PQ1G (Standard seats in front)
porsche 2025 (macan-e) electrics standard seat parts diagram

817-500 - Electrics Standard seat

Porsche 2025 (Macan-E) Electrics Standard seat Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    MPN: 95C971363CQ
    WIRE SET LEFT MODIFY IN WORKSHOP
    PL0L (Left-hand drive) | PQ1G (Standard seats in front) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P6C2 (Side airbag in front with curtain airbag and interaction airbag in front) | P6C4 (Side airbag in front and rear, with curtain airbag and interaction airbag in front) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £116.00
    from £116.00
    WIRE SET Genuine Porsche Part - New (to order)
    # 1
    MPN: 95C971363CS
    WIRE SET LEFT MODIFY IN WORKSHOP
    PL0R (Right-hand drive) | PQ1G (Standard seats in front) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P9P9 (Seat belt reminder, electric contact in buckle, advanced safety equipment) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £116.00
    from £116.00
    WIRE SET Genuine Porsche Part - New (to order)
    # 1
    MPN: 95C971363DA
    WIRE SET LEFT MODIFY IN WORKSHOP
    PL0R (Right-hand drive) | PQ1G (Standard seats in front) | P1I0 (Passenger presence detection) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled)
    from £116.00
    from £116.00
    WIRE SET Genuine Porsche Part - New (to order)
    # 2
    MPN: 95C971364CR
    WIRE SET RIGHT MODIFY IN WORKSHOP
    PL0L (Left-hand drive) | PQ1G (Standard seats in front) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P9P9 (Seat belt reminder, electric contact in buckle, advanced safety equipment) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £116.00
    from £116.00
    WIRE SET Genuine Porsche Part - New (to order)
    # 2
    MPN: 95C971364CP
    WIRE SET RIGHT MODIFY IN WORKSHOP
    PL0L (Left-hand drive) | PQ1G (Standard seats in front) | P1I0 (Passenger presence detection) | P9P7 (Visual and acoustic seat belt reminder, electric contact in buckle) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled)
    from £116.00
    from £116.00
    WIRE SET Genuine Porsche Part - New (to order)
    # 2
    MPN: 95C971364DA
    WIRE SET RIGHT MODIFY IN WORKSHOP
    PL0R (Right-hand drive) | PQ1G (Standard seats in front) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P6C2 (Side airbag in front with curtain airbag and interaction airbag in front) | P6C4 (Side airbag in front and rear, with curtain airbag and interaction airbag in front) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £116.00
    from £116.00
    WIRE SET Genuine Porsche Part - New (to order)
    # 3
    MPN: 95C971385A
    WIRE SET LEFT MODIFY IN WORKSHOP
    PL0L (Left-hand drive) | PQ1G (Standard seats in front) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P6C2 (Side airbag in front with curtain airbag and interaction airbag in front) | P6C4 (Side airbag in front and rear, with curtain airbag and interaction airbag in front) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £52.89
    from £52.89
    WIRE SET Genuine Porsche Part - New (to order)
    # 3
    MPN: 95C971385C
    WIRE SET LEFT MODIFY IN WORKSHOP
    PL0R (Right-hand drive) | PQ1G (Standard seats in front) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £52.89
    from £52.89
    WIRE SET Genuine Porsche Part - New (to order)
    # 4
    MPN: 95C971384A
    WIRE SET RIGHT MODIFY IN WORKSHOP
    PL0L (Left-hand drive) | PQ1G (Standard seats in front) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £52.89
    from £52.89
    WIRE SET Genuine Porsche Part - New (to order)
    # 4
    MPN: 95C971384C
    WIRE SET RIGHT MODIFY IN WORKSHOP
    PL0R (Right-hand drive) | PQ1G (Standard seats in front) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P6C2 (Side airbag in front with curtain airbag and interaction airbag in front) | P6C4 (Side airbag in front and rear, with curtain airbag and interaction airbag in front) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £57.99
    from £57.99
    WIRE SET Genuine Porsche Part - New (to order)
    # 5
    MPN: 971959747BB1E0
    SWITCH MODULE FOR SEAT LEFT SEAT ADJUSTER - BLACK
    PL0L (Left-hand drive) | PQ1G (Standard seats in front) | P3L5 (Both front seats power-adjustable ) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £218.30
    from £218.30
    SWITCH MODULE FOR SEAT BLACK Genuine Porsche Part - New (to order)
    # 5
    MPN: 971959747BA1E0
    SWITCH MODULE FOR SEAT LEFT SEAT ADJUSTER - BLACK
    PL0R (Right-hand drive) | PQ1G (Standard seats in front) | P3L5 (Both front seats power-adjustable ) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £218.30
    from £218.30
    SWITCH MODULE FOR SEAT BLACK Genuine Porsche Part - New (to order)
    # 6
    MPN: 971959748BA1E0
    SWITCH MODULE FOR SEAT RIGHT SEAT ADJUSTER - BLACK
    PL0L (Left-hand drive) | PQ1G (Standard seats in front) | P3L5 (Both front seats power-adjustable ) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £218.30
    from £218.30
    SWITCH MODULE FOR SEAT BLACK Genuine Porsche Part - New (to order)
    # 6
    MPN: 971959748BB1E0
    SWITCH MODULE FOR SEAT RIGHT SEAT ADJUSTER - BLACK
    PL0R (Right-hand drive) | PQ1G (Standard seats in front) | P3L5 (Both front seats power-adjustable ) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £218.30
    from £218.30
    SWITCH MODULE FOR SEAT BLACK Genuine Porsche Part - New (to order)
    # 7
    MPN: PAF106339
    HEXAGON SOCKET HEAD PANEL BOLT 4,2X9,5
    from £0.47
    from £0.47
    HEXAGON SOCKET HEAD PANEL BOLT Genuine Porsche Part - New (to order)
    # 8
    MPN: PAD959760E
    CONTROL UNIT FOR SEAT
    PL0L (Left-hand drive) | PL0R (Right-hand drive) | PAI1 (Memory feature on driver side (for Audi/SEAT only))
    from £425.05
    from £425.05
    CONTROL UNIT FOR SEAT Genuine Porsche Part - New (to order)
    # 9
    MPN: 992963553B
    SEAT OCCUPIED SENSOR
    PQ1G (Standard seats in front) | 9P9
    from £55.49
    from £55.49
    SEAT OCCUPIED SENSOR Genuine Porsche Part - New (to order)
    # 9
    MPN: 992963553B
    SEAT OCCUPIED SENSOR
    PL0L (Left-hand drive) | Q1G, 1I0, 9P7
    from £55.49
    from £55.49
    SEAT OCCUPIED SENSOR Genuine Porsche Part - New (to order)
    # 9
    MPN: 992963553B
    SEAT OCCUPIED SENSOR
    PL0R (Right-hand drive) | Q1G, 1I0
    from £55.49
    from £55.49
    SEAT OCCUPIED SENSOR Genuine Porsche Part - New (to order)
