porsche 2020 (718 cayman) parking brake parts diagram

603-050 - PARKING BRAKE

Porsche 2020 (718 Cayman) Parking brake Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 1
              MPN: 971698533
              1 SET: BRAKE SHOES WITH LININGS
              1 SET: BRAKE SHOES WITH LININGS
              BRAKE SHOE Genuine Porsche Part - New (to order)
              # 1
              MPN: 971698533E
              1 SET: BRAKE SHOES WITH LININGS REPAIR SET ALSO USE: 2X 298 609 717 2X 971 609 715 4X 298 609 583 USE IF REQUIRED: 2X 298 609 723
              from £179.26
              from £179.26
              This part replaces part number 971698533C
              1 SET: BRAKE SHOES WITH LININGS Genuine Porsche Part - New (to order)
              # 2
              MPN: 298609723
              ADJUSTMENT SCREW
              from £5.73
              from £5.73
              adjustment screw - D - MJ 2000>> Genuine Porsche Part - New (to order)
              ADJUSTMENT SCREW Genuine Bentley Part - New (to order)
              # 3
              MPN: 298609717
              TENSION SPRING
              from £5.34
              from £5.34
              TENSION SPRING Genuine Porsche Part - New In stock
              TENSION SPRING Genuine Bentley Part - New (to order)
              TENSION SPRING Genuine Porsche Part - Used In stock
              # 4
              MPN: 298609715
              TENSION SPRING
              from £5.34
              from £5.34
              TENSION SPRING Genuine Porsche Part - New (to order)
              TENSION SPRING Genuine Porsche Part - Used In stock
              # 5
              MPN: 298609583
              PRESSURE SPRING
              from £9.49
              from £9.49
              This part replaces part number 97035274100
              PRESSURE SPRING Genuine Porsche Part - New (to order)
              PRESSURE SPRING Genuine Bentley Part - New (to order)
              # 6
              MPN: 298609404
              SERVOMOTOR LEFT USE IF REQUIRED: 999 073 452 01
              from £343.67
              from £343.67
              This part replaces part number 97035209205
              motor for adjustment Genuine Porsche Part - New (to order)
              electric motor Genuine Aston Martin - New (to order)
              # 6
              MPN: 298609403
              Servomotor right use if required: 999 073 452 01
              from £343.67
              from £343.67
              This part replaces part number 97035209101 - and 1 more. Click to view details
              motor for adjustment Genuine Porsche Part - New (to order)
              electric motor Genuine Aston Martin - New (to order)
              # 7
              MPN: 99907345201
              LOCATING BOLT M8X38
              from £0.74
              from £0.74
              SCREW Genuine Porsche Part - New (to order)
