102-000 - crankshaft
Porsche 2010 (987 Cayman) Crankshaft Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 9A110207704
crankshaft
crankshaft
# 1
MPN: 9A110207720
crankshaft
crankshaft
from £3,591.66
from £3,591.66
# 2
MPN: 90009503100
SPRING PIN 6,0 X 16
from £0.56
from £0.56
# 3
MPN: 90030201600
CYLINDER PIN A 6,0 X 16
from £1.20
from £1.20
# 4
MPN: 9A110122202
SHAFT OIL SEAL 52X72X9
Supersession
Supersession
# 5
MPN: 99710121201
SHAFT OIL SEAL 85X105X11
Supersession
Supersession
# 6
MPN: 9A110391402
CONROD COMPRISING: CONROD 6 PCS
from £1,344.29
from £1,344.29
# 7
MPN: 9A110312202
BUSH - CONNECTING ROD D = 22 REWORK REQUIRED
from £5.02
from £5.02
# 8
MPN: 9A110311502
BOLT - CONNECTING ROD M 10 X 1,25 X 51
# 9
MPN: 9A110305300
connecting rod bearing shell Identification: >>>>red
Supersession
Supersession
# 9
MPN: 9A110305301
connecting rod bearing shell Identification: >>>>yellow
Supersession
Supersession
# 9
MPN: 9A110305302
connecting rod bearing shell Identification: >>>>blue
Supersession
Supersession
# 10
MPN: 9A110106400
crankshaft bearing Identification: >>>>red
Supersession
Supersession
# 10
MPN: 9A110106401
crankshaft bearing Identification: >>>>yellow
Supersession
Supersession
# 10
MPN: 9A110106402
crankshaft bearing Identification: >>>>blue
from £13.21
from £13.21
# 11
MPN: 9A110106300
crankshaft bearing with: Partial-groove Identification: >>>>red
Supersession
Supersession
# 11
MPN: 9A110106301
crankshaft bearing with: Partial-groove Identification: >>>>yellow
Supersession
Supersession
# 11
MPN: 9A110106302
crankshaft bearing with: Partial-groove Identification: >>>>blue
# 12
MPN: 9A110105200
crankshaft bearing Identification: >>>>red
Supersession
Supersession
# 12
MPN: 9A110105201
crankshaft bearing Identification: >>>>yellow
Supersession
Supersession
# 12
MPN: 9A110105202
crankshaft bearing Identification: >>>>blue
# 13
MPN: 99610113200
THRUST WASHER D = 63
Supersession
Supersession
# 14
MPN: 9G211401200
DUAL-MASS FLYWHEEL
DUAL-MASS FLYWHEEL
# 14
MPN: 9G211401201
DUAL-MASS FLYWHEEL
DUAL-MASS FLYWHEEL
# 14
MPN: 9G211401202
DUAL-MASS FLYWHEEL
A120 (2.9 Litre 6 Cyliner Engine (265 Horsepower / 195 Kilowatt with Engine Code: A120 and installed 08/2008-05/2012) with, P480 (6-speed manual transmission)
Supersession
Supersession
# 14
MPN: 9G211401220
DUAL-MASS FLYWHEEL
DUAL-MASS FLYWHEEL
# 14
MPN: 9G211401221
DUAL-MASS FLYWHEEL
DUAL-MASS FLYWHEEL
# 14
MPN: 9G211401222
DUAL-MASS FLYWHEEL
A121 (3.4 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: A121 and installed 08/2008-05/2012) A121 (3.4 Litre 6 Cyliner Engine (330 Horsepower / 243 Kilowatt with Engine Code: A121 and installed 05/2011-05/2012) with, P480 (6-speed manual transmission)
from £1,237.31
from £1,237.31
# 14
MPN: 9G211402000
DUAL-MASS FLYWHEEL
DUAL-MASS FLYWHEEL
# 14
MPN: 9G211402001
DUAL-MASS FLYWHEEL
DUAL-MASS FLYWHEEL
# 14
MPN: 9G211402002
DUAL-MASS FLYWHEEL
P250 (PDK transmission (dual clutch))
from £1,237.31
from £1,237.31
# 15
MPN: N 90665101
SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD M 10 X 1 X 29
from £2.21
from £2.21
# 16
MPN: 9A110214602
PULLEY WITH: VIBRATION DAMPER
Supersession
Supersession
# 17
-
V-BELT SEE ILLUSTRATION: 101-010
