P1LN (Front disc brake - 18-inch disc diameter, brake calliper painted Black)
porsche 2025 (macan-e) disc brake front axle parts diagram

602-000 - Disc Brake Front Axle

Porsche 2025 (Macan-E) Disc brake front axle Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                              #
                              Part number
                              Description
                              Key
                              Price
                              # 1
                              MPN: PAC615301
                              BRAKE DISC LEFT ALSO USE: 1X PAC 615 302 4X PAF 104 560 2X 95C 615 269 D
                              from £184.83
                              from £184.83
                              BRAKE DISC Genuine Porsche Part - New (to order)
                              # 1
                              MPN: PAC615302
                              BRAKE DISC RIGHT ALSO USE: 1X PAC 615 301 4X PAF 104 560 2X 95C 615 269 D
                              from £184.83
                              from £184.83
                              BRAKE DISC Genuine Porsche Part - New (to order)
                              # 2
                              MPN: PAF104560
                              Hexagon socket head bolt, M6X12 self-locking
                              from £0.73
                              from £0.73
                              HEXAGON SOCKET HEAD BOLT, SELF-LOCKING Genuine Porsche Part - New (to order)
                              # 3
                              MPN: PAC615311D
                              COVER PLATE LEFT USE IF REQUIRED: 4X N 107 414 02
                              from £34.58
                              from £34.58
                              COVER PLATE Genuine Porsche Part - New (to order)
                              # 3
                              MPN: PAC615312D
                              COVER PLATE RIGHT USE IF REQUIRED: 4X N 107 414 02
                              from £34.58
                              from £34.58
                              COVER PLATE Genuine Porsche Part - New (to order)
                              # 4
                              MPN: N 10741402
                              Hexagon socket flat M6X14 head bolt
                              from £0.78
                              from £0.78
                              HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                              HEXALOBULAR SOCKETM6X14 Genuine Lamborghini - New In stock
                              # 5
                              MPN: 95C615123Q
                              CALIPER WITHOUT BRAKE PADS LEFT BLACK ANODISED ALSO USE: 2X PAF 004 571 2X 95C 615 269 D 1X 95C 698 151
                              from £402.24
                              from £402.24
                              CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                              # 5
                              MPN: 95C615124Q
                              CALIPER WITHOUT BRAKE PADS RIGHT BLACK ANODISED ALSO USE: 2X PAF 004 571 2X 95C 615 269 D 1X 95C 698 151
                              from £402.24
                              from £402.24
                              CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                              # 6
                              MPN: 95C698151
                              1 SET OF BRAKE PADS FOR DISK BRAKE ALSO USE: 4X PAF 004 571 4X 95C 615 269 D 2X 95C 907 253 J
                              from £168.64
                              from £168.64
                              1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
                              # 7
                              MPN: 95C907253J
                              SENDER WIRE (PAD WEAR INDICATOR) BRAKE LINING
                              from £27.57
                              from £27.57
                              SENDER WIRE (PAD WEAR INDICATOR) Genuine Porsche Part - New (to order)
                              # 8
                              MPN: PAF004571
                              Socket head collared bolt with M14X1,5X115 inner multipoint head Fixed calliper
                              from £7.18
                              from £7.18
                              This part replaces part number WHT004571
                              SCREW Genuine Porsche Part - New (to order)
                              # 9
                              MPN: 95C615269D
                              RETAINING SPRING CONTAINS: 1 PC
                              from £10.54
                              from £10.54
                              RETAINING SPRING Genuine Porsche Part - New (to order)
                              # 10
                              -
                              CONNECTING LINE NO REPLACEMENT PART INCLUDED IN POSITION: 5
                              # 11
                              MPN: 95C698471
                              1 SET PROTECTIVE CAPS CONTAINS: 4 PCS
                              from £11.39
                              from £11.39
                              1 set protective caps Genuine Porsche Part - New (to order)
                              # 12
                              MPN: 211611483
                              DUST CAP CONTAINS: 20 PC
                              from £3.60
                              from £3.60
                              dust cap - D >> - MJ 1983 Genuine Porsche Part - New (to order)
                              DUST CAP Genuine Lamborghini - New (to order)
                              # 13
                              MPN: 8A0615273
                              1 SET BLEEDER VALVES WITH FRONT DUST CAP WITH COVER CAP FIXED CALLIPER
                              from £9.05
                              from £9.05
                              BLEEDER VALVE Genuine Porsche Part - New (to order)
                              BLEEDER SCREW Genuine Lamborghini - New (to order)
                              # 14
                              MPN: 00004330508
                              ASSEMBLY PASTE 100 GRAM
                              from £17.99
                              from £17.99
                              This part replaces part number 00004302000
                              ASSEMBLY PASTE Genuine Porsche Part - New (to order)
