porsche 2018 (macan) camshaft, valves parts diagram

103-050 - CAMSHAFT, VALVES

Porsche 2018 (Macan) camshaft, valves Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                            #
                            Part number
                            Description
                            Key
                            Price
                            # 1
                            MPN: 95810504200
                            CAMSHAFT OUTLET CYLINDERS 1-3
                            CDUD (3.0 Litre 6 Cyliner Engine (245 Horsepower / 180 Kilowatt with Engine Code: CDUD and installed 05/2013-09/2018)
                            from £327.45
                            from £327.45
                            camshaft Genuine Porsche Part - New (to order)
                            # 1
                            MPN: 95810504210
                            CAMSHAFT OUTLET CYLINDERS 1-3
                            CTBA (3.0 Litre 6 Cyliner Engine (258 Horsepower / 190 Kilowatt with Engine Code: CTBA and installed 05/2013-09/2018) | CTBB (3.0 Litre 6 Cyliner Engine (211 Horsepower / 155 Kilowatt with Engine Code: CTBB and installed 05/2013-09/2018) | CTBC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CTBC and installed 05/2013-09/2018)
                            from £227.04
                            from £227.04
                            camshaft Genuine Porsche Part - New (to order)
                            # 2
                            MPN: 95810504111
                            CAMSHAFT INLET CYLINDERS 1-3
                            CAMSHAFT INLET CYLINDERS 1-3
                            camshaft Genuine Porsche Part - New (to order)
                            # 2
                            MPN: 95810504112
                            CAMSHAFT INLET CYLINDERS 1-3
                            CDUD (3.0 Litre 6 Cyliner Engine (245 Horsepower / 180 Kilowatt with Engine Code: CDUD and installed 05/2013-09/2018) | CTBA (3.0 Litre 6 Cyliner Engine (258 Horsepower / 190 Kilowatt with Engine Code: CTBA and installed 05/2013-09/2018) | CTBB (3.0 Litre 6 Cyliner Engine (211 Horsepower / 155 Kilowatt with Engine Code: CTBB and installed 05/2013-09/2018) | CTBC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CTBC and installed 05/2013-09/2018)
                            from £600.63
                            from £600.63
                            camshaft Genuine Porsche Part - New (to order)
                            # 3
                            MPN: 95810504401
                            CAMSHAFT INLET CYLINDERS 4-6
                            CDUD (3.0 Litre 6 Cyliner Engine (245 Horsepower / 180 Kilowatt with Engine Code: CDUD and installed 05/2013-09/2018) | CTBA (3.0 Litre 6 Cyliner Engine (258 Horsepower / 190 Kilowatt with Engine Code: CTBA and installed 05/2013-09/2018) | CTBB (3.0 Litre 6 Cyliner Engine (211 Horsepower / 155 Kilowatt with Engine Code: CTBB and installed 05/2013-09/2018) | CTBC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CTBC and installed 05/2013-09/2018)
                            camshaft Genuine Porsche Part - New (to order)
                            # 4
                            MPN: 95810504310
                            CAMSHAFT OUTLET CYLINDERS 4-6
                            CDUD (3.0 Litre 6 Cyliner Engine (245 Horsepower / 180 Kilowatt with Engine Code: CDUD and installed 05/2013-09/2018)
                            from £600.63
                            from £600.63
                            camshaft Genuine Porsche Part - New (to order)
                            # 4
                            MPN: 95810504320
                            CAMSHAFT OUTLET CYLINDERS 4-6
                            CTBA (3.0 Litre 6 Cyliner Engine (258 Horsepower / 190 Kilowatt with Engine Code: CTBA and installed 05/2013-09/2018) | CTBB (3.0 Litre 6 Cyliner Engine (211 Horsepower / 155 Kilowatt with Engine Code: CTBB and installed 05/2013-09/2018) | CTBC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CTBC and installed 05/2013-09/2018)
                            from £410.55
                            from £410.55
                            camshaft Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 95510560120
                            INLET VALVE
                            from £39.24
                            from £39.24
                            INTAKE VALVE Genuine Porsche Part - New (to order)
                            # 6
                            MPN: 95810532230
                            EXHAUST VALVE
                            from £39.53
                            from £39.53
                            EXHAUST VALVE Genuine Porsche Part - New (to order)
                            # 7
                            MPN: 95810542310
                            EQUALIZING ELEMENT, HYDRAULIC
                            from £10.49
                            from £10.49
                            Differential Case Genuine Porsche Part - New (to order)
                            # 8
                            MPN: 95510541720
                            CAM LEVER
                            from £14.38
                            from £14.38
                            PULL LEVER Genuine Porsche Part - New (to order)
                            # 9
                            MPN: 95510565120
                            COTTER, SPLIT
                            from £3.30
                            from £3.30
                            COTTER, SPLIT Genuine Porsche Part - New (to order)
                            # 10
                            MPN: 95510564110
                            SPRING DISC UPPER
                            from £8.99
                            from £8.99
                            SPRING SEAT Genuine Porsche Part - New (to order)
                            # 11
                            MPN: 95510511910
                            VALVE SPRING
                            from £8.01
                            from £8.01
                            VALVE SPRING Genuine Porsche Part - New (to order)
                            # 12
                            MPN: 95510511510
                            Valve stem seal Inlet 6MM also use: 955 105 501 00
                            Valve stem seal Inlet 6MM also use: 955 105 501 00
                            from £9.78
                            from £9.78
                            VALVE GUIDE SEAL Genuine Porsche Part - New (to order)
                            # 12
                            MPN: 95810511520
                            VALVE STEM SEAL OUTLET 6MM ALSO USE: 955 105 501 00
                            from £9.78
                            from £9.78
                            VALVE GUIDE SEAL Genuine Porsche Part - New (to order)
                            # 12
                            MPN: 95510550100
                            SLEEVE 6X20 FOR REPAIR PART VALVE STEM SEAL
                            from £1.82
                            from £1.82
                            SLEEVE Genuine Porsche Part - New (to order)
                            # 13
                            MPN: 95810513001
                            COVER CYLINDERS 1-3 ALSO USE: 1X 000 043 300 39
                            from £48.76
                            from £48.76
                            COVER Genuine Porsche Part - New (to order)
                            # 14
                            MPN: 95810559202
                            SEAL ALSO USE: 1X 000 043 300 39
                            from £12.22
                            from £12.22
                            GASKET Genuine Porsche Part - New (to order)
                            # 15
                            MPN: 95810512901
                            COVER CYLINDERS 4-6 ALSO USE: 1X 000 043 300 39
                            from £52.02
                            from £52.02
                            COVER Genuine Porsche Part - New (to order)
                            # 16
                            MPN: 95810559111
                            SEAL ALSO USE: 1X 000 043 300 39
                            from £12.22
                            from £12.22
                            GASKET Genuine Porsche Part - New (to order)
                            # 17
                            MPN: N 10582103
                            OVAL HEAD COUNTERSUNK BOLT M6X40 WITH MULTI-POINT SOCKET HEAD
                            from £0.99
                            from £0.99
                            SCREW, COUNTERSUNK WITH POLYGON Genuine Porsche Part - New (to order)
                            HEXALOBULAR SOCKET Genuine Lamborghini - New In stock
                            # 18
                            MPN: N 10124306
                            Hexagon socket flat M6X20 head bolt
                            from £0.87
                            from £0.87
                            This part replaces part number 99907334401 - and 1 more. Click to view details
                            OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New In stock
                            HEXALOBULAR SOCKET M6 X 20 Genuine Lamborghini - New In stock
                            # 19
                            MPN: 00004330039
                            SEALANT 50ml 1 TUBE
                            SEALANT 50ml 1 TUBE
                            Supersession
                            Supersession
                            Genuine Porsche Part (no longer available to order)
                            # 19
                            MPN: 00004330510
                            SEALANT 50ml 1 TUBE
                            from £27.36
                            from £27.36
                            This part replaces part number 00004330039 - and 1 more. Click to view details
                            SEALANT Genuine Porsche Part - New (to order)
