porsche 2010 (cayenne e1 9pa) roof channel parts diagram

810-015 - ROOF CHANNEL

Porsche 2010 (Cayenne E1 9PA) roof channel Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                        #
                        Part number
                        Description
                        Key
                        Price
                        # 1
                        MPN: 97055940100GRV
                        ROOF CHANNEL LEFT D >>- MJ 2013 - PRIMED
                        from £288.72
                        from £288.72
                        This part replaces part number 97055940100
                        PRIMED Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 97055940100GRV
                        ROOF CHANNEL LEFT D - MJ 2014>>- PRIMED
                        P0E1 (Shorter wheelbase)
                        from £288.72
                        from £288.72
                        This part replaces part number 97055940100
                        PRIMED Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 97055940101GRV
                        ROOF CHANNEL LEFT D - MJ 2014>>- PRIMED
                        P0E2 (Long wheelbase)
                        from £158.05
                        from £158.05
                        This part replaces part number 97055940101
                        PRIMED Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 97055940200GRV
                        ROOF CHANNEL RIGHT D >>- MJ 2013 - PRIMED
                        from £288.72
                        from £288.72
                        This part replaces part number 97055940200
                        PRIMED Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 97055940200GRV
                        ROOF CHANNEL RIGHT D - MJ 2014>>- PRIMED
                        P0E1 (Shorter wheelbase)
                        from £288.72
                        from £288.72
                        This part replaces part number 97055940200
                        PRIMED Genuine Porsche Part - New (to order)
                        # 1
                        MPN: 97055940201GRV
                        ROOF CHANNEL RIGHT D - MJ 2014>>- PRIMED
                        P0E2 (Long wheelbase)
                        from £324.79
                        from £324.79
                        This part replaces part number 97055940201
                        PRIMED Genuine Porsche Part - New (to order)
                        # 2
                        MPN: 97055940500
                        SEAL ROOF CHANNEL D >>- MJ 2013
                        from £19.65
                        from £19.65
                        GASKET Genuine Porsche Part - New (to order)
                        # 2
                        MPN: 97055940500
                        SEAL ROOF CHANNEL D - MJ 2014>>
                        P0E1 (Shorter wheelbase)
                        from £19.65
                        from £19.65
                        GASKET Genuine Porsche Part - New (to order)
                        # 2
                        MPN: 97055940501
                        SEAL ROOF CHANNEL D - MJ 2014>>
                        P0E2 (Long wheelbase)
                        from £19.65
                        from £19.65
                        GASKET Genuine Porsche Part - New (to order)
                        # 3
                        MPN: 97055961300G2L
                        FLAP REAR - PRIMED
                        Supersession
                        Supersession
                        This part replaces part number 97055961300
                        Genuine Porsche Part (no longer available to order)
                        # 3
                        MPN: 97055961100G2L
                        FLAP FRONT - PRIMED
                        Supersession
                        Supersession
                        This part replaces part number 97055961100
                        Genuine Porsche Part (no longer available to order)
                        # 4
                        MPN: 97055972900
                        CARRIER FLAP ROOF CHANNEL
                        from £6.34
                        from £6.34
                        BRACKET Genuine Porsche Part - New (to order)
                        # 5
                        MPN: 97055983600G2L
                        COVER REAR RIGHT - PRIMED
                        from £12.26
                        from £12.26
                        This part replaces part number 97055983600
                        PRIMED Genuine Porsche Part - New (to order)
                        # 5
                        MPN: 97055983500G2L
                        COVER REAR LEFT - PRIMED
                        from £12.26
                        from £12.26
                        This part replaces part number 97055983500
                        PRIMED Genuine Porsche Part - New (to order)
                        # 6
                        MPN: 97055973600
                        COVER RIGHT VORNE
                        from £9.09
                        from £9.09
                        COVER Genuine Porsche Part - New (to order)
                        # 6
                        MPN: 97055973500
                        COVER LEFT VORNE
                        from £9.09
                        from £9.09
                        COVER Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 97055971101
                        BRACKET OUTER ROOF CHANNEL BLACK
                        BRACKET Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 97055971103
                        BRACKET CENTER ROOF CHANNEL WHITE
                        from £1.18
                        from £1.18
                        BRACKET Genuine Porsche Part - New (to order)
                        # 8
                        MPN: 3D5853707B
                        RETAINING CLIP BRACKET ROOF CHANNEL
                        from £8.22
                        from £8.22
                        Retaining Clip Genuine Porsche Part - New (to order)
                        # 9
                        MPN: N 90787802
                        CUP RIVET FOR RETAINING CLIP
                        from £0.69
                        from £0.69
                        RIVET Genuine Porsche Part - New (to order)
                        # 10
                        MPN: 97055974500
                        LINING FOR FENDER SIDE LEFT
                        from £6.43
                        from £6.43
                        LINING FOR FENDER Genuine Porsche Part - New (to order)
                        # 10
                        MPN: 97055974600
                        LINING FOR FENDER SIDE RIGHT
                        from £6.43
                        from £6.43
                        LINING FOR FENDER Genuine Porsche Part - New (to order)
                        # 11
                        MPN: 00004320762
                        1 SET PROTECTIVE FILM FOR REPAIR SET PAINT ROOF CHANNEL
                        from £6.48
                        from £6.48
                        Set Genuine Porsche Part - New (to order)
                        # 12
                        MPN: 99950014201
                        RIVETTED CAP NUT LUGGAGE CARRIER BT-NT-MU M6/0,8-3
                        from £0.84
                        from £0.84
                        RIVETTED CAP NUT Genuine Porsche Part - New (to order)
                        # 13
                        MPN: 97050488501
                        CAP CLOSURE SUPPORT ROOF CARRIER
                        CAP Genuine Porsche Part - New (to order)
                        # 13
                        MPN: N 0140325
                        T-BOLT 3X5,35
                        from £0.47
                        from £0.47
                        T-BOLT Genuine Porsche Part - New (to order)
                        # 14
                        MPN: 97055940300GRV
                        ROOF CHANNEL LEFT FRONT D - MJ 2014>>- PRIMED
                        P0E2 (Long wheelbase)
                        from £240.52
                        from £240.52
                        This part replaces part number 97055940300
                        PRIMED Genuine Porsche Part - New (to order)
                        # 14
                        MPN: 97055940400GRV
                        ROOF CHANNEL RIGHT FRONT D - MJ 2014>>- PRIMED
                        P0E2 (Long wheelbase)
                        from £240.52
                        from £240.52
                        This part replaces part number 97055940400
                        PRIMED Genuine Porsche Part - New (to order)
                        # 15
                        MPN: 97055940700
                        CLIP LEFT ROOF CHANNEL D - MJ 2014>>
                        P0E2 (Long wheelbase)
                        from £12.13
                        from £12.13
                        CLAMP Genuine Porsche Part - New (to order)
                        # 15
                        MPN: 97055940800
                        CLIP RIGHT ROOF CHANNEL D - MJ 2014>>
                        P0E2 (Long wheelbase)
                        from £12.13
                        from £12.13
                        CLAMP Genuine Porsche Part - New (to order)
