CRCC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CRCC and installed 05/2011-05/2016) | CRCB (3.0 Litre 6 Cyliner Engine (210 Horsepower / 155 Kilowatt with Engine Code: CRCB and installed 05/2011-05/2016) | CWJA (3.0 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWJA and installed 05/2013-05/2015) CWJA (3.0 Litre 6 Cyliner Engine (300 Horsepower / 221 Kilowatt with Engine Code: CWJA and installed 05/2015-05/2016)
porsche 2010 (cayenne e1 9pa) camshaft, valves cover parts diagram

103-055 - camshaft, valves Cover

Porsche 2010 (Cayenne E1 9PA) camshaft, valves Cover Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                              #
                              Part number
                              Description
                              Key
                              Price
                              # 1
                              MPN: 95810504200
                              CAMSHAFT OUTLET CYLINDERS 1-3
                              from £327.45
                              from £327.45
                              camshaft Genuine Porsche Part - New (to order)
                              # 2
                              MPN: 95810504110
                              CAMSHAFT INLET CYLINDERS 1-3
                              CAMSHAFT INLET CYLINDERS 1-3
                              camshaft Genuine Porsche Part - New (to order)
                              # 2
                              MPN: 95810504111
                              CAMSHAFT INLET CYLINDERS 1-3
                              CAMSHAFT INLET CYLINDERS 1-3
                              camshaft Genuine Porsche Part - New (to order)
                              # 2
                              MPN: 95810504112
                              CAMSHAFT INLET CYLINDERS 1-3
                              CRCC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CRCC and installed 05/2011-05/2016) | CRCB (3.0 Litre 6 Cyliner Engine (210 Horsepower / 155 Kilowatt with Engine Code: CRCB and installed 05/2011-05/2016)
                              from £600.63
                              from £600.63
                              camshaft Genuine Porsche Part - New (to order)
                              # 2
                              MPN: 95810504130
                              CAMSHAFT INLET CYLINDERS 1-3
                              CWJA (3.0 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWJA and installed 05/2013-05/2015) CWJA (3.0 Litre 6 Cyliner Engine (300 Horsepower / 221 Kilowatt with Engine Code: CWJA and installed 05/2015-05/2016)
                              from £495.42
                              from £495.42
                              camshaft Genuine Porsche Part - New (to order)
                              # 3
                              MPN: 95810504400
                              CAMSHAFT INLET CYLINDERS 4-6
                              CAMSHAFT INLET CYLINDERS 4-6
                              camshaft Genuine Porsche Part - New (to order)
                              # 3
                              MPN: 95810504401
                              CAMSHAFT INLET CYLINDERS 4-6
                              CRCC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CRCC and installed 05/2011-05/2016) | CRCB (3.0 Litre 6 Cyliner Engine (210 Horsepower / 155 Kilowatt with Engine Code: CRCB and installed 05/2011-05/2016)
                              camshaft Genuine Porsche Part - New (to order)
                              # 3
                              MPN: 95810504420
                              CAMSHAFT INLET CYLINDERS 4-6
                              CWJA (3.0 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWJA and installed 05/2013-05/2015) CWJA (3.0 Litre 6 Cyliner Engine (300 Horsepower / 221 Kilowatt with Engine Code: CWJA and installed 05/2015-05/2016)
                              from £452.95
                              from £452.95
                              camshaft Genuine Porsche Part - New (to order)
                              # 4
                              MPN: 95810504310
                              CAMSHAFT OUTLET CYLINDERS 4-6
                              from £600.63
                              from £600.63
                              camshaft Genuine Porsche Part - New (to order)
                              # 5
                              MPN: 95510560120
                              INLET VALVE
                              from £39.24
                              from £39.24
                              INTAKE VALVE Genuine Porsche Part - New (to order)
                              # 6
                              MPN: 95810532230
                              EXHAUST VALVE
                              CRCC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CRCC and installed 05/2011-05/2016) | CRCB (3.0 Litre 6 Cyliner Engine (210 Horsepower / 155 Kilowatt with Engine Code: CRCB and installed 05/2011-05/2016)
                              from £39.53
                              from £39.53
                              EXHAUST VALVE Genuine Porsche Part - New (to order)
                              # 6
                              MPN: 95810532250
                              EXHAUST VALVE
                              CWJA (3.0 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWJA and installed 05/2013-05/2015) CWJA (3.0 Litre 6 Cyliner Engine (300 Horsepower / 221 Kilowatt with Engine Code: CWJA and installed 05/2015-05/2016)
                              from £57.61
                              from £57.61
                              EXHAUST VALVE Genuine Porsche Part - New (to order)
                              # 7
                              MPN: 95810542310
                              EQUALIZING ELEMENT, HYDRAULIC
                              from £10.49
                              from £10.49
                              Differential Case Genuine Porsche Part - New (to order)
                              # 8
                              MPN: 95510541720
                              CAM LEVER
                              from £14.38
                              from £14.38
                              PULL LEVER Genuine Porsche Part - New (to order)
                              # 9
                              MPN: 95510565120
                              COTTER, SPLIT
                              from £3.30
                              from £3.30
                              COTTER, SPLIT Genuine Porsche Part - New (to order)
                              # 10
                              MPN: 95510564110
                              SPRING DISC UPPER
                              from £8.99
                              from £8.99
                              SPRING SEAT Genuine Porsche Part - New (to order)
                              # 11
                              MPN: 95510511910
                              VALVE SPRING
                              from £8.01
                              from £8.01
                              VALVE SPRING Genuine Porsche Part - New (to order)
                              # 12
                              MPN: 95510511510
                              VALVE STEM SEAL INLET 6 MM ALSO USE: 955 105 501 00
                              VALVE STEM SEAL INLET 6 MM ALSO USE: 955 105 501 00
                              from £9.78
                              from £9.78
                              VALVE GUIDE SEAL Genuine Porsche Part - New (to order)
                              # 12
                              MPN: 95810511520
                              VALVE STEM SEAL OUTLET 6 MM ALSO USE: 955 105 501 00
                              from £9.78
                              from £9.78
                              VALVE GUIDE SEAL Genuine Porsche Part - New (to order)
                              # 12
                              MPN: 95510550100
                              SLEEVE FOR VALVE STEM SEAL 6 X 20
                              from £1.82
                              from £1.82
                              SLEEVE Genuine Porsche Part - New (to order)
                              # 13
                              MPN: 95810513000
                              COVER CYLINDERS 1-3 ALSO USE: 000 043 207 49 M >>0 43366
                              COVER Genuine Porsche Part - New (to order)
                              # 13
                              MPN: 95810513001
                              COVER CYLINDERS 1-3 ALSO USE: 000 043 207 49 M 0 43367 >>
                              from £48.76
                              from £48.76
                              COVER Genuine Porsche Part - New (to order)
                              # 14
                              MPN: 95810559200
                              SEAL ALSO USE: 000 043 207 49 M >>0 43366
                              GASKET Genuine Porsche Part - New (to order)
                              # 14
                              MPN: 95810559202
                              SEAL ALSO USE: 000 043 207 49 M 0 43367 >>
                              from £12.22
                              from £12.22
                              GASKET Genuine Porsche Part - New (to order)
                              # 15
                              MPN: 95810512900
                              COVER CYLINDERS 4-6 ALSO USE: 000 043 207 49 M >>0 43366
                              COVER Genuine Porsche Part - New (to order)
                              # 15
                              MPN: 95810512901
                              COVER CYLINDERS 4-6 ALSO USE: 000 043 207 49 M 0 43367 >>
                              from £52.02
                              from £52.02
                              COVER Genuine Porsche Part - New (to order)
                              # 16
                              MPN: 95810559110
                              SEAL ALSO USE: 000 043 207 49 M >>0 43366
                              GASKET Genuine Porsche Part - New (to order)
                              # 16
                              MPN: 95810559111
                              SEAL ALSO USE: 000 043 207 49 M 0 43367 >>
                              from £12.22
                              from £12.22
                              GASKET Genuine Porsche Part - New (to order)
                              # 17
                              MPN: N 10156206
                              OVAL HEXAGON SOCKET HEAD BOLT M6X30 M >>0 43366
                              from £0.87
                              from £0.87
                              OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                              HEXALOBULAR SOCKETM6X30 Genuine Lamborghini - New (to order)
                              # 17
                              MPN: N 10582103
                              OVAL HEAD COUNTERSUNK BOLT M6X40 WITH MULTI-POINT SOCKET HEAD M 0 43367 >>
                              from £0.99
                              from £0.99
                              SCREW, COUNTERSUNK WITH POLYGON Genuine Porsche Part - New In stock
                              HEXALOBULAR SOCKET Genuine Lamborghini - New In stock
                              # 18
                              MPN: N 10124306
                              Hexagon socket flat M6X20 head bolt
                              from £0.87
                              from £0.87
                              This part replaces part number 99907334401 - and 1 more. Click to view details
                              OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New In stock
                              HEXALOBULAR SOCKET M6 X 20 Genuine Lamborghini - New In stock
                              # 19
                              MPN: 00004320749
                              SEALANT 80ml
                              SEALANT 80ml
                              SEALANT Genuine Porsche Part - New (to order)
                              # 19
                              MPN: 95810190200
                              SEALANT 80ml
                              SEALANT 80ml
                              SEALANT Genuine Porsche Part - New (to order)
                              # 19
                              MPN: 00004330635
                              SEALANT 80ml
                              from £36.44
                              from £36.44
                              SEALANT Genuine Porsche Part - New (to order)
