CDUD (3.0 Litre 6 Cyliner Engine (245 Horsepower / 180 Kilowatt with Engine Code: CDUD and installed 05/2013-09/2018) | CTBA (3.0 Litre 6 Cyliner Engine (258 Horsepower / 190 Kilowatt with Engine Code: CTBA and installed 05/2013-09/2018) | CTBB (3.0 Litre 6 Cyliner Engine (211 Horsepower / 155 Kilowatt with Engine Code: CTBB and installed 05/2013-09/2018) | CTBC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CTBC and installed 05/2013-09/2018)
porsche 2018 (macan) valve cover parts diagram

103-020 - valve cover

Porsche 2018 (Macan) Valve cover Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                        #
                        Part number
                        Description
                        Key
                        Price
                        # 1
                        MPN: 95810513511
                        VALVE COVER CYLINDERS 4-6
                        from £214.89
                        from £214.89
                        valve cover Genuine Porsche Part - New (to order)
                        # 2
                        MPN: 95810513611
                        VALVE COVER CYLINDERS 1-3
                        from £214.89
                        from £214.89
                        valve cover Genuine Porsche Part - New (to order)
                        # 3
                        MPN: 95810523110
                        SEAL CYLINDERS 4-6
                        from £65.73
                        from £65.73
                        GASKET Genuine Porsche Part - New (to order)
                        # 4
                        MPN: 95810523210
                        SEAL CYLINDERS 1-3
                        from £65.73
                        from £65.73
                        GASKET Genuine Porsche Part - New (to order)
                        # 5
                        MPN: 95810534300
                        SECURING ELEMENT
                        SECURING ELEMENT
                        ATTACHMENT ELEMENT Genuine Porsche Part - New (to order)
                        # 5
                        MPN: 95810534301
                        SECURING ELEMENT
                        from £8.75
                        from £8.75
                        ATTACHMENT ELEMENT Genuine Porsche Part - New (to order)
                        # 6
                        MPN: 95810534311
                        SECURING ELEMENT
                        SECURING ELEMENT
                        ATTACHMENT ELEMENT Genuine Porsche Part - New (to order)
                        # 6
                        MPN: 95810534310
                        SECURING ELEMENT
                        from £8.46
                        from £8.46
                        ATTACHMENT ELEMENT Genuine Porsche Part - New (to order)
                        # 7
                        MPN: 95810558500
                        SHAFT OIL SEAL 37X13
                        from £11.26
                        from £11.26
                        SEAL Genuine Porsche Part - New (to order)
                        # 8
                        MPN: 95810563100
                        GROMMET
                        from £4.52
                        from £4.52
                        GROMMET Genuine Porsche Part - New (to order)
                        # 9
                        MPN: 95810728700
                        SEAL RING
                        from £10.14
                        from £10.14
                        SEAL RING Genuine Porsche Part - New (to order)
                        # 10
                        MPN: 95810448510
                        END CAP
                        from £15.02
                        from £15.02
                        SEALING CAP Genuine Porsche Part - New (to order)
                        # 11
                        MPN: 95810453600
                        SEAL
                        from £7.07
                        from £7.07
                        GASKET Genuine Porsche Part - New (to order)
                        # 12
                        MPN: 95860610601
                        IMPULSE SENDER
                        from £78.74
                        from £78.74
                        IMPULSE SENDER Genuine Porsche Part - New (to order)
                        # 13
                        MPN: N 10405604
                        OVAL HEXAGON SOCKET HEAD BOLT M6X14
                        from £0.72
                        from £0.72
                        OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                        HEXALOBULAR SOCKET M6X14 Genuine Lamborghini - New In stock
