PTV8 (6-cylinder SI engine 2.9 l unit 06M.A) with GP2
porsche 2020 (macan) piston parts diagram

102-305 - PISTON

Porsche 2020 (Macan) piston Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
        #
        Part number
        Description
        Key
        Price
        # 1
        MPN: PAB107066
        PISTON COMPLETE CYLINDERS 1-3 MARKED WITH: 06M 100 G ALSO USE: 3X N 012 278 1
        from £300.08
        from £300.08
        PISTON Genuine Porsche Part - New (to order)
        # 1
        MPN: PAB107065A
        PISTON COMPLETE CYLINDERS 4-6 MARKED WITH: 06M 099 G ALSO USE: 3X N 012 278 1
        from £300.08
        from £300.08
        PISTON Genuine Porsche Part - New (to order)
        # 2
        -
        1 SET: PISTON RINGS * SINGLE PARTS NO AVAILABLE *
        # 3
        MPN: N 0122781
        SNAP RING 22X1,5
        from £0.63
        from £0.63
        circlip - F. ST C 22 Genuine Porsche Part - New (to order)
        CIRCLIP Genuine Lamborghini - New (to order)
