porsche 2016 (981 cayman gt4) seat parts diagram

817-060 - SEAT

Porsche 2016 (981 Cayman GT4) SEAT Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    MPN: 99152120190
    seat frame
    left | seat (PR:373)
    seat frame Genuine Porsche Part - New (to order)
    # 1
    MPN: 91852120201
    seat frame
    right | seat | 918 Spyder (PR:374)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # 1
    MPN: 99152191390
    repair kit
    seat frame | seat
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # 2
    MPN: 99152140190
    SEAT
    seat |
    with: | airbag unit (PR:373)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    CARBON GLOSS BLACK
    This part replaces part number 99152140190
    # 2
    MPN: 99152140290
    SEAT
    seat |
    with: | airbag unit (PR:374)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    CARBON GLOSS BLACK
    This part replaces part number 99152140290
    # 2
    MPN: 99152140291
    SEAT
    seat |
    with: | airbag unit (PR:374,560)
    SEAT Genuine Porsche Part - New (to order)
    # -
    -
    CARBON GLOSS BLACK
    # 3
    MPN: 99152158190
    foam part
    backrest | Centre part (PR:373,374)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # 4
    MPN: 91852153100
    foam part
    outer | backrest (PR:373,374)
    from £214.92
    from £214.92
    foam part Genuine Porsche Part - New (to order)
    # 5
    MPN: 91852155100
    foam part
    headrest (PR:373,374)
    foam part Genuine Porsche Part - New (to order)
    # 6
    MPN: 91852153500
    foam part
    outer | Seat cushion (PR:373,374)
    from £124.84
    from £124.84
    foam part Genuine Porsche Part - New (to order)
    # 6
    MPN: 91852153600
    foam part
    outer | Seat cushion (PR:373,374)
    from £126.39
    from £126.39
    foam part Genuine Porsche Part - New (to order)
    # 7
    MPN: 91852157100
    foam part
    left | Seat cushion (PR:373,374)
    from £218.62
    from £218.62
    foam part Genuine Porsche Part - New (to order)
    # 7
    MPN: 91861894500
    repair kit for passenger seat
    right | occupant detection | Seat cushion |
    with: | Completed (PR:374,560)
    from £2,249.41
    from £2,249.41
    repair kit for passenger seat Genuine Porsche Part - New (to order)
    # 8
    MPN: 99152114190
    backrest cover
    left | Outer part (PR:373,951)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    BLACK/PLATINUM GREY
    -28,78
    This part replaces part number 99152114190
    # -
    -
    BLACK/GUARDS RED
    -68
    This part replaces part number 99152114190
    # -
    -
    BLACK/RACING YELLOW
    -58
    # 8
    MPN: 99152114290
    backrest cover
    right | Outer part (PR:374,951)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    BLACK/PLATINUM GREY
    -28,78
    This part replaces part number 99152114290
    # -
    -
    BLACK/GUARDS RED
    -68
    This part replaces part number 99152114290
    # -
    -
    BLACK/RACING YELLOW
    -58
    # 9
    MPN: 99152115190
    BACKREST CENTRE PART W. COVER
    (PR:373,374, 951)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    Black
    This part replaces part number 99152115190
    # 10
    MPN: 91852116112
    SEAT COVER
    Seat cushion (PR:373,374, 951)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    Black
    This part replaces part number 91852116112
    # 10
    MPN: 91852116102
    COVER
    Seat cushion (PR:373,374, 951)
    COVER Genuine Porsche Part - New (to order)
    # -
    -
    Black
    # 10
    MPN: 91852116106
    COVER
    right | Seat cushion (PR:374,560, 951)
    COVER Genuine Porsche Part - New (to order)
    # -
    -
    Black
    # 10
    MPN: 91852116116
    SEAT COVER
    right | Seat cushion (PR:374,560, 951)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    Black
    This part replaces part number 91852116116
    # 11
    MPN: 98152118180
    COVER FOR HEADREST
    right | | GT4 | STICKUNG (PR:373,374, 951,981)
    COVER FOR HEADREST Genuine Porsche Part - New (to order)
    # -
    -
    BLACK/PLATINUM GREY
    -28,78
    # -
    -
    BLACK/GUARDS RED
    -68
    # -
    -
    BLACK/RACING YELLOW
    -58
    # 12
    MPN: 91852151300
    BRACKET - FIRE EXTINGUISHER
    right (PR:373,374, 509)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # 13
    MPN: 91861320101
    SWITCH
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    Black
    -28,68,78,58
    This part replaces part number 91861320101
    # 14
    MPN: 91852130100
    SEAT
    (PR:373)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    Black
    -28,68,78,58
    This part replaces part number 91852130100
    # 14
    MPN: 91852130200
    SEAT
    (PR:374)
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    Black
    -28,68,78,58
    This part replaces part number 91852130200
    # 15
    MPN: N 0152612
    CLAMP
    Mount | Seat cover
    from £0.47
    from £0.47
    CLAMP Genuine Porsche Part - New (to order)
    # 16
    MPN: 9P1980341
    POSITIONSSENSOR
    Position | Seat rail |
    also use: | N 907.321.02
    from £70.47
    from £70.47
    POSITIONSSENSOR Genuine Porsche Part - New (to order)
    # 17
    MPN: N 90732102
    HEXAGON SOCKET FLAT
    head bolt | TP 4 X 16 | Mount | Sensor
    from £0.47
    from £0.47
    HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
    # 18
    MPN: 91852191100
    repair kit
    Cover | bowden cable
    from £48.28
    from £48.28
    repair kit Genuine Porsche Part - New (to order)
