501-005 - DRIVE SHAFT
Porsche 2016 (981 Cayman GT4) Drive shaft Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 98133202380
DRIVE SHAFT LEFT
P480 (6-speed manual transmission)
# 1
MPN: 98133202480
DRIVE SHAFT RIGHT
P480 (6-speed manual transmission)
# 2
MPN: 99951004701
SOCKET HEAD BOLT M10X46,5
from £2.29
from £2.29
# 3
MPN: 9P1501375
SPACER
from £4.86
from £4.86
# 4
MPN: 99633295700
TERMINAL
P480 (6-speed manual transmission)
from £7.38
from £7.38
# 5
MPN: 90004105501
SECURING RING 29X1,5
from £2.14
from £2.14
# 6
MPN: WHT007021
HEX. NUT, SELF-LOCKING WITH M22X1.5 WASHER
from £6.68
from £6.68
# 7
MPN: 00004321008
SEALANT 1 TUBE 20 GRAM
from £58.37
from £58.37
This part replaces part number 00004320536
# 8
MPN: 99733226700
END CAP
P480 (6-speed manual transmission)
from £13.52
from £13.52
# 9
MPN: 99133203080
CONSTANT VELOCITY JOINT
P480 (6-speed manual transmission)
from £253.66
from £253.66
# 10
MPN: 99733295500
BELLOWS INCLUDED CAP
P480 (6-speed manual transmission)
from £45.49
from £45.49
# 11
MPN: 99633229300
BELLOWS
P480 (6-speed manual transmission)
from £34.16
from £34.16
# 12
MPN: 99633225700
TERMINAL
from £2.05
from £2.05
