PL0L (Left-hand drive) | PL0R (Right-hand drive) with, PGP1 (Vehicles with special upgrade measures )
porsche 2020 (macan) oil pump wire set parts diagram

302-110 - oil pump Wire set

Porsche 2020 (Macan) oil pump Wire set Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                          #
                                                          Part number
                                                          Description
                                                          Key
                                                          Price
                                                          # 1
                                                          MPN: 9A731510501
                                                          OIL PUMP GEARBOX
                                                          from £649.74
                                                          from £649.74
                                                          oil pump Genuine Porsche Part - New (to order)
                                                          # 2
                                                          MPN: 0B5315100
                                                          oil pipe with: seal ring
                                                          from £25.18
                                                          from £25.18
                                                          OIL PIPE Genuine Porsche Part - New (to order)
                                                          # 3
                                                          MPN: 0B5315105TA
                                                          oil pipe with: seal ring
                                                          from £18.37
                                                          from £18.37
                                                          OIL PIPE Genuine Porsche Part - New (to order)
                                                          # 4
                                                          MPN: N 91076601
                                                          SOCKET HEAD BOLT WITH INNER M8X30 MULTIPOINT HEAD
                                                          from £1.78
                                                          from £1.78
                                                          BOLT, WITH POLYGON SOCKET HD. Genuine Porsche Part - New (to order)
                                                          12-POINT SOCKET Genuine Lamborghini - New (to order)
                                                          # 5
                                                          MPN: 9A730151500
                                                          SUCTION JET PUMP GEARBOX
                                                          from £98.66
                                                          from £98.66
                                                          SUCTION PUMP Genuine Porsche Part - New (to order)
                                                          # 6
                                                          MPN: 9A700474100
                                                          O-RING 71,5X1,5
                                                          O-RING 71,5X1,5
                                                          from £19.69
                                                          from £19.69
                                                          O-RING Genuine Porsche Part - New (to order)
                                                          # 6
                                                          MPN: PAF004741
                                                          O-RING 71,5X1,5
                                                          from £20.10
                                                          from £20.10
                                                          O-RING Genuine Porsche Part - New (to order)
                                                          # 7
                                                          MPN: N 10637302
                                                          OVAL HEXAGON SOCKET HEAD BOLT M5X20
                                                          from £0.66
                                                          from £0.66
                                                          OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                                                          HEXALOBULAR SOCKETM5X20 Genuine Lamborghini - New In stock
                                                          # 8
                                                          MPN: 9A730122700
                                                          RADIAL SHAFT SEAL
                                                          from £18.53
                                                          from £18.53
                                                          RADIAL SHAFT SEAL Genuine Porsche Part - New (to order)
                                                          # 9
                                                          MPN: N 91196301
                                                          HEX SOCKET HEAD LOCATING BOLT M6X8X25
                                                          from £1.33
                                                          from £1.33
                                                          HEX SOCKET HEAD LOCATING BOLT Genuine Porsche Part - New (to order)
                                                          # 10
                                                          MPN: 9A792732100
                                                          SPEED SENSOR ALSO USE: 1X 9A7 321 391 00
                                                          from £246.43
                                                          from £246.43
                                                          SPEED SENSOR Genuine Porsche Part - New (to order)
                                                          # 11
                                                          MPN: 9A792740700
                                                          LOCK RING
                                                          from £24.98
                                                          from £24.98
                                                          RING Genuine Porsche Part - New (to order)
                                                          # 12
                                                          MPN: 9A792737700
                                                          SEAL
                                                          from £23.07
                                                          from £23.07
                                                          GASKET Genuine Porsche Part - New (to order)
                                                          # 13
                                                          MPN: 9A730131100
                                                          OIL DRIP TRAY
                                                          from £35.28
                                                          from £35.28
                                                          OIL DRIP TRAY Genuine Porsche Part - New (to order)
                                                          # 14
                                                          MPN: 9A730127900
                                                          OIL DRIP TRAY
                                                          from £9.23
                                                          from £9.23
                                                          OIL DRIP TRAY Genuine Porsche Part - New (to order)
                                                          # 15
                                                          MPN: 9A700245900
                                                          TORX SCREW M8X40
                                                          from £1.26
                                                          from £1.26
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 16
                                                          MPN: 9A730113400
                                                          OIL GUIDE
                                                          from £3.87
                                                          from £3.87
                                                          OIL GUIDE Genuine Porsche Part - New (to order)
                                                          # 17
                                                          MPN: 9A700767400
                                                          BANJO BOLT M26X1,5X29
                                                          from £9.23
                                                          from £9.23
                                                          BANJO BOLT Genuine Porsche Part - New (to order)
                                                          # 18
                                                          MPN: 9A731152500
                                                          NEEDLE BEARING -
                                                          from £15.04
                                                          from £15.04
                                                          NEEDLE BEARING - Genuine Porsche Part - New (to order)
                                                          # 19
                                                          MPN: 9A732139100
                                                          WIRE SET
                                                          from £51.29
                                                          from £51.29
                                                          harness Genuine Porsche Part - New (to order)
                                                          # 20
                                                          MPN: 9A731194400
                                                          RADIAL SHAFT SEAL 26X16X6
                                                          RADIAL SHAFT SEAL 26X16X6
                                                          RADIAL SHAFT SEAL Genuine Porsche Part - New (to order)
                                                          # 20
                                                          MPN: 9A731194401
                                                          RADIAL SHAFT SEAL 26X16X6
                                                          RADIAL SHAFT SEAL 26X16X6
                                                          from £17.09
                                                          from £17.09
                                                          RADIAL SHAFT SEAL Genuine Porsche Part - New (to order)
                                                          # 20
                                                          MPN: 9A7311944
                                                          SHAFT OIL SEAL 26X16X6
                                                          from £26.88
                                                          from £26.88
                                                          SHAFT OIL SEAL Genuine Porsche Part - New (to order)
                                                          # 21
                                                          MPN: 9A730114300
                                                          MAGNET
                                                          from £9.26
                                                          from £9.26
                                                          MAGNET Genuine Porsche Part - New (to order)
                                                          # 22
                                                          MPN: 9A732119100
                                                          SHIFT ROD ALSO USE: 1X 9A7 321 222 00
                                                          from £36.77
                                                          from £36.77
                                                          SHIFT ROD Genuine Porsche Part - New (to order)
                                                          # 23
                                                          MPN: 9A732122200
                                                          SHIFT ROD
                                                          from £16.80
                                                          from £16.80
                                                          SHIFT ROD Genuine Porsche Part - New (to order)
                                                          # 24
                                                          MPN: 00004330033
                                                          SEALANT 100G DREI BOND 1110
                                                          from £43.79
                                                          from £43.79
                                                          SEALANT Genuine Porsche Part - New (to order)
                                                          # 24
                                                          MPN: 00004321045
                                                          CLEANING SOLUTION 100ML TEROSTAT 450
                                                          from £28.47
                                                          from £28.47
                                                          CLEANING SOLUTION Genuine Porsche Part - New (to order)
                                                          # 25
                                                          MPN: 9A731119000
                                                          RADIAL SHAFT SEAL 45,5X60X8
                                                          from £20.75
                                                          from £20.75
                                                          RADIAL SHAFT SEAL Genuine Porsche Part - New (to order)
                                                          # 26
                                                          MPN: 9A731118900
                                                          RADIAL SHAFT SEAL 29X37,5X6
                                                          from £15.87
                                                          from £15.87
                                                          RADIAL SHAFT SEAL Genuine Porsche Part - New (to order)
                                                          # 27
                                                          MPN: 0FD301212B
                                                          TRANSMISSION HOUSING COVER
                                                          from £112.02
                                                          from £112.02
                                                          COVER FOR TRANSMISSION CASE Genuine Porsche Part - New (to order)
                                                          # 28
                                                          MPN: 9A700207900
                                                          TORX SCREW M8X43
                                                          from £1.63
                                                          from £1.63
                                                          Torx screw - M 8 X 48 - D - MJ 2003>> Genuine Porsche Part - New (to order)
                                                          # 29
                                                          MPN: 9A700195800
                                                          TORX SCREW M8X55
                                                          from £1.53
                                                          from £1.53
                                                          TORX SCREW Genuine Porsche Part - New (to order)
                                                          # 30
                                                          MPN: 9A700195500
                                                          HEXAGON BOLT
                                                          from £17.31
                                                          from £17.31
                                                          SCREW, HEX. HD Genuine Porsche Part - New (to order)
