porsche 2013 (panamera 970) rear axle parts diagram

501-010 - rear axle

Porsche 2013 (Panamera 970) REAR AXLE Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
      #
      Part number
      Description
      Key
      Price
      # 1
      MPN: 97033105105
      sub-frame
      D >> - MJ 2013
      sub-frame Genuine Porsche Part - New (to order)
      # 1
      MPN: 97033105121
      sub-frame
      D >> - MJ 2013 (HYBRID)
      sub-frame Genuine Porsche Part - New (to order)
      # 1
      MPN: 97033105133
      sub-frame
      D - MJ 2014>>
      sub-frame Genuine Porsche Part - New (to order)
      # 2
      MPN: 97033125702
      RUBBER ISOLATOR
      sub-frame |
      D >> - MJ 2013
      RUBBER ISOLATOR Genuine Porsche Part - New (to order)
      # 2
      MPN: 97033125704
      RUBBER ISOLATOR
      sub-frame |
      D - MJ 2014>>
      from £60.37
      from £60.37
      RUBBER ISOLATOR Genuine Porsche Part - New (to order)
      # 3
      MPN: 97033125902
      RUBBER ISOLATOR
      sub-frame |
      D >> - MJ 2013
      RUBBER ISOLATOR Genuine Porsche Part - New (to order)
      # 3
      MPN: 97033125904
      RUBBER ISOLATOR
      sub-frame |
      D - MJ 2014>>
      RUBBER ISOLATOR Genuine Porsche Part - New (to order)
      # 4
      MPN: 99907287201
      BOLT WITH WASHER
      M 12 X 1,5 X 115
      from £5.80
      from £5.80
      BOLT WITH WASHER Genuine Porsche Part - New (to order)
      # 5
      MPN: 97033118102
      cross support
      D >> - MJ 2013
      cross support Genuine Porsche Part - New (to order)
      # 5
      MPN: 97033118103
      cross support
      D - MJ 2014>>
      from £36.83
      from £36.83
      cross support Genuine Porsche Part - New (to order)
      # 6
      MPN: 99907280201
      SCREW, HEX. HD.
      M 8 X 28
      from £0.91
      from £0.91
      SCREW, HEX. HD Genuine Porsche Part - New (to order)
      # 7
      MPN: 97033302103
      DISTANCE SENSOR
      LEFT
      from £263.79
      from £263.79
      DISTANCE SENSOR Genuine Porsche Part - New (to order)
      # 7
      MPN: 97033302203
      DISTANCE SENSOR
      right |
      D >> - MJ 2013 (PR:350,351, 475)
      DISTANCE SENSOR Genuine Porsche Part - New (to order)
      # 7
      MPN: 97033302204
      DISTANCE SENSOR
      right |
      D - MJ 2014>> (PR:350,351, 475)
      from £263.79
      from £263.79
      DISTANCE SENSOR Genuine Porsche Part - New (to order)
      # 8
      MPN: 99921711601
      SCREW, HEX. HD.
      M 6 X 16
      from £0.71
      from £0.71
      SCREW, HEX. HD Genuine Porsche Part - New (to order)
      # 8
      MPN: N 90999502
      BOLT, HEX. HD. WITH SHOULDER
      screw, hex. hd. | M 6 X 16
      from £0.86
      from £0.86
      BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
      HEXAGON FLANGE M6X25 Genuine Lamborghini - New (to order)
      # 9
      MPN: 90038001501
      HEX. NUT
      M 6
      Supersession
      Supersession
      Genuine Porsche Part (no longer available to order)
      # 10
      MPN: 97050428101
      cross support
      Rear end |
      D >> - MJ 2013
      cross support Genuine Porsche Part - New (to order)
      # 10
      MPN: 97050428102
      cross support
      Rear end |
      D - MJ 2014>>
      cross support Genuine Porsche Part - New (to order)
      # 11
      MPN: 99921716901
      BOLT WITH WASHER
      BOLT WITH WASHER Genuine Porsche Part - New (to order)
      # 12
      MPN: 99991926301
      FILLISTER HD. SCREW
      from £0.82
      from £0.82
      FILLISTER HD. SCREW Genuine Porsche Part - New (to order)
