 946 110 428 61 6X 946 110 328 61 6X 999 701 187 42 6X 946 110 228 60
from £158.94
from £158.94
SEALING FLANGE Genuine Porsche Part - New (to order)
# 2
MPN: 99970757540
O-RING INSTALLATION KIT FOR SHORT BLOCK ALSO USE: 1X 999 707 481 40 1X 946 101 130 04 1X 948 101 125 20 1X 948 101 127 20 1X 946 101 129 04 1X 000 043 209 93 1X 000 043 204 35 2X 999 073 913 31 9X 999 073 914 31 21X 999 073 905 31 2X 999 073 903 31 1X 946
from £4.52
from £4.52
O-RING Genuine Porsche Part - New In stock
# 2
MPN: 94610593565
SEAL INSTALLATION KIT FOR SHORT BLOCK ALSO USE: 1X 946 105 936 65 6X 946 105 937 65 17X 999 073 905 31 7X 999 073 908 31 1X 946 105 169 75 1X 948 105 023 12 1X 946 105 068 00 1X 948 105 065 10 1X 946 105 180 76 2X 948 105 166 12 1X 999 015 022 01 2X 999 0
from £30.38
from £30.38
GASKET Genuine Porsche Part - New (to order)
# 2
MPN: 94810722200
OIL FILTER INSERT INSTALLATION KIT FOR SHORT BLOCK ALSO USE: 999 915 573 43 19X 999 073 905 31 21X 999 073 905 31 1X 946 107 322 75 2X 999 707 567 40 1X 999 707 547 40 1X 999 707 585 40 1X 999 707 568 40 1X 038 103 196 B 1X 946 107 275 21 1X 946 107 252 7
P338 (Rear-wheel drive) | P339 (All-wheel drive)
Supersession
Supersession
Genuine Porsche Part (no longer available to order)
