P7CE (Emission standard LEV 3/Tier 3 70) | P7CP (Emission standard EU6 AG/H/I) | P7GH (Emission standard EU4 without EOBD without hardware modification) | P7MM (Emission standard EU6 plus) with D1C, PD29 (6-cylinder SI engine 2.9 l/324 kW biturbo, FSI, homogeneous base engine is TV8)
porsche 2020 (macan) catalytic converter lambda probe parts diagram

202-255 - Catalytic converter Lambda probe

Porsche 2020 (Macan) Catalytic converter Lambda probe Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                  #
                                  Part number
                                  Description
                                  Key
                                  Price
                                  # 1
                                  MPN: 95B254300D
                                  EXHAUST PIPE WITH CATALYST LEFT
                                  P7CE (Emission standard LEV 3/Tier 3 70) | P7GH (Emission standard EU4 without EOBD without hardware modification) | P7MM (Emission standard EU6 plus)
                                  from £2,009.24
                                  from £2,009.24
                                  EXHAUST PIPE WITH CATALYST Genuine Porsche Part - New (to order)
                                  # 1
                                  MPN: 95B254300DX
                                  EXHAUST PIPE WITH CATALYST LEFT
                                  P7CE (Emission standard LEV 3/Tier 3 70) | P7GH (Emission standard EU4 without EOBD without hardware modification) | P7MM (Emission standard EU6 plus)
                                  from £2,009.24
                                  from £2,009.24
                                  EXHAUST PIPE WITH CATALYST Genuine Porsche Part - New (to order)
                                  # 2
                                  MPN: 95B254350D
                                  EXHAUST PIPE WITH CATALYST RIGHT
                                  P7CE (Emission standard LEV 3/Tier 3 70) | P7GH (Emission standard EU4 without EOBD without hardware modification) | P7MM (Emission standard EU6 plus)
                                  from £2,009.24
                                  from £2,009.24
                                  EXHAUST PIPE WITH CATALYST Genuine Porsche Part - New (to order)
                                  # 2
                                  MPN: 95B254350DX
                                  EXHAUST PIPE WITH CATALYST RIGHT
                                  P7CE (Emission standard LEV 3/Tier 3 70) | P7GH (Emission standard EU4 without EOBD without hardware modification) | P7MM (Emission standard EU6 plus)
                                  from £2,009.24
                                  from £2,009.24
                                  EXHAUST PIPE WITH CATALYST Genuine Porsche Part - New (to order)
                                  # 3
                                  MPN: 95B253725
                                  CLAMP
                                  CLAMP
                                  from £32.82
                                  from £32.82
                                  CLAMP Genuine Porsche Part - New (to order)
                                  # 3
                                  MPN: PAE253725A
                                  CLAMP
                                  from £38.34
                                  from £38.34
                                  CLAMP Genuine Porsche Part - New (to order)
                                  # 4
                                  MPN: 971253115B
                                  SEAL
                                  from £46.10
                                  from £46.10
                                  This part replaces part number 9A725311501
                                  GASKET Genuine Porsche Part - New (to order)
                                  # 5
                                  MPN: 95B253230A
                                  BRACKET LEFT
                                  from £22.05
                                  from £22.05
                                  BRACKET Genuine Porsche Part - New (to order)
                                  # 6
                                  MPN: 95B253230
                                  BRACKET RIGHT
                                  from £22.05
                                  from £22.05
                                  BRACKET Genuine Porsche Part - New (to order)
                                  # 7
                                  MPN: N 10049308
                                  HEXAGON HEAD BOLT (COMBI) M8X20
                                  from £1.08
                                  from £1.08
                                  BOLT HEX HD (COMBI) Genuine Porsche Part - New (to order)
                                  HEXAGON HEAD BOLT M8 X 20 - S1 Genuine Lamborghini - New In stock
                                  # 8
                                  MPN: 95511111310
                                  SEAL
                                  from £10.08
                                  from £10.08
                                  GASKET Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: N 90894602
                                  HEXAGON NUT, SELF-LOCKING M8-B-
                                  from £0.78
                                  from £0.78
                                  HEX. NUT, SELF-LOCKING Genuine Porsche Part - New (to order)
                                  # 10
                                  MPN: 95B253300P
                                  EXHAUST PIPE
                                  from £426.89
                                  from £426.89
                                  EXHAUST PIPE Genuine Porsche Part - New (to order)
                                  # 11
                                  MPN: 95B253350P
                                  EXHAUST PIPE
                                  from £426.89
                                  from £426.89
                                  EXHAUST PIPE Genuine Porsche Part - New (to order)
                                  # 12
                                  MPN: 95B906265F
                                  LAMBDA PROBE LEFT
                                  from £158.91
                                  from £158.91
                                  OXYGEN SENSOR Genuine Porsche Part - New (to order)
                                  # 13
                                  MPN: 8E0201449R
                                  CABLE HOLDER
                                  from £2.47
                                  from £2.47
                                  This part replaces part number 99950707540
                                  CABLE HOLDER Genuine Porsche Part - New (to order)
                                  # 14
                                  MPN: N 90681301
                                  BRACKET FOR CORRUGATED PIPE
                                  from £0.65
                                  from £0.65
                                  CLIP Genuine Porsche Part - New (to order)
                                  CORRUGATED TUBE A4.5 Genuine Lamborghini - New (to order)
                                  # 15
                                  MPN: 95B906265E
                                  LAMBDA PROBE RIGHT
                                  from £158.91
                                  from £158.91
                                  OXYGEN SENSOR Genuine Porsche Part - New (to order)
                                  # 16
                                  MPN: 8E0201449R
                                  CABLE HOLDER
                                  from £2.47
                                  from £2.47
                                  This part replaces part number 99950707540
                                  CABLE HOLDER Genuine Porsche Part - New (to order)
                                  # 17
                                  MPN: PAF908549
                                  HOSE BRACKET
                                  from £1.16
                                  from £1.16
                                  BRACKET FOR HOSE Genuine Porsche Part - New (to order)
                                  # 18
                                  MPN: 95860683810
                                  CABLE TIES
                                  from £2.67
                                  from £2.67
                                  TIE WRAP Genuine Porsche Part - New (to order)
                                  # 19
                                  MPN: 95811122010
                                  CLAMPING SLEEVE 65X88MM
                                  Supersession
                                  Supersession
                                  Genuine Porsche Part (no longer available to order)
