PT2B (4-cylinder SI engine 2.0 l unit 06N.B 888evo4) with GP2
porsche 2020 (macan) coolant cooling system cooler for coolant parts diagram

105-225 - Coolant cooling system Cooler for coolant

Porsche 2020 (Macan) Coolant cooling system Cooler for coolant Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                    #
                    Part number
                    Description
                    Key
                    Price
                    # 1
                    MPN: 9A712125110
                    COOLER FOR COOLANT
                    from £357.06
                    from £357.06
                    RADIATOR Genuine Porsche Part - New (to order)
                    # 2
                    MPN: 8K0121276A
                    RUBBER BUSH LOWER
                    from £1.51
                    from £1.51
                    RUBBER ISOLATOR Genuine Porsche Part - New (to order)
                    # 3
                    MPN: 95B121093
                    BRACKET
                    from £4.67
                    from £4.67
                    BRACKET Genuine Porsche Part - New (to order)
                    # 4
                    MPN: 4H0121268A
                    RUBBER BUSH LOWER
                    from £9.57
                    from £9.57
                    RUBBER ISOLATOR Genuine Porsche Part - New (to order)
                    # 5
                    MPN: N 90817003
                    HEXAGON SOCKET HEAD PANEL BOLT TP6X17
                    from £0.50
                    from £0.50
                    HEXAGON SOCKET HEAD PANEL BOLT Genuine Porsche Part - New In stock
                    SCREW TP6X17-Q Genuine Lamborghini - New In stock
                    # 6
                    MPN: 8K0121275C
                    RUBBER BUSH
                    from £2.97
                    from £2.97
                    RUBBER ISOLATOR Genuine Porsche Part - New (to order)
                    # 7
                    MPN: N 90967502
                    HEXAGON SOCKET HEAD PANEL BOLT 7X16
                    from £0.65
                    from £0.65
                    HEXAGON SOCKET HEAD PANEL BOLT Genuine Porsche Part - New (to order)
                    # 8
                    MPN: 95B121003E
                    RADIATOR FAN WITH FAN RING
                    from £855.30
                    from £855.30
                    This part replaces part number 95B121003A
                    RADIATOR FAN WITH FAN RING Genuine Porsche Part - New (to order)
                    # 9
                    MPN: WHT001506A
                    SECURING PIN 19X46.2
                    from £0.65
                    from £0.65
                    ATTACHMENT BOLT Genuine Porsche Part - New (to order)
