901-003 - CONTROL UNITS

Porsche 2010 (Cayenne E1 9PA) Control units Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                  #
                                  Part number
                                  Description
                                  Price
                                  # 1
                                  MPN: 95561860301
                                  CONTROL UNIT - DME -
                                  PD5X (6-cyl. spark-ignition engine, 3.6 l/206 kW FSI)
                                  from £1,840.61
                                  from £1,840.61
                                  # 1
                                  MPN: 95561860310
                                  CONTROL UNIT - DME - SEE TECHNICAL INFORMATION GR. 9 NR. 3/09 KD -NR. 2470
                                  PD50 (6-cylinder diesel engine, 3.0 l/176 kW TDI) | P7GG (EU 4 emissions concept with particle filter)
                                  from £1,034.53
                                  from £1,034.53
                                  # 1
                                  MPN: 95561860320
                                  CONTROL UNIT - DME - SEE TECHNICAL INFORMATION GR. 9 NR. 3/09 KD - NR 2470
                                  PD50 (6-cylinder diesel engine, 3.0 l/176 kW TDI) | P0GZ (EU 3 diesel emissions concept with E-OBD)
                                  from £1,349.78
                                  from £1,349.78
                                  # 1
                                  MPN: 95561860403
                                  CONTROL UNIT - DME -
                                  PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI) | PD5Z (8-cylinder petrol engine 4.8 l/368 KW V8 biturbo)
                                  from £865.61
                                  from £865.61
                                  # 2
                                  MPN: 95561823300
                                  RETAINER FOR CONTROL UNITS
                                  PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI) | PD5Z (8-cylinder petrol engine 4.8 l/368 KW V8 biturbo)
                                  from £16.30
                                  from £16.30
                                  # 3
                                  MPN: 95561823400
                                  RETAINER FOR CONTROL UNITS
                                  PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI) | PD5Z (8-cylinder petrol engine 4.8 l/368 KW V8 biturbo)
                                  from £16.30
                                  from £16.30
                                  # 3
                                  MPN: 95561813302
                                  RETAINER FOR CONTROL UNITS
                                  PD5X (6-cyl. spark-ignition engine, 3.6 l/206 kW FSI)
                                  from £19.38
                                  from £19.38
                                  # 3
                                  MPN: 95561813302
                                  RETAINER FOR CONTROL UNITS
                                  PD50 (6-cylinder diesel engine, 3.0 l/176 kW TDI)
                                  from £19.38
                                  from £19.38
                                  # 3
                                  MPN: 95561815000
                                  CLIP SIDE
                                  PD5X (6-cyl. spark-ignition engine, 3.6 l/206 kW FSI)
                                  from £2.00
                                  from £2.00
                                  # 3
                                  MPN: 95561815100
                                  CLIP REAR
                                  PD5X (6-cyl. spark-ignition engine, 3.6 l/206 kW FSI)
                                  from £2.00
                                  from £2.00
                                  # 4
                                  MPN: N 10521503
                                  OVAL HEXAGON SOCKET HEAD BOLT M 6 X 16
                                  PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI) | PD5Z (8-cylinder petrol engine 4.8 l/368 KW V8 biturbo)
                                  from £0.59
                                  from £0.59
                                  # 5
                                  MPN: N 10248003
                                  SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD M 6 X 14
                                  PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI) | PD5Z (8-cylinder petrol engine 4.8 l/368 KW V8 biturbo)
                                  from £1.25
                                  from £1.25
                                  # 6
                                  MPN: N 0150829
                                  HEXAGON COLLAR NUT M 6
                                  from £0.47
                                  from £0.47
                                  # 7
                                  MPN: N 10156307
                                  HEX COLLARED BOLT M 6 X 12
                                  from £0.63
                                  from £0.63
                                  # 8
                                  MPN: 95561812003
                                  CONTROL UNIT FOR AUTOMATIC GEARBOX F >>9P-8LA26 516 F >>9P-8LA26 515
                                  PG0R (Tiptronic s) | PD5X (6-cyl. spark-ignition engine, 3.6 l/206 kW FSI)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812004
                                  Control unit for automatic gearbox F 9P-8LA26 517>>F 9P-8LA26 516>>D >>- MJ 2008
                                  Control unit for automatic gearbox F 9P-8LA26 517>>F 9P-8LA26 516>>D >>- MJ 2008
                                  # 8
                                  MPN: 95561812005
                                  Control unit for automatic gearbox F 9P-8LA26 517>>F 9P-8LA26 516>>D >>- MJ 2009
                                  Control unit for automatic gearbox F 9P-8LA26 517>>F 9P-8LA26 516>>D >>- MJ 2009
                                  # 8
                                  MPN: 95561812006
                                  CONTROL UNIT FOR AUTOMATIC GEARBOX F 9P-8LA26 517>>F 9P-8LA26 516>>
                                  PG0R (Tiptronic s) | PD5X (6-cyl. spark-ignition engine, 3.6 l/206 kW FSI)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812010
                                  Control unit for automatic gearbox D - MJ 2009>>- MJ 2009
                                  PG0R (Tiptronic s) | PD50 (6-cylinder diesel engine, 3.0 l/176 kW TDI)
                                  # 8
                                  MPN: 95561812011
                                  Control unit for automatic gearbox D - MJ 2010>>
                                  PG0R (Tiptronic s) | PD50 (6-cylinder diesel engine, 3.0 l/176 kW TDI)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812103
                                  CONTROL UNIT FOR AUTOMATIC GEARBOX F >>9P-8LA52 982 F >>9P-8LA52 988
                                  PG0R (Tiptronic s) | PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812104
                                  Control unit for automatic gearbox F 9P-8LA52 983>>F 9P-8LA52 989>>D >>- MJ 2009
                                  Control unit for automatic gearbox F 9P-8LA52 983>>F 9P-8LA52 989>>D >>- MJ 2009
                                  # 8
                                  MPN: 95561812105
                                  CONTROL UNIT FOR AUTOMATIC GEARBOX F 9P-8LA52 983>>F 9P-8LA52 989>>
                                  PG0R (Tiptronic s) | PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812110
                                  CONTROL UNIT FOR AUTOMATIC GEARBOX F >>9P-8LA73 576 F >>9P-8LA73 577
                                  , PG0R (Tiptronic s) | PE0W (GTS version) | PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812111
                                  Control unit for automatic gearbox F 9P-8LA73 577>>F 9P-8LA73 578>>D >>- MJ 2009
                                  , PG0R (Tiptronic s) | PE0W (GTS version) | PE2D (Special model Transsyberia) | PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI)
                                  # 8
                                  MPN: 95561812112
                                  Control unit for automatic gearbox D - MJ 2010>>
                                  PG0R (Tiptronic s) | PE0W (GTS version) | PE1T (Sondermodell CAYENNE. Porsche Design Edition 3) | PE2D (Special model Transsyberia) | PD5V (8-cylinder petrol engine 4.8 l/280 KW V8 FSI)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812203
                                  CONTROL UNIT FOR AUTOMATIC GEARBOX F >>9P-8LA96 403 F >>9P-8LA96 436
                                  PG0R (Tiptronic s) | PD5Z (8-cylinder petrol engine 4.8 l/368 KW V8 biturbo)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812204
                                  Control unit for automatic gearbox F 9P-8LA96 404>>F 9P-8LA96 437>>D >>- MJ 2009
                                  PG0R (Tiptronic s) | PD5Z (8-cylinder petrol engine 4.8 l/368 KW V8 biturbo)
                                  # 8
                                  MPN: 95561812205
                                  Control unit for automatic gearbox D - MJ 2010>>
                                  PG0R (Tiptronic s) | PD5Z (8-cylinder petrol engine 4.8 l/368 KW V8 biturbo)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812210
                                  CONTROL UNIT FOR AUTOMATIC GEARBOX F >>9P-8LA96 403 F >>9P-8LA96 436
                                  PG0R (Tiptronic s) | PE81 (Enhanced performance engine)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812211
                                  Control unit for automatic gearbox F 9P-8LA96 404>>F 9P-8LA96 437>>D >>- MJ 2009
                                  PG0R (Tiptronic s) | PE81 (Enhanced performance engine)
                                  # 8
                                  MPN: 95561812212
                                  Control unit for automatic gearbox D - MJ 2010>>
                                  PG0R (Tiptronic s) | PE81 (Enhanced performance engine)
                                  from £597.20
                                  from £597.20
                                  # 8
                                  MPN: 95561812211
                                  Control unit for automatic gearbox D - MJ 2009>>- MJ 2009
                                  PG0R (Tiptronic s) | PE8A (Turbo S)
                                  # 8
                                  MPN: 95561812212
                                  Control unit for automatic gearbox D - MJ 2010>>
                                  PG0R (Tiptronic s) | PE8A (Turbo S)
                                  from £597.20
                                  from £597.20
                                  # 9
                                  MPN: 95561802502
                                  Control unit Connection f lock control unit lengthwise D >>- MJ 2008
                                  Control unit Connection f lock control unit lengthwise D >>- MJ 2008
                                  # 9
                                  MPN: 95561802503
                                  CONTROL UNIT CONNECTION F LOCK CONTROL UNIT LENGTHWISE
                                  PG0R (Tiptronic s)
                                  from £427.66
                                  from £427.66
                                  # 9
                                  MPN: 95561802522
                                  Control unit Connection f lock control unit lengthwise D >>- MJ 2008
                                  Control unit Connection f lock control unit lengthwise D >>- MJ 2008
                                  # 9
                                  MPN: 95561802523
                                  CONTROL UNIT CONNECTION F LOCK CONTROL UNIT LENGTHWISE
                                  PG0L (6-speed manual transmission for all-wheel drive vehicle)
                                  from £427.66
                                  from £427.66
                                  # 10
                                  MPN: 95561812901
                                  BRACKET
                                  from £19.62
                                  from £19.62
                                  # 11
                                  MPN: N 10171105
                                  HEX COLLARED BOLT M 6 X 16
                                  from £0.58
                                  from £0.58
                                  # 12
                                  MPN: 95561802404
                                  CONTROL UNIT FOR DIFFERENTIAL LOCKS
                                  P1Y1 (Differential lock, rear, centre differential lock)
                                  from £762.74
                                  from £762.74
                                  # 13
                                  MPN: 95561813000
                                  BRACKET
                                  P1Y1 (Differential lock, rear, centre differential lock)
                                  from £10.45
                                  from £10.45
                                  # 14
                                  MPN: N 10473401
                                  HEXAGON SOCKET HEAD PANEL BOLT 6 X 20
                                  P1Y1 (Differential lock, rear, centre differential lock)
                                  from £0.61
                                  from £0.61
                                  # 15
                                  MPN: 95561812700
                                  ONBOARD SUPPLY CONTROL UNIT
                                  PJ0L (340 A (70 Ah) battery) | PJ0Z (520 A (110 Ah) battery) | PJ1U (450 A (95 Ah) battery)
                                  from £552.19
                                  from £552.19
                                  # 16
                                  MPN: 95561813101
                                  BRACKET FOR VEHICLE'S LHD ELECTRICAL SYSTEM CONTROL UNIT
                                  PL0L (Left-hand drive version)
                                  from £32.58
                                  from £32.58
                                  # 16
                                  MPN: 95561813200
                                  BRACKET FOR VEHICLE'S RHD ELECTRICAL SYSTEM CONTROL UNIT
                                  PL0R (Right-hand drive version)
                                  from £29.58
                                  from £29.58
                                  # 17
                                  MPN: N 10205802
                                  HEXAGON COLLAR NUT SELF-LOCKING M 6
                                  from £1.25
                                  from £1.25
                                  # 18
                                  MPN: 95561805901
                                  CONTROL UNIT
                                  from £314.98
                                  from £314.98
                                  # 19
                                  MPN: 95561804010
                                  Control unit Tow hitch D - MJ 2008>>- MJ 2008
                                  Control unit Tow hitch D - MJ 2008>>- MJ 2008
                                  # 19
                                  MPN: 95561804011
                                  Control unit Tow hitch D - MJ 2008>>- MJ 2008
                                  Control unit Tow hitch D - MJ 2008>>- MJ 2008
                                  # 19
                                  MPN: 95561804012
                                  CONTROL UNIT TOW HITCH
                                  from £438.16
                                  from £438.16
                                  # 20
                                  MPN: 95561813700
                                  RETAINER FOR CONTROL UNITS
                                  from £6.59
                                  from £6.59
                                  # 21
                                  MPN: N 10464802
                                  OVAL HEXAGON SOCKET HEAD BOLT 4 X 12
                                  from £0.47
                                  from £0.47
                                  # 22
                                  MPN: N 10459201
                                  HEXAGON SOCKET HEAD BOLT M 5 X 12
                                  from £0.47
                                  from £0.47
                                  # 23
                                  MPN: N 90475903
                                  SPEED NUT M 5 X 13,6 X 11,5
                                  from £0.76
                                  from £0.76
                                  # 24
                                  MPN: N 10338302
                                  SETTING SCREW M 5 X 12
                                  from £0.47
                                  from £0.47
                                  # 25
                                  MPN: 95561804201
                                  CONTROL UNIT FOR PARKING AID
                                  # 26
                                  MPN: 95561813600
                                  BRACKET FOR PARKING AID CONTROL UNIT
                                  from £6.59
                                  from £6.59
                                  # 27
                                  MPN: 95561830401
                                  CONTROL UNIT FOR ADAPTIVE SUSPENSION
                                  P1BK (Air suspension with levelling system and height adjustment (PASM)) | P without D50
                                  from £1,141.71
                                  from £1,141.71
                                  # 27
                                  MPN: 95561830401
                                  CONTROL UNIT FOR ADAPTIVE SUSPENSION
                                  P1BK (Air suspension with levelling system and height adjustment (PASM)) | PD50 (6-cylinder diesel engine, 3.0 l/176 kW TDI)
                                  from £1,141.71
                                  from £1,141.71
                                  # 27
                                  MPN: 95561830410
                                  CONTROL UNIT FOR ADAPTIVE SUSPENSION
                                  PE0W (GTS version) | PE1T (Sondermodell CAYENNE. Porsche Design Edition 3) | P1BH (Suspension/dampers, standard 2 PASM) | P1BK (Air suspension with levelling system and height adjustment (PASM))
                                  from £693.47
                                  from £693.47
                                  # 28
                                  MPN: 95561821500
                                  BRACKET
                                  from £20.53
                                  from £20.53
                                  # 29
                                  MPN: N 10415903
                                  OVAL HEXAGON SOCKET HEAD BOLT 4 X 12
                                  from £0.47
                                  from £0.47
                                  # 30
                                  MPN: 95561012702
                                  CONTROL UNIT FOR GATEWAY
                                  from £369.96
                                  from £369.96
                                  # 31
                                  MPN: 95561804500
                                  CONTROL UNIT FOR REVERSING CAMERA SYSTEM
                                  P7X8 (Ultrasound parking aid and reversing camera) | P7X9 (Rear view camera system)
                                  from £205.52
                                  from £205.52
                                  # 32
                                  MPN: 95561805000
                                  BRACKET
                                  P7X8 (Ultrasound parking aid and reversing camera) | P7X9 (Rear view camera system)
                                  from £16.30
                                  from £16.30
                                  # 33
                                  MPN: N 90819501
                                  OVAL-HEAD SCREW ST 4,8 X 13
                                  P7X8 (Ultrasound parking aid and reversing camera) | P7X9 (Rear view camera system)
                                  from £0.47
                                  from £0.47
                                  # 34
                                  MPN: N 10669701
                                  SPEED NUT ST 4,8
                                  P7X8 (Ultrasound parking aid and reversing camera) | P7X9 (Rear view camera system)
                                  from £0.47
                                  from £0.47
                                  # 35
                                  MPN: 95561806800
                                  CONTROL UNIT - PDCC -
                                  CONTROL UNIT - PDCC -
                                  # 35
                                  MPN: 95561806801
                                  CONTROL UNIT - PDCC -
                                  CONTROL UNIT - PDCC -
                                  # 35
                                  MPN: 95561806803
                                  CONTROL UNIT - PDCC -
                                  P0AW (Front and rear anti-roll bars with active Body control -PDCC-) | P1BK (Air suspension with levelling system and height adjustment (PASM))
                                  from £433.11
                                  from £433.11
                                  # 35
                                  MPN: 95561806810
                                  CONTROL UNIT - PDCC -
                                  CONTROL UNIT - PDCC -
                                  # 35
                                  MPN: 95561806812
                                  CONTROL UNIT - PDCC -
                                  PE0W (GTS version) | P0AW (Front and rear anti-roll bars with active Body control -PDCC-) | P1BK (Air suspension with levelling system and height adjustment (PASM))
                                  from £479.56
                                  from £479.56
                                  # 35
                                  MPN: 95561806812
                                  CONTROL UNIT - PDCC -
                                  PE1T (Sondermodell CAYENNE. Porsche Design Edition 3) | P0AW (Front and rear anti-roll bars with active Body control -PDCC-) | P1BK (Air suspension with levelling system and height adjustment (PASM))
                                  from £479.56
                                  from £479.56
                                  # 36
                                  MPN: 95561807000
                                  RETAINER FOR CONTROL UNITS
                                  P0AW (Front and rear anti-roll bars with active Body control -PDCC-)
                                  from £6.46
                                  from £6.46
                                  # 37
                                  MPN: N 01508210
                                  HEXAGON COLLAR NUT M 6
                                  P0AW (Front and rear anti-roll bars with active Body control -PDCC-)
                                  from £0.47
                                  from £0.47
                                  # 38
                                  MPN: 95561808000
                                  CONTROL UNIT REAR LID
                                  P4E7 (Tailgate/trunk lid power closing)
                                  from £430.55
                                  from £430.55
                                  # 38
                                  -
                                  BRACKET SEE ILLUSTRATION: 803-007
                                  P4E7 (Tailgate/trunk lid power closing)
                                  # 39
                                  MPN: 95561808200
                                  ACCELERATOR SENSOR
                                  P4E7 (Tailgate/trunk lid power closing)
                                  from £158.82
                                  from £158.82
                                  # 40
                                  MPN: 95561808400
                                  RETAINER FOR ACCELERATION SENSOR
                                  P4E7 (Tailgate/trunk lid power closing)
                                  from £84.82
                                  from £84.82
                                  # 41
                                  MPN: N 90598804
                                  OVAL HEXAGON SOCKET HEAD BOLT M 6 X 12
                                  P4E7 (Tailgate/trunk lid power closing)
                                  from £0.53
                                  from £0.53
                                  # 42
                                  MPN: 90011909102
                                  SOCKET HEAD BOLT M 6 X 16
                                  SOCKET HEAD BOLT M 6 X 16
                                  from £0.54
                                  from £0.54
                                  # 42
                                  MPN: 90011909101
                                  SOCKET HEAD BOLT M 6 X 16
                                  P4E7 (Tailgate/trunk lid power closing)
                                  from £1.53
                                  from £1.53
                                  # 43
                                  MPN: 90008403102
                                  HEXAGON NUT M 6
                                  P4E7 (Tailgate/trunk lid power closing)
                                  from £0.47
                                  from £0.47
                                  # 44
                                  MPN: 95564123000
                                  BUZZER
                                  P4E7 (Tailgate/trunk lid power closing)
                                  from £25.40
                                  from £25.40
                                  # 44
                                  -
                                  ALARM HORN CONTROL UNIT TILT ANGLE SENSOR SEE ILLUSTRATION: 903-000
