porsche 2017 (macan) valve cover parts diagram

103-015 - valve cover

Porsche 2017 (Macan) Valve cover Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                            #
                            Part number
                            Description
                            Key
                            Price
                            # 1
                            MPN: 94610513539
                            VALVE COVER CYLINDERS 1-3 ALSO USE: 5X 999 073 905 31 2X 999 073 908 31 1X 000 043 305 33 M >>CTM 003 553 M >>CTL 002 423
                            CTMA (3.0 Litre 6 Cyliner Engine (340 Horsepower / 250 Kilowatt with Engine Code: CTMA and installed 05/2013-09/2018) | CTM (3.0 Litre 6 Cyliner Engine (340 Horsepower / 250 Kilowatt with Engine Code: CTM and installed 05/2017-09/2018) | CTLA (3.6 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: CTLA and installed 05/2013-09/2018) | CTL (3.6 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: CTL and installed 05/2017-09/2018)
                            valve cover Genuine Porsche Part - New (to order)
                            # 1
                            MPN: 94610513545
                            VALVE COVER CYLINDERS 1-3 ALSO USE: 8X 999 073 905 31 4X 999 073 908 31 1X 000 043 305 33 M CTM 003 554>>M CTL 002 424>>
                            CTMA (3.0 Litre 6 Cyliner Engine (340 Horsepower / 250 Kilowatt with Engine Code: CTMA and installed 05/2013-09/2018) | CTM (3.0 Litre 6 Cyliner Engine (340 Horsepower / 250 Kilowatt with Engine Code: CTM and installed 05/2017-09/2018) | CTLA (3.6 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: CTLA and installed 05/2013-09/2018) | CTL (3.6 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: CTL and installed 05/2017-09/2018) | DCNA (3.0 Litre 6 Cyliner Engine (360 Horsepower / 265 Kilowatt with Engine Code: DCNA and installed 05/2015-09/2018) | DCN (3.0 Litre 6 Cyliner Engine (360 Horsepower / 265 Kilowatt with Engine Code: DCN and installed 05/2016-09/2018)
                            from £401.68
                            from £401.68
                            valve cover Genuine Porsche Part - New (to order)
                            # 1
                            MPN: 94610513545
                            Valve cover cylinders 1-3 also use: 8X 999 073 905 31 4X 999 073 908 31 1X 000 043 305 33
                            DCNA (3.0 Litre 6 Cyliner Engine (360 Horsepower / 265 Kilowatt with Engine Code: DCNA and installed 05/2015-09/2018) | DCN (3.0 Litre 6 Cyliner Engine (360 Horsepower / 265 Kilowatt with Engine Code: DCN and installed 05/2016-09/2018) | DHKA (3.6 Litre 6 Cyliner Engine (440 Horsepower / 324 Kilowatt with Engine Code: DHKA and installed 05/2016-09/2018) | DHK (3.6 Litre 6 Cyliner Engine (440 Horsepower / 324 Kilowatt with Engine Code: DHK and installed 05/2016-09/2018)
                            from £401.68
                            from £401.68
                            valve cover Genuine Porsche Part - New (to order)
                            # 2
                            MPN: 94610513664
                            VALVE COVER CYLINDERS 4-6 ALSO USE: 8X 999 073 905 31 1X 999 073 908 31 1X 000 043 305 33 M >>CTM 003 553 M >>CTL 002 423
                            CTMA (3.0 Litre 6 Cyliner Engine (340 Horsepower / 250 Kilowatt with Engine Code: CTMA and installed 05/2013-09/2018) | CTM (3.0 Litre 6 Cyliner Engine (340 Horsepower / 250 Kilowatt with Engine Code: CTM and installed 05/2017-09/2018) | CTLA (3.6 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: CTLA and installed 05/2013-09/2018) | CTL (3.6 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: CTL and installed 05/2017-09/2018)
                            valve cover Genuine Porsche Part - New (to order)
                            # 2
                            MPN: 94610513665
                            VALVE COVER CYLINDERS 4-6 ALSO USE: 9X 999 073 905 31 3X 999 073 908 31 1X 000 043 305 33 M CTM 003 554>>M CTL 002 424>>
                            CTMA (3.0 Litre 6 Cyliner Engine (340 Horsepower / 250 Kilowatt with Engine Code: CTMA and installed 05/2013-09/2018) | CTM (3.0 Litre 6 Cyliner Engine (340 Horsepower / 250 Kilowatt with Engine Code: CTM and installed 05/2017-09/2018) | CTLA (3.6 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: CTLA and installed 05/2013-09/2018) | CTL (3.6 Litre 6 Cyliner Engine (399 Horsepower / 294 Kilowatt with Engine Code: CTL and installed 05/2017-09/2018) | DCNA (3.0 Litre 6 Cyliner Engine (360 Horsepower / 265 Kilowatt with Engine Code: DCNA and installed 05/2015-09/2018) | DCN (3.0 Litre 6 Cyliner Engine (360 Horsepower / 265 Kilowatt with Engine Code: DCN and installed 05/2016-09/2018)
                            Supersession
                            Supersession
                            Genuine Porsche Part (no longer available to order)
                            # 2
                            MPN: 94610513666
                            VALVE COVER CYLINDERS 4-6 ALSO USE: 9X 999 073 905 31 3X 999 073 908 31 1X 000 043 305 33 D - MJ 2017>>
                            from £374.83
                            from £374.83
                            This part replaces part number 94610513665
                            valve cover Genuine Porsche Part - New (to order)
                            # 3
                            MPN: 94610593560
                            SEAL CYLINDERS 1-3 ALSO USE: 8x 999 073 905 31 4x 999 073 908 31 3x 946 105 937 65 1x 000 043 305 33
                            SEAL CYLINDERS 1-3 ALSO USE: 8x 999 073 905 31 4x 999 073 908 31 3x 946 105 937 65 1x 000 043 305 33
                            GASKET Genuine Porsche Part - New (to order)
                            # 3
                            MPN: 94610593565
                            SEAL CYLINDERS 1-3 ALSO USE: 8x 999 073 905 31 4x 999 073 908 31 3x 946 105 937 65 1x 000 043 305 33
                            from £30.38
                            from £30.38
                            GASKET Genuine Porsche Part - New (to order)
                            # 4
                            MPN: 94610593660
                            SEAL CYLINDERS 4-6 ALSO USE: 9x 999 073 905 31 3x 999 073 908 31 3x 946 105 937 65 1x 000 043 305 33
                            SEAL CYLINDERS 4-6 ALSO USE: 9x 999 073 905 31 3x 999 073 908 31 3x 946 105 937 65 1x 000 043 305 33
                            GASKET Genuine Porsche Part - New (to order)
                            # 4
                            MPN: 94610593665
                            SEAL CYLINDERS 4-6 ALSO USE: 9x 999 073 905 31 3x 999 073 908 31 3x 946 105 937 65 1x 000 043 305 33
                            from £30.38
                            from £30.38
                            GASKET Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 94610593760
                            SEAL INNER CYLINDERS 1-3 ALSO USE: 8x 999 073 905 31 4x 999 073 908 31 1x 946 105 935 65 1x 000 043 305 33
                            SEAL INNER CYLINDERS 1-3 ALSO USE: 8x 999 073 905 31 4x 999 073 908 31 1x 946 105 935 65 1x 000 043 305 33
                            GASKET Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 94610593760
                            SEAL INNER CYLINDERS 4-6 ALSO USE: 9x 999 073 905 31 3x 999 073 908 31 1x 946 105 936 65 1x 000 043 305 33
                            SEAL INNER CYLINDERS 4-6 ALSO USE: 9x 999 073 905 31 3x 999 073 908 31 1x 946 105 936 65 1x 000 043 305 33
                            GASKET Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 94610593765
                            SEAL INNER CYLINDERS 1-3 ALSO USE: 8x 999 073 905 31 4x 999 073 908 31 1x 946 105 935 65 1x 000 043 305 33
                            from £28.88
                            from £28.88
                            GASKET Genuine Porsche Part - New In stock
                            # 5
                            MPN: 94610593765
                            SEAL INNER CYLINDERS 4-6 ALSO USE: 9x 999 073 905 31 3x 999 073 908 31 1x 946 105 936 65 1x 000 043 305 33
                            from £28.88
                            from £28.88
                            GASKET Genuine Porsche Part - New In stock
                            # 6
                            MPN: 95810448510
                            END CAP
                            from £15.02
                            from £15.02
                            SEALING CAP Genuine Porsche Part - New (to order)
                            # 7
                            MPN: 99916705690
                            BALL PIN D15M6X12
                            from £10.59
                            from £10.59
                            BALLPIN Genuine Porsche Part - New (to order)
                            # 8
                            MPN: 99916705590
                            BALL PIN D10M6X32,4
                            from £10.59
                            from £10.59
                            BALLPIN Genuine Porsche Part - New (to order)
                            # 9
                            MPN: 99970767741
                            O-RING 22,5X2,5N
                            from £11.39
                            from £11.39
                            O-RING Genuine Porsche Part - New (to order)
                            # 10
                            MPN: 99970767740
                            O-RING 22,5X2,5N
                            from £11.39
                            from £11.39
                            O-RING Genuine Porsche Part - New In stock
                            # 11
                            MPN: 99907358101
                            FLAT ROUND HEAD BOLT M6X36-PA M >>CTM 003 553 M >>CTL 002 423
                            from £1.60
                            from £1.60
                            SCREW, ROUND HD Genuine Porsche Part - New In stock
                            # 12
                            MPN: 99907358201
                            FLAT ROUND HEAD BOLT M8X44-PA M >>CTM 003 553 M >>CTL 002 423
                            from £2.66
                            from £2.66
                            SCREW, ROUND HD Genuine Porsche Part - New (to order)
                            # 13
                            MPN: 99907390531
                            FILLISTER HD. BOLT M6X30PA ALUMINIUM M >>CTM 003 553 M >>CTL 002 423
                            from £1.41
                            from £1.41
                            FILLISTER HD. SCREW Genuine Porsche Part - New In stock
                            # 13
                            MPN: 99907390531
                            FILLISTER HD. BOLT M6X30PA ALUMINIUM M CTM 003 554>>M CTL 002 424>>
                            from £1.41
                            from £1.41
                            FILLISTER HD. SCREW Genuine Porsche Part - New In stock
                            # 13
                            MPN: 99907390531
                            FILLISTER HD. BOLT M6X30PA ALUMINIUM
                            DCNA (3.0 Litre 6 Cyliner Engine (360 Horsepower / 265 Kilowatt with Engine Code: DCNA and installed 05/2015-09/2018) | DCN (3.0 Litre 6 Cyliner Engine (360 Horsepower / 265 Kilowatt with Engine Code: DCN and installed 05/2016-09/2018) | DHKA (3.6 Litre 6 Cyliner Engine (440 Horsepower / 324 Kilowatt with Engine Code: DHKA and installed 05/2016-09/2018) | DHK (3.6 Litre 6 Cyliner Engine (440 Horsepower / 324 Kilowatt with Engine Code: DHK and installed 05/2016-09/2018)
                            from £1.41
                            from £1.41
                            FILLISTER HD. SCREW Genuine Porsche Part - New In stock
                            # 14
                            MPN: 99907390831
                            FILLISTER HD. BOLT M8X35PA ALUMINIUM M >>CTM 003 553 M >>CTL 002 423
                            from £1.45
                            from £1.45
                            FILLISTER HD. SCREW Genuine Porsche Part - New In stock
                            # 14
                            MPN: 99907390831
                            FILLISTER HD. BOLT M8X35PA ALUMINIUM M CTM 003 554>>M CTL 002 424>>
                            from £1.45
                            from £1.45
                            FILLISTER HD. SCREW Genuine Porsche Part - New In stock
                            # 14
                            MPN: 99907390831
                            FILLISTER HD. BOLT M8X35PA ALUMINIUM
                            DCNA (3.0 Litre 6 Cyliner Engine (360 Horsepower / 265 Kilowatt with Engine Code: DCNA and installed 05/2015-09/2018) | DCN (3.0 Litre 6 Cyliner Engine (360 Horsepower / 265 Kilowatt with Engine Code: DCN and installed 05/2016-09/2018) | DHKA (3.6 Litre 6 Cyliner Engine (440 Horsepower / 324 Kilowatt with Engine Code: DHKA and installed 05/2016-09/2018) | DHK (3.6 Litre 6 Cyliner Engine (440 Horsepower / 324 Kilowatt with Engine Code: DHK and installed 05/2016-09/2018)
                            from £1.45
                            from £1.45
                            FILLISTER HD. SCREW Genuine Porsche Part - New In stock
                            # 15
                            MPN: 94810430521
                            TRANSPORTATION SHACKLE
                            from £15.57
                            from £15.57
                            TRANSPORTATION SHACKLE Genuine Porsche Part - New (to order)
                            # 16
                            MPN: 94610430600
                            TRANSPORTATION SHACKLE
                            from £12.04
                            from £12.04
                            TRANSPORTATION SHACKLE Genuine Porsche Part - New (to order)
                            # 17
                            MPN: 90038504201
                            TORX SCREW BM8X35
                            Supersession
                            Supersession
                            Genuine Porsche Part (no longer available to order)
                            # 18
                            MPN: 99311053001
                            GROMMET TEMPERATURE SENSOR
                            Supersession
                            Supersession
                            Genuine Porsche Part (no longer available to order)
                            # 19
                            MPN: 99760621300
                            TEMPERATURE SENSOR ENGINE BAY
                            Supersession
                            Supersession
                            Genuine Porsche Part (no longer available to order)
                            # 20
                            MPN: 00004330533
                            sealant 75ML 1 tube for Valve cover Cylinder head Cover for timing chain
                            from £47.01
                            from £47.01
                            SEALANT Genuine Porsche Part - New (to order)
