CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) | CWFA (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWFA and installed 05/2013-05/2014) | CWF (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWF and installed 05/2013-05/2016) | CGEA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGEA and installed 05/2011-05/2016) | CGE (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGE and installed 05/2011-05/2016) | CGFA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGFA and installed 05/2011-05/2016) | CRCB (3.0 Litre 6 Cyliner Engine (210 Horsepower / 155 Kilowatt with Engine Code: CRCB and installed 05/2011-05/2016) | CRCC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CRCC and installed 05/2011-05/2016) | CWJA (3.0 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWJA and installed 05/2013-05/2015) CWJA (3.0 Litre 6 Cyliner Engine (300 Horsepower / 221 Kilowatt with Engine Code: CWJA and installed 05/2015-05/2016)
porsche 2010 (panamera 970) disc brake rear axle d - mj 2014>> parts diagram

603-012 - Disc brake Rear axle D - MJ 2014>>

Porsche 2010 (Panamera 970) Disc brake Rear axle D - MJ 2014>> Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: 298615601A
                BRAKE DISC LEFT REAR ALSO USE: 1X 298 615 602 A 1X 970 352 949 05
                P without 450
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 1
                MPN: 298615602A
                BRAKE DISC RIGHT REAR ALSO USE: 1X 298 615 601 A 1X 970 352 949 05
                P without 450
                from £182.61
                from £182.61
                BRAKE DISC Genuine Porsche Part - New (to order)
                # 1
                MPN: 298615601
                Brake disc left rear also use: 1x 298 615 602 1x 991 352 948 03
                Brake disc left rear also use: 1x 298 615 602 1x 991 352 948 03
                BRAKE DISC Genuine Porsche Part - New (to order)
                # 1
                MPN: 298615601C
                BRAKE DISC LEFT REAR ALSO USE: 1X 298 615 602 C 1X 991 352 948 03
                P450 (Ceramic brake (PCCB))
                BRAKE DISC Genuine Porsche Part - New (to order)
                # 1
                MPN: 298615602
                Brake disc right rear also use: 1x 298 615 601 1x 991 352 948 03
                Brake disc right rear also use: 1x 298 615 601 1x 991 352 948 03
                BRAKE DISC Genuine Porsche Part - New (to order)
                # 1
                MPN: 298615602C
                BRAKE DISC RIGHT REAR ALSO USE: 1X 298 615 601 C 1X 991 352 948 03
                P450 (Ceramic brake (PCCB))
                BRAKE DISC Genuine Porsche Part - New (to order)
                # 2
                MPN: 90026904703
                countersunk bolt M6X12
                countersunk bolt M6X12
                from £0.50
                from £0.50
                SCREW, COUNTERSUNK HD Genuine Porsche Part - New (to order)
                # 2
                MPN: N 10456004
                Hexagon socket head bolt, M6X12 self-locking
                from £0.47
                from £0.47
                HEXAGON SOCKET HEAD BOLT, Genuine Porsche Part - New (to order)
                # 3
                MPN: 97035280101
                COVER PLATE LEFT
                P without 450
                from £23.75
                from £23.75
                COVER PLATE Genuine Porsche Part - New (to order)
                # 3
                MPN: 97035280201
                COVER PLATE RIGHT
                P without 450
                from £23.75
                from £23.75
                COVER PLATE Genuine Porsche Part - New (to order)
                # 3
                MPN: 97035280533
                COVER PLATE LEFT
                P450 (Ceramic brake (PCCB))
                from £141.42
                from £141.42
                COVER PLATE Genuine Porsche Part - New (to order)
                # 3
                MPN: 97035280633
                COVER PLATE RIGHT
                P450 (Ceramic brake (PCCB))
                from £141.42
                from £141.42
                COVER PLATE Genuine Porsche Part - New (to order)
                # 4
                MPN: 99921711601
                HEXAGON BOLT M 6 X 16
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 5
                MPN: 00004311036
                REPAIR SET FOR REAR AXLE FIXED CALLIPER BLACK COMPRISING: FIXED CALLIPER 1X LEFT FIXED CALLIPER 1X RIGHT F >>97-EL000 322
                CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) | CWFA (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWFA and installed 05/2013-05/2014) | CWF (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWF and installed 05/2013-05/2016) | CRCB (3.0 Litre 6 Cyliner Engine (210 Horsepower / 155 Kilowatt with Engine Code: CRCB and installed 05/2011-05/2016) | CRCC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CRCC and installed 05/2011-05/2016) | CWJA (3.0 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWJA and installed 05/2013-05/2015) CWJA (3.0 Litre 6 Cyliner Engine (300 Horsepower / 221 Kilowatt with Engine Code: CWJA and installed 05/2015-05/2016) with, P without 450
                from £534.86
                from £534.86
                REPAIR SET FOR Genuine Porsche Part - New (to order)
                # 5
                MPN: 298615149
                FIXED CALLIPER LEFT BLACK F 97-EL000 323>>
                CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) | CWFA (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWFA and installed 05/2013-05/2014) | CWF (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWF and installed 05/2013-05/2016) | CRCB (3.0 Litre 6 Cyliner Engine (210 Horsepower / 155 Kilowatt with Engine Code: CRCB and installed 05/2011-05/2016) | CRCC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CRCC and installed 05/2011-05/2016) | CWJA (3.0 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWJA and installed 05/2013-05/2015) CWJA (3.0 Litre 6 Cyliner Engine (300 Horsepower / 221 Kilowatt with Engine Code: CWJA and installed 05/2015-05/2016) with, P without 450
                FIXED CALLIPER Genuine Porsche Part - New (to order)
                # 5
                MPN: 00004311038
                REPAIR SET FOR REAR AXLE FIXED CALLIPER GREEN COMPRISING: FIXED CALLIPER 1X LEFT FIXED CALLIPER 1X RIGHT
                CGEA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGEA and installed 05/2011-05/2016) | CGE (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGE and installed 05/2011-05/2016) | CGFA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGFA and installed 05/2011-05/2016) with, P without 450
                from £637.31
                from £637.31
                REPAIR SET FOR Genuine Porsche Part - New (to order)
                # 5
                MPN: 298615149C
                FIXED CALLIPER LEFT GREEN F A7-EL044 148>>
                CGEA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGEA and installed 05/2011-05/2016) | CGE (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGE and installed 05/2011-05/2016) | CGFA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGFA and installed 05/2011-05/2016)
                FIXED CALLIPER Genuine Porsche Part - New (to order)
                # 5
                MPN: 298615150
                FIXED CALLIPER RIGHT BLACK F 97-EL000 323>>
                CWAA (3.6 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWAA and installed 05/2013-05/2014) CWAA (3.6 Litre 6 Cyliner Engine (310 Horsepower / 228 Kilowatt with Engine Code: CWAA and installed 05/2014-05/2016) | CWFA (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWFA and installed 05/2013-05/2014) | CWF (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWF and installed 05/2013-05/2016) | CRCB (3.0 Litre 6 Cyliner Engine (210 Horsepower / 155 Kilowatt with Engine Code: CRCB and installed 05/2011-05/2016) | CRCC (3.0 Litre 6 Cyliner Engine (250 Horsepower / 184 Kilowatt with Engine Code: CRCC and installed 05/2011-05/2016) | CWJA (3.0 Litre 6 Cyliner Engine (299 Horsepower / 220 Kilowatt with Engine Code: CWJA and installed 05/2013-05/2015) CWJA (3.0 Litre 6 Cyliner Engine (300 Horsepower / 221 Kilowatt with Engine Code: CWJA and installed 05/2015-05/2016) with, P without 450
                FIXED CALLIPER Genuine Porsche Part - New (to order)
                # 5
                MPN: 298615150C
                FIXED CALLIPER RIGHT GREEN F A7-EL044 148>>
                CGEA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGEA and installed 05/2011-05/2016) | CGE (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGE and installed 05/2011-05/2016) | CGFA (3.0 Litre 6 Cyliner Engine (333 Horsepower / 245 Kilowatt with Engine Code: CGFA and installed 05/2011-05/2016)
                FIXED CALLIPER Genuine Porsche Part - New (to order)
                # 5
                MPN: 00004311040
                REPAIR SET FOR REAR AXLE FIXED CALLIPER YELLOW COMPRISING: FIXED CALLIPER 1X LEFT FIXED CALLIPER 1X RIGHT F >>97-EL070 482
                P450 (Ceramic brake (PCCB))
                from £682.79
                from £682.79
                REPAIR SET FOR Genuine Porsche Part - New (to order)
                # 5
                MPN: 97035242534
                CALIPER WITHOUT BRAKE PADS LEFT YELLOW F 97-EL070 483>>
                P450 (Ceramic brake (PCCB))
                CALLIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                # 5
                MPN: 97035242634
                CALIPER WITHOUT BRAKE PADS RIGHT YELLOW F 97-EL070 483>>
                P450 (Ceramic brake (PCCB))
                CALLIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                # 6
                MPN: 97035294905
                1 set of brake pads for rear disk brake comprising: Brake lining 4x also use: Fasteners
                P without 450
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 6
                MPN: 97035294908
                1 set of brake pads for rear disk brake comprising: Brake lining 4x also use: Fasteners
                P without 450
                from £152.14
                from £152.14
                This part replaces part number 97035294904 - and 1 more. Click to view details
                1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
                # 6
                MPN: 97035294703
                1 set of brake pads for rear disk brake comprising: Brake lining 4x also use: Fasteners
                1 set of brake pads for rear disk brake comprising: Brake lining 4x also use: Fasteners
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 6
                MPN: 99135294803
                1 set of brake pads for rear disk brake comprising: Brake lining 4x also use: Fasteners
                P450 (Ceramic brake (PCCB))
                from £420.58
                from £420.58
                1 SET OF BRAKE PADS FOR DISC Genuine Porsche Part - New (to order)
                # 6
                MPN: 99135294804
                1 set of brake pads for rear disk brake comprising: Brake lining 4x also use: Fasteners
                P450 (Ceramic brake (PCCB))
                from £456.06
                from £456.06
                This part replaces part number 97035294703
                1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
                # 7
                MPN: 95861236550
                SENDER WIRE (PAD WEAR INDICATOR)
                P without 450
                from £19.57
                from £19.57
                SENDER WIRE Genuine Porsche Part - New In stock
                # 7
                MPN: 97060914500
                SENDER WIRE (PAD WEAR INDICATOR)
                P450 (Ceramic brake (PCCB))
                from £25.36
                from £25.36
                SENDER WIRE Genuine Porsche Part - New (to order)
                # 8
                MPN: 99906704001
                SOCKET HEAD BOLT M 12 X 1,5 X 95
                P450 (Ceramic brake (PCCB))
                from £12.92
                from £12.92
                SCREW, CHEESE HD Genuine Porsche Part - New (to order)
                # 8
                MPN: 99906705309
                SOCKET HEAD BOLT M 12 X 1,5 X 85
                P without 450
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
                # 9
                MPN: 97035296100
                connecting line
                connecting line Genuine Porsche Part - New (to order)
                # 10
                MPN: 99635191500
                REPAIR SET 1 SET PROTECTIVE CAPS 32 MM FOR FIXED CALLIPER 1X
                from £13.98
                from £13.98
                repair kit - Protection caps - 32 MM $ - D - MJ 2004>> Genuine Porsche Part - New (to order)
                # 11
                MPN: 93035191900
                BREATHER VALVE
                from £13.16
                from £13.16
                bleeder valve - with: - dust cap Genuine Porsche Part - New (to order)
                # 13
                MPN: 97035295900
                SPRING
                from £39.59
                from £39.59
                SPRING Genuine Porsche Part - New (to order)
                # 14
                MPN: 00004311700
                BRAKE CYLINDER PASTE 1 TUBE 50 GRAM
                brake cylinder paste - Discontinued part Genuine Porsche Part - New (to order)
                # 14
                MPN: 00004302000
                ASSEMBLY PASTE 1 TUBE 100 GRAM
                Supersession
                Supersession
                Genuine Porsche Part (no longer available to order)
