CDUD (3.0 Litre 6 Cyliner Engine (245 Horsepower / 180 Kilowatt with Engine Code: CDUD and installed 05/2013-09/2018) | CTBA (3.0 Litre 6 Cyliner Engine (258 Horsepower / 190 Kilowatt with Engine Code: CTBA and installed 05/2013-09/2018) | CTBB (3.0 Litre 6 Cyliner Engine (211 Horsepower / 155 Kilowatt with Engine Code: CTBB and installed 05/2013-09/2018) | CTBC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CTBC and installed 05/2013-09/2018)
porsche 2015 (macan) oil-conducting housing oil pump vacuum pump oil sump parts diagram

104-040 - Oil-conducting housing oil pump Vacuum pump oil sump

Porsche 2015 (Macan) Oil-conducting housing oil pump Vacuum pump oil sump Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                      #
                                                                      Part number
                                                                      Description
                                                                      Key
                                                                      Price
                                                                      # 1
                                                                      MPN: 95810706610
                                                                      GUIDE TUBE ALSO USE: 1X 955 107 427 00
                                                                      from £29.38
                                                                      from £29.38
                                                                      GUIDE TUBE Genuine Porsche Part - New (to order)
                                                                      # 2
                                                                      MPN: 95510742700
                                                                      O-RING 12X2
                                                                      from £7.38
                                                                      from £7.38
                                                                      O-RING Genuine Porsche Part - New In stock
                                                                      # 3
                                                                      MPN: N 10554005
                                                                      ROUND HD. SCREW M6X35
                                                                      from £1.10
                                                                      from £1.10
                                                                      Genuine Porsche Part (no longer available to order)
                                                                      ROUND HD. SCREW Genuine Bentley Part - New (to order)
                                                                      SCREW M6X35 Genuine Lamborghini - New In stock
                                                                      # 4
                                                                      MPN: N 10124306
                                                                      Hexagon socket flat M6X20 head bolt
                                                                      from £0.73
                                                                      from £0.73
                                                                      This part replaces part number 99907334401 - and 1 more. Click to view details
                                                                      OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New In stock
                                                                      HEXAGON SOCKET FLAT HEAD BOLT Genuine Bentley Part - New (to order)
                                                                      HEXALOBULAR SOCKET M6 X 20 Genuine Lamborghini - New In stock
                                                                      # 5
                                                                      MPN: 95810716810
                                                                      SEALING CAP
                                                                      from £7.60
                                                                      from £7.60
                                                                      SEALING CAP Genuine Porsche Part - New (to order)
                                                                      # 6
                                                                      MPN: N 90813802
                                                                      O-RING 5X1,9
                                                                      from £1.70
                                                                      from £1.70
                                                                      O-RING Genuine Porsche Part - New (to order)
                                                                      O-RING Genuine Bentley Part - New (to order)
                                                                      O-RING Genuine Lamborghini - New (to order)
                                                                      # 7
                                                                      MPN: 95810707123
                                                                      oil-conducting housing
                                                                      from £390.24
                                                                      from £390.24
                                                                      oil-conducting housing Genuine Porsche Part - New (to order)
                                                                      # 8
                                                                      MPN: 95510227700
                                                                      SPRING PIN 6,2X22
                                                                      from £1.74
                                                                      from £1.74
                                                                      PIN Genuine Porsche Part - New (to order)
                                                                      # 9
                                                                      MPN: 95810760900
                                                                      SEAL
                                                                      from £4.86
                                                                      from £4.86
                                                                      GASKET Genuine Porsche Part - New (to order)
                                                                      # 10
                                                                      MPN: 95810761000
                                                                      SEAL
                                                                      from £4.86
                                                                      from £4.86
                                                                      GASKET Genuine Porsche Part - New (to order)
                                                                      # 11
                                                                      MPN: WHT004873
                                                                      FILLISTER HEAD BOLT WITH M7X40 MULTI-POINT SOCKET HEAD
                                                                      from £1.36
                                                                      from £1.36
                                                                      FILLISTER HD. SCREW WITH Genuine Porsche Part - New (to order)
                                                                      FILLISTER HEAD BOLT WITH MULTI-POINT SOCKET HEAD Genuine Bentley Part - New (to order)
                                                                      # 12
                                                                      MPN: WHT004874
                                                                      FILLISTER HEAD BOLT WITH M7X105X39 MULTI-POINT SOCKET HEAD
                                                                      from £2.16
                                                                      from £2.16
                                                                      FILLISTER HD. SCREW WITH Genuine Porsche Part - New (to order)
                                                                      FILLISTER HEAD BOLT WITH MULTI-POINT SOCKET HEAD Genuine Bentley Part - New (to order)
                                                                      # 13
                                                                      MPN: N 0138326
                                                                      SEAL RING 18X22
                                                                      from £1.70
                                                                      from £1.70
                                                                      SEAL RING Genuine Porsche Part - New In stock
                                                                      SEAL RING Genuine Bentley Part - New (to order)
                                                                      SEAL Genuine Lamborghini - New In stock
                                                                      # 14
                                                                      MPN: N 91196501
                                                                      SEALING PLUG M18X1,5
                                                                      from £4.21
                                                                      from £4.21
                                                                      THREADED PLUG Genuine Porsche Part - New (to order)
                                                                      SEALING PLUG Genuine Bentley Part - New (to order)
                                                                      # 15
                                                                      MPN: 95810724330
                                                                      CONTROL VALVE
                                                                      CONTROL VALVE
                                                                      CONTROL VALVE Genuine Porsche Part - New (to order)
                                                                      # 15
                                                                      MPN: 95810724331
                                                                      CONTROL VALVE
                                                                      from £58.37
                                                                      from £58.37
                                                                      CONTROL VALVE Genuine Porsche Part - New (to order)
                                                                      # 16
                                                                      MPN: N 91056801
                                                                      O-RING 12X2
                                                                      from £2.12
                                                                      from £2.12
                                                                      O-RING Genuine Porsche Part - New (to order)
                                                                      O-RING Genuine Bentley Part - New (to order)
                                                                      # 17
                                                                      MPN: N 10196103
                                                                      Oval socket head bolt M6X18 with hex drive
                                                                      from £0.62
                                                                      from £0.62
                                                                      oval socket head bolt Genuine Porsche Part - New In stock
                                                                      OVAL SOCKET HEAD BOLT WITH HEX DRIVE Genuine Bentley Part - New (to order)
                                                                      HEXALOBULAR SOCKET M6X18 Genuine Lamborghini - New In stock
                                                                      # 18
                                                                      MPN: 95810701360
                                                                      OIL PUMP INCLUDED VACUUM PUMP M >>CDU 165 339 M >>CTB 020 586
                                                                      from £271.58
                                                                      from £271.58
                                                                      oil pump Genuine Porsche Part - New (to order)
                                                                      # 18
                                                                      MPN: 95810701361
                                                                      OIL PUMP INCLUDED VACUUM PUMP M CDU 165 340>>M CTB 020 587>>
                                                                      from £502.66
                                                                      from £502.66
                                                                      oil pump Genuine Porsche Part - New (to order)
                                                                      # 19
                                                                      -
                                                                      BUSH * SINGLE PARTS NO AVAILABLE *
                                                                      # 20
                                                                      MPN: 95810761110
                                                                      SEAL FOR OIL PUMP 23,4X3,53
                                                                      from £12.22
                                                                      from £12.22
                                                                      SEAL FOR OIL PUMP Genuine Porsche Part - New In stock
                                                                      # 21
                                                                      -
                                                                      SUCTION LINE * SINGLE PARTS NO AVAILABLE * ALTERNATIVELY, YOU CAN USE: POS.18
                                                                      # 22
                                                                      -
                                                                      SEAL RING * SINGLE PARTS NO AVAILABLE * ALTERNATIVELY, YOU CAN USE: POS.18
                                                                      # 23
                                                                      -
                                                                      OVAL-HEAD SCREW * SINGLE PARTS NO AVAILABLE * ALTERNATIVELY, YOU CAN USE: POS.18
                                                                      # 24
                                                                      MPN: N 10745301
                                                                      OVAL HEXAGON SOCKET HEAD BOLT M8X30
                                                                      from £1.19
                                                                      from £1.19
                                                                      OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                                                                      OVAL HEXAGON SOCKET HEAD BOLT Genuine Bentley Part - New (to order)
                                                                      SCREW M8X30 Genuine Lamborghini - New (to order)
                                                                      # 25
                                                                      MPN: 95810703120
                                                                      RETURN PIPE
                                                                      from £37.92
                                                                      from £37.92
                                                                      RETURN PIPE Genuine Porsche Part - New (to order)
                                                                      # 26
                                                                      MPN: N 10745101
                                                                      Hexagon socket flat M6X20 head bolt
                                                                      from £0.95
                                                                      from £0.95
                                                                      HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                                                                      HEXAGON SOCKET FLAT HEAD BOLT Genuine Bentley Part - New (to order)
                                                                      head bolt Genuine Lamborghini - New In stock
                                                                      # 27
                                                                      MPN: 95810713811
                                                                      INSERT OIL SUMP
                                                                      from £22.98
                                                                      from £22.98
                                                                      INSERT Genuine Porsche Part - New (to order)
                                                                      # 28
                                                                      MPN: N 10745101
                                                                      Hexagon socket flat M6X20 head bolt
                                                                      from £0.95
                                                                      from £0.95
                                                                      HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                                                                      HEXAGON SOCKET FLAT HEAD BOLT Genuine Bentley Part - New (to order)
                                                                      head bolt Genuine Lamborghini - New In stock
                                                                      # 29
                                                                      MPN: 95810705521
                                                                      oil sump
                                                                      OIL PAN Genuine Porsche Part - New (to order)
                                                                      # 30
                                                                      MPN: N 0160276
                                                                      SEALING PLUG M14X1,5
                                                                      SEALING PLUG M14X1,5
                                                                      from £3.11
                                                                      from £3.11
                                                                      Genuine Porsche Part (no longer available to order)
                                                                      SEALING PLUG Genuine Bentley Part - New (to order)
                                                                      SCREW M14X1.5 DIN908 Genuine Lamborghini - New (to order)
                                                                      # 30
                                                                      MPN: N 91167901
                                                                      SEALING PLUG M14X1,5
                                                                      from £2.76
                                                                      from £2.76
                                                                      Genuine Porsche Part (no longer available to order)
                                                                      SEALING PLUG Genuine Bentley Part - New (to order)
                                                                      SEALING PLUG Genuine Lamborghini - New In stock
                                                                      # 31
                                                                      MPN: N 0138157
                                                                      SEAL RING 14X20
                                                                      SEAL RING 14X20
                                                                      from £1.70
                                                                      from £1.70
                                                                      Genuine Porsche Part (no longer available to order)
                                                                      SEAL RING Genuine Bentley Part - New (to order)
                                                                      O-RING Genuine Lamborghini - New In stock
                                                                      # 31
                                                                      MPN: N 0138494
                                                                      SEAL RING 14X20
                                                                      from £0.52
                                                                      from £0.52
                                                                      SEAL RING Genuine Porsche Part - New In stock
                                                                      SEAL RING Genuine Bentley Part - New (to order)
                                                                      WASHER Genuine Lamborghini - New In stock
                                                                      # 32
                                                                      MPN: N 10745101
                                                                      Hexagon socket flat M6X20 head bolt
                                                                      from £0.95
                                                                      from £0.95
                                                                      HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                                                                      HEXAGON SOCKET FLAT HEAD BOLT Genuine Bentley Part - New (to order)
                                                                      head bolt Genuine Lamborghini - New In stock
                                                                      # 33
                                                                      MPN: 95860616020
                                                                      OIL LEVEL SENDER
                                                                      OIL LEVEL SENDER
                                                                      OIL LEVEL SENDER Genuine Porsche Part - New (to order)
                                                                      # 33
                                                                      MPN: 95860616021
                                                                      OIL LEVEL SENDER
                                                                      from £130.45
                                                                      from £130.45
                                                                      OIL LEVEL SENDER Genuine Porsche Part - New In stock
                                                                      # 34
                                                                      MPN: 038103196B
                                                                      SEAL RING
                                                                      from £5.13
                                                                      from £5.13
                                                                      Genuine Porsche Part (no longer available to order)
                                                                      SEAL RING Genuine Bentley Part - New (to order)
                                                                      # 35
                                                                      MPN: N 10413405
                                                                      Hexagon socket flat M6X25 head bolt
                                                                      from £0.78
                                                                      from £0.78
                                                                      HEXAGON SOCKET FLAT Genuine Porsche Part - New In stock
                                                                      HEXAGON SOCKET FLAT HEAD BOLT Genuine Bentley Part - New (to order)
                                                                      HEXALOB.SOCKET PAN HEAD SCREW Genuine Lamborghini - New (to order)
                                                                      # 36
                                                                      MPN: 95810737620
                                                                      NON-RETURN VALVE
                                                                      from £11.24
                                                                      from £11.24
                                                                      CHECK VALVE Genuine Porsche Part - New (to order)
                                                                      # 37
                                                                      -
                                                                      VACUUM LINE SEE ILLUSTRATION, ITEM: 108-030,28
                                                                      # 38
                                                                      MPN: 00004330039
                                                                      SEALANT 50ML 1 TUBE
                                                                      Supersession
                                                                      Supersession
                                                                      Genuine Porsche Part (no longer available to order)
