porsche 2018 (macan) water box parts diagram

813-090 - water box

Porsche 2018 (Macan) water box Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 1
              MPN: 8K0260753B
              ADAPTER
              from £2.99
              from £2.99
              ADAPTER Genuine Porsche Part - New (to order)
              # 2
              MPN: 95B819979
              RAIN CHANNEL LHD
              PL0L (Left-hand drive version)
              RAIN CHANNEL Genuine Porsche Part - New (to order)
              # 2
              MPN: 95B819979A
              RAIN CHANNEL RHD
              PL0R (Right-hand drive version)
              RAIN CHANNEL Genuine Porsche Part - New (to order)
              # 3
              MPN: N 90132605
              HEX. NUT WITH WASHER M6
              from £1.10
              from £1.10
              HEX. NUT WITH WASHER Genuine Porsche Part - New (to order)
              # 4
              MPN: 8K1819904A
              INTAKE MANIFOLD LHD WATER BOX
              PL0L (Left-hand drive version)
              from £14.51
              from £14.51
              INTAKE MANIFOLD Genuine Porsche Part - New (to order)
              # 4
              MPN: 8K2819904A
              INTAKE MANIFOLD RHD WATER BOX
              PL0R (Right-hand drive version)
              from £13.97
              from £13.97
              INTAKE MANIFOLD Genuine Porsche Part - New (to order)
              # 5
              MPN: N 90132605
              HEX. NUT WITH WASHER M6
              from £1.10
              from £1.10
              HEX. NUT WITH WASHER Genuine Porsche Part - New (to order)
              # 6
              MPN: 8K1819408A
              FOLIAGE GRILLE LHD
              PL0L (Left-hand drive version)
              from £5.33
              from £5.33
              LEAF GRILLE Genuine Porsche Part - New (to order)
              # 6
              MPN: 8K2819408A
              FOLIAGE GRILLE RHD
              PL0R (Right-hand drive version)
              from £5.33
              from £5.33
              LEAF GRILLE Genuine Porsche Part - New (to order)
              # 7
              MPN: 8K0260753C
              INTERMEDIATE PIECE
              from £2.99
              from £2.99
              INTERMEDIATE PIECE Genuine Porsche Part - New (to order)
              # 8
              MPN: 8K0819699A
              DOUBLE GROMMET HEAT EXCHANGER
              from £2.12
              from £2.12
              DOUBLE GROMMET Genuine Porsche Part - New (to order)
              DOUBLE GROMMET Genuine Lamborghini - New (to order)
              DOUBLE GROMMET Genuine Lamborghini - Used In stock
              # 9
              MPN: 8KD819441A
              FOLIAGE GRILLE INCLUDED CARRIER
              PB1P (Component set for China)
              from £22.80
              from £22.80
              LEAF GRILLE Genuine Porsche Part - New (to order)
              # 10
              MPN: 95B971824B
              CABLE GUIDE
              PDU0 (6-cylinder turbo engine 3.0 l/250 kW) | PDU1 (6-cylinder turbo engine 3.6 l/294 kW)
              from £2.93
              from £2.93
              WIRING CONDUIT Genuine Porsche Part - New (to order)
              # 10
              MPN: 95B971824C
              CABLE GUIDE
              PDM0 (4-cylinder TFSI engine 2.0 l/174 kW) | PD43 (6-cylinder diesel engine 3.0 l/180 kW TDI) | PDD7 (6-cylinder diesel engine 3.0 l/190 kW TDI) | PD1V (6-cylinder diesel engine 3.0/155 kW TDI) | PD51 (6-Zylinder-Dieselmotor 3,0 L/184 KW TDI)
              from £2.93
              from £2.93
              WIRING CONDUIT Genuine Porsche Part - New (to order)
              # 11
              MPN: 95857265900
              AIR QUALITY SENSOR
              from £98.42
              from £98.42
              SENSOR FOR AIR QUALITY Genuine Porsche Part - New (to order)
