porsche 2020 (cayenne e3 9ya/9yb) dome strut parts diagram

801-010 - dome strut

Porsche 2020 (Cayenne E3 9YA/9YB) Dome strut Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: PAB806303B
                DOME STRUT FIREWALL SUSPENSION STRUT MOUNTING
                from £84.69
                from £84.69
                dome strut Genuine Porsche Part - New (to order)
                # 2
                MPN: PAB80564500
                REINFORCEMENT SUSPENSION STRUT MOUNTING FIREWALL
                from £98.01
                from £98.01
                REINFORCEMENT Genuine Porsche Part - New (to order)
                # 3
                MPN: PAB80639101
                Plenum chamber cover Closing element
                Plenum chamber cover Closing element
                PLENUM CHAMBER COVER Genuine Porsche Part - New (to order)
                # 3
                MPN: PAB80639100
                CLOSING ELEMENT WATER BOX
                from £78.86
                from £78.86
                END PLATE Genuine Porsche Part - New (to order)
                # 4
                MPN: PAB80250700
                CONNECTING PIECE WING CARRIER
                from £169.74
                from £169.74
                CONNECTING PIECE Genuine Porsche Part - New (to order)
                # 4
                MPN: PAB80250701
                CONNECTING PIECE WING CARRIER
                from £57.56
                from £57.56
                CONNECTING PIECE Genuine Porsche Part - New (to order)
                # 7
                MPN: N 0195308
                HEX COLLARED BOLT M8X25 TO BE USED FOR ITEM: 1
                from £2.27
                from £2.27
                BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New In stock
                HEX COLLARED BOLT Genuine Bentley Part - New (to order)
                HEXAGON FLANGE M8X25 Genuine Lamborghini - New In stock
                # 8
                MPN: N 10665001
                FLAT HEAD MULTI-POINT M8X30 SOCKET BOLT TO BE USED FOR ITEM: 1,2
                from £1.12
                from £1.12
                Flat head multi-point Genuine Porsche Part - New (to order)
                FLAT HEAD MULTI-POINT SOCKET BOLT Genuine Bentley Part - New (to order)
                12-POINT SOCKET M8X30 Genuine Lamborghini - New (to order)
                # 9
                MPN: PAF00537100
                HEXAGON BOLT M6X14 TO BE USED FOR ITEM: 3
                from £1.26
                from £1.26
                SCREW, HEX. HD Genuine Porsche Part - New (to order)
                # 10
                MPN: N 91228201
                HEX SOCKET HEAD BOLT (COMBI) M6X55 TO BE USED FOR ITEM: 4
                from £0.65
                from £0.65
                HEX SOCKET HEAD BOLT (COMBI) Genuine Porsche Part - New (to order)
                HEX SOCKET HEAD BOLT (COMBI) Genuine Bentley Part - New (to order)
                HEXALOBULAR SOCKETM6X55-S23 Genuine Lamborghini - New In stock
