porsche 2020 (macan) refrigerant circuit r1234yf coolant parts diagram

814-600 - refrigerant circuit R1234yf coolant

Porsche 2020 (Macan) refrigerant circuit R1234yf coolant Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                          #
                                          Part number
                                          Description
                                          Key
                                          Price
                                          # 1
                                          MPN: 9A726071200
                                          REFRIGERANT LINE WITH: GROMMET
                                          from £152.94
                                          from £152.94
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 1
                                          MPN: 9A726071210
                                          REFRIGERANT LINE WITH: GROMMET
                                          from £152.94
                                          from £152.94
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 2
                                          MPN: 95B816743M
                                          Refrigerant line suction line
                                          PT2B (4-cylinder SI engine 2.0 l unit 06N.B 888evo4)
                                          from £213.94
                                          from £213.94
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 2
                                          MPN: 95B816743D
                                          Refrigerant line suction line Compressor
                                          PTV8 (6-cylinder SI engine 2.9 l unit 06M.A)
                                          from £204.17
                                          from £204.17
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 3
                                          MPN: 95B816720H
                                          REFRIGERANT LINE
                                          PT2B (4-cylinder SI engine 2.0 l unit 06N.B 888evo4)
                                          from £157.26
                                          from £157.26
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 3
                                          MPN: 95B816720D
                                          REFRIGERANT LINE
                                          PTV8 (6-cylinder SI engine 2.9 l unit 06M.A)
                                          from £144.68
                                          from £144.68
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 4
                                          MPN: 95B816741D
                                          REFRIGERANT LINE PRESSURE LINE
                                          from £177.91
                                          from £177.91
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 5
                                          MPN: 95B260702H
                                          REFRIGERANT LINE
                                          PT2B (4-cylinder SI engine 2.0 l unit 06N.B 888evo4)
                                          from £87.36
                                          from £87.36
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 5
                                          MPN: 95B260702F
                                          REFRIGERANT LINE
                                          PTV8 (6-cylinder SI engine 2.9 l unit 06M.A)
                                          from £87.36
                                          from £87.36
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 6
                                          MPN: 95B260367J
                                          REFRIGERANT LINE
                                          PT2B (4-cylinder SI engine 2.0 l unit 06N.B 888evo4)
                                          from £119.60
                                          from £119.60
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 6
                                          MPN: 95B260367G
                                          REFRIGERANT LINE
                                          PTV8 (6-cylinder SI engine 2.9 l unit 06M.A)
                                          from £119.60
                                          from £119.60
                                          REFRIGERANT LINE Genuine Porsche Part - New (to order)
                                          # 7
                                          MPN: 9A781657900
                                          BRACKET
                                          from £3.41
                                          from £3.41
                                          BRACKET Genuine Porsche Part - New (to order)
                                          # 8
                                          MPN: 8R0260759
                                          BRACKET FOR REFRIGERANT PIPE
                                          from £3.38
                                          from £3.38
                                          BRACKET FOR REFRIGERANT PIPE Genuine Porsche Part - New (to order)
                                          # 9
                                          MPN: 9P1819827
                                          BRACKET
                                          from £6.70
                                          from £6.70
                                          BRACKET Genuine Porsche Part - New (to order)
                                          # 10
                                          MPN: N 90903502
                                          SOCKET HEAD BOLT WITH INNER M8X35 MULTIPOINT HEAD
                                          from £1.84
                                          from £1.84
                                          BOLT, WITH POLYGON SOCKET HD. Genuine Porsche Part - New (to order)
                                          # 11
                                          MPN: N 10347204
                                          HEXAGON SOCKET HEAD BOLT, M6X25 SELF-LOCKING BOLT WITH WASHER
                                          from £1.10
                                          from £1.10
                                          HEXAGON SOCKET HEAD BOLT, Genuine Porsche Part - New (to order)
                                          HEXALOBULAR SOCKETM6X25-S11-N Genuine Lamborghini - New (to order)
                                          # 12
                                          MPN: N 10414402
                                          Socket head bolt with M8X28 hexagon socket head
                                          from £1.62
                                          from £1.62
                                          BOLT, WITH HEX. SOCKET Genuine Porsche Part - New (to order)
                                          HEXALOBULAR SOCKETM8X28-S10-N Genuine Lamborghini - New In stock
                                          # 13
                                          MPN: PAF015082
                                          HEXAGON COLLAR NUT M6
                                          from £1.58
                                          from £1.58
                                          This part replaces part number N 01508210
                                          shouldered hex. nut Genuine Porsche Part - New In stock
                                          # 14
                                          MPN: 95557374901
                                          O-RING 11,00X2,50
                                          from £4.53
                                          from £4.53
                                          O-RING Genuine Porsche Part - New (to order)
                                          # 15
                                          MPN: 95557374902
                                          O-RING 18,70X2,50
                                          from £4.32
                                          from £4.32
                                          O-RING Genuine Porsche Part - New (to order)
                                          # 16
                                          MPN: 95557374900
                                          O-RING 9,50X2,50
                                          from £4.34
                                          from £4.34
                                          O-RING Genuine Porsche Part - New In stock
                                          # 17
                                          MPN: 99970743941
                                          O-RING 23,80X2,40N*
                                          from £6.45
                                          from £6.45
                                          O-RING - 23,80X2,40 Genuine Porsche Part - New (to order)
                                          # 18
                                          MPN: 9A7004858
                                          O-RING 13,94X2,62
                                          from £5.68
                                          from £5.68
                                          O-RING Genuine Porsche Part - New (to order)
                                          # 19
                                          MPN: 9A781623100
                                          COVER
                                          from £6.06
                                          from £6.06
                                          COVER Genuine Porsche Part - New (to order)
                                          # 20
                                          MPN: 9A781658100
                                          COVER VALVE
                                          from £5.14
                                          from £5.14
                                          COVER Genuine Porsche Part - New (to order)
                                          # 21
                                          MPN: N 10722501
                                          DISTANCE PIECE B10,5X22,5X30
                                          from £11.77
                                          from £11.77
                                          SPACER Genuine Porsche Part - New (to order)
                                          SPINED SLEEVE B10.5X22.5X30 Genuine Lamborghini - New (to order)
                                          # 22
                                          MPN: 95B260197
                                          BRACKET FOR COOLANT LINE
                                          from £2.53
                                          from £2.53
                                          BRACKET FOR COOLANT Genuine Porsche Part - New (to order)
                                          # 23
                                          MPN: N 10442003
                                          SELF-TAPPING SCREW 5X16 FILLISTER HD. BOLT
                                          from £0.47
                                          from £0.47
                                          SCREW, THREAD CUTTING Genuine Porsche Part - New (to order)
                                          SCREW, THREAD CUTTING Genuine Lamborghini - New (to order)
                                          # 24
                                          MPN: PAB298260
                                          REPAIR KIT FOR QUICK RELEASE COUPLING
                                          from £24.42
                                          from £24.42
                                          REPAIR KIT FOR QUICK RELEASE COUPLING Genuine Porsche Part - New (to order)
