CDUD (3.0 Litre 6 Cyliner Engine (245 Horsepower / 180 Kilowatt with Engine Code: CDUD and installed 05/2013-09/2018) | CTBA (3.0 Litre 6 Cyliner Engine (258 Horsepower / 190 Kilowatt with Engine Code: CTBA and installed 05/2013-09/2018) | CTBB (3.0 Litre 6 Cyliner Engine (211 Horsepower / 155 Kilowatt with Engine Code: CTBB and installed 05/2013-09/2018) | CTBC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CTBC and installed 05/2013-09/2018)
porsche 2018 (macan) cylinder head parts diagram

103-005 - CYLINDER HEAD

Porsche 2018 (Macan) Cylinder head Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                            #
                            Part number
                            Description
                            Key
                            Price
                            # 1
                            MPN: 95810401621
                            COMPLETE CYLINDER HEAD CYLINDERS 4-6
                            COMPLETE CYLINDER HEAD CYLINDERS 4-6
                            CYLINDER HEAD, COMPLETE Genuine Porsche Part - New (to order)
                            # 1
                            MPN: 95810401622
                            COMPLETE CYLINDER HEAD CYLINDERS 4-6
                            COMPLETE CYLINDER HEAD CYLINDERS 4-6
                            CYLINDER HEAD, COMPLETE Genuine Porsche Part - New (to order)
                            # 1
                            MPN: 95810401624
                            COMPLETE CYLINDER HEAD CYLINDERS 4-6
                            from £3,968.14
                            from £3,968.14
                            CYLINDER HEAD, COMPLETE Genuine Porsche Part - New (to order)
                            # 2
                            MPN: 95810401521
                            COMPLETE CYLINDER HEAD CYLINDERS 1-3
                            COMPLETE CYLINDER HEAD CYLINDERS 1-3
                            CYLINDER HEAD, COMPLETE Genuine Porsche Part - New (to order)
                            # 2
                            MPN: 95810401522
                            COMPLETE CYLINDER HEAD CYLINDERS 1-3
                            COMPLETE CYLINDER HEAD CYLINDERS 1-3
                            CYLINDER HEAD, COMPLETE Genuine Porsche Part - New (to order)
                            # 2
                            MPN: 95810401524
                            COMPLETE CYLINDER HEAD CYLINDERS 1-3
                            from £4,081.55
                            from £4,081.55
                            CYLINDER HEAD, COMPLETE Genuine Porsche Part - New (to order)
                            # 3
                            MPN: 95810442910
                            DOWEL SLEEVE 8X9
                            from £1.74
                            from £1.74
                            SLEEVE Genuine Porsche Part - New (to order)
                            # 4
                            MPN: N 0444087
                            THREADED PIN M8X25
                            from £1.80
                            from £1.80
                            STUD Genuine Porsche Part - New (to order)
                            # 5
                            MPN: N 10283304
                            SEALING PLUG M8X1 D >>- 02.11.2016
                            from £1.23
                            from £1.23
                            THREADED PLUG Genuine Porsche Part - New (to order)
                            # 6
                            MPN: 95810495900
                            BEARING COVER CYLINDERS 4-6
                            from £90.17
                            from £90.17
                            BEARING CAP Genuine Porsche Part - New (to order)
                            # 7
                            MPN: 95810496000
                            BEARING COVER CYLINDERS 1-3
                            from £90.17
                            from £90.17
                            BEARING CAP Genuine Porsche Part - New (to order)
                            # 8
                            MPN: N 10616501
                            OVAL HEXAGON SOCKET HEAD BOLT M6X56
                            from £1.06
                            from £1.06
                            OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                            # 9
                            MPN: 95810456400
                            BALL HEAD M5X6 CYLINDERS 1-3
                            from £7.19
                            from £7.19
                            BALL JOINT Genuine Porsche Part - New (to order)
                            # 10
                            MPN: 95810456410
                            BALL HEAD M6X12 CYLINDERS 1-3
                            from £14.41
                            from £14.41
                            BALL JOINT Genuine Porsche Part - New (to order)
                            # 11
                            MPN: 95810456400
                            BALL HEAD M5X6 CYLINDERS 4-6
                            from £7.19
                            from £7.19
                            BALL JOINT Genuine Porsche Part - New (to order)
                            # 12
                            MPN: 95810417411
                            CYLINDER HEAD GASKET 1,58MM 1 HOLE
                            from £72.34
                            from £72.34
                            CYLINDER HEAD GASKET Genuine Porsche Part - New (to order)
                            # 12
                            MPN: 95810417421
                            CYLINDER HEAD GASKET 1,63MM 2 HOLES
                            from £72.34
                            from £72.34
                            CYLINDER HEAD GASKET Genuine Porsche Part - New (to order)
                            # 12
                            MPN: 95810417431
                            CYLINDER HEAD GASKET 1,68MM 3 HOLES
                            from £72.34
                            from £72.34
                            CYLINDER HEAD GASKET Genuine Porsche Part - New (to order)
                            # 13
                            MPN: 95810417311
                            CYLINDER HEAD GASKET 1,58MM 1 HOLE
                            from £72.34
                            from £72.34
                            CYLINDER HEAD GASKET Genuine Porsche Part - New (to order)
                            # 13
                            MPN: 95810417321
                            CYLINDER HEAD GASKET 1,63MM 2 HOLES
                            from £72.34
                            from £72.34
                            CYLINDER HEAD GASKET Genuine Porsche Part - New (to order)
                            # 13
                            MPN: 95810417331
                            CYLINDER HEAD GASKET 1,68MM 3 HOLES
                            from £72.34
                            from £72.34
                            CYLINDER HEAD GASKET Genuine Porsche Part - New (to order)
                            # 14
                            MPN: WHT005262A
                            CYLINDER SCREW WITH M12X1,5X177 WASHER
                            from £7.32
                            from £7.32
                            BOLT WITH Genuine Porsche Part - New (to order)
                            # 15
                            MPN: 00004330039
                            SEALANT 50ML 1 TUBE
                            Supersession
                            Supersession
                            Genuine Porsche Part (no longer available to order)
