porsche 2010 (cayenne e1 9pa) exhaust system control line parts diagram

202-055 - exhaust system Control line

Porsche 2010 (Cayenne E1 9PA) exhaust system Control line Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # 1
                          MPN: 97011131651
                          CONTROL LINE LEFT
                          from £54.24
                          from £54.24
                          control line Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 97011131251
                          Change-over valve with: Control line
                          Change-over valve with: Control line
                          Change-over valve Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 97011131252
                          CHANGE-OVER VALVE WITH: CONTROL LINE SEE TECHNICAL INFORMATION GR. 2, 2637 88/16
                          Change-over valve Genuine Porsche Part - New (to order)
                          # 3
                          MPN: 95551164500
                          CLIP
                          from £1.18
                          from £1.18
                          CLIP Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 7PP906283F
                          CHANGE-OVER VALVE SEE TECHNICAL INFORMATION GR. 2, 2637 88/16
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          Genuine Lamborghini (no longer available to order)
                          # 5
                          MPN: 298941749
                          FILTER ELEMENT SEE TECHNICAL INFORMATION GR. 2, 2637 88/16
                          from £40.74
                          from £40.74
                          FILTER Genuine Porsche Part - New (to order)
                          # 6
                          MPN: 99950799740
                          BRACKET 6,0 / 9,5 SEE TECHNICAL INFORMATION GR. 2, 2637 88/16
                          from £0.97
                          from £0.97
                          BRACKET Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 99161294400
                          WIRE SET ADAPTER SEE TECHNICAL INFORMATION GR. 2, 2637 88/16
                          from £43.20
                          from £43.20
                          harness Genuine Porsche Part - New (to order)
                          # 8
                          MPN: N 10741501
                          CABLE TIES A05-4.5 X 140 X C01-6 SEE TECHNICAL INFORMATION GR. 2, 2637 88/16
                          from £1.36
                          from £1.36
                          TIE WRAP Genuine Porsche Part - New (to order)
                          # 9
                          MPN: 97011072700
                          CAP CLOSURE CONTROL LINE
                          CWDA (3.0 Litre 6 Cyliner Engine (420 Horsepower / 309 Kilowatt with Engine Code: CWDA and installed 05/2013-05/2016) | CWD (3.0 Litre 6 Cyliner Engine (420 Horsepower / 309 Kilowatt with Engine Code: CWD and installed 05/2014-05/2016) with, P0E2 (Long wheelbase)
                          from £0.68
                          from £0.68
                          CAP Genuine Porsche Part - New (to order)
                          # 10
                          MPN: 97011131751
                          CONTROL LINE RIGHT
                          4870 (4.8 Litre 8 Cyliner Engine (524 Horsepower / 386 Kilowatt with Engine Code: 4870 and installed 08/2009-07/2010) 4870 (4.8 Litre 8 Cyliner Engine (500 Horsepower / 368 Kilowatt with Engine Code: 4870 and installed 08/2010-05/2013) 4870 (4.8 Litre 8 Cyliner Engine (539 Horsepower / 397 Kilowatt with Engine Code: 4870 and installed 05/2011-05/2013) 4870 (4.8 Litre 8 Cyliner Engine (549 Horsepower / 404 Kilowatt with Engine Code: 4870 and installed 05/2011-05/2013) | CWBA (4.8 Litre 8 Cyliner Engine (519 Horsepower / 382 Kilowatt with Engine Code: CWBA and installed 05/2013-05/2016) | CWB (4.8 Litre 8 Cyliner Engine (519 Horsepower / 382 Kilowatt with Engine Code: CWB and installed 05/2015-05/2016) | CWFA (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWFA and installed 05/2013-05/2014) | CWF (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWF and installed 05/2013-05/2016)
                          from £54.24
                          from £54.24
                          control line Genuine Porsche Part - New (to order)
                          # 10
                          MPN: 97011131751
                          CONTROL LINE RIGHT
                          CWDA (3.0 Litre 6 Cyliner Engine (420 Horsepower / 309 Kilowatt with Engine Code: CWDA and installed 05/2013-05/2016) | CWD (3.0 Litre 6 Cyliner Engine (420 Horsepower / 309 Kilowatt with Engine Code: CWD and installed 05/2014-05/2016) with, P0E1 (Shorter wheelbase)
                          from £54.24
                          from £54.24
                          control line Genuine Porsche Part - New (to order)
                          # 11
                          -
                          VACUUM UNIT SEE ILLUSTRATION, ITEM: 202-050,15 AND SEE ILLUSTRATION, ITEM: 202-085,11
                          # 12
                          MPN: 97011131352
                          CONTROL LINE CENTER
                          from £47.99
                          from £47.99
                          control line Genuine Porsche Part - New (to order)
                          # 13
                          MPN: 99950717640
                          LINE HOLDER 6,0
                          from £2.86
                          from £2.86
                          LINE HOLDER Genuine Porsche Part - New (to order)
                          # 14
                          MPN: 97011131850
                          ELBOW FITTING
                          from £22.26
                          from £22.26
                          ELBOW Genuine Porsche Part - New (to order)
                          # 15
                          -
                          PRESSURE ACCUMULATOR SEE ILLUSTRATION: 606-000
