porsche 2014 (panamera 970) valve cover parts diagram

103-021 - valve cover

Porsche 2014 (Panamera 970) VALVE COVER Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
        #
        Part number
        Description
        Key
        Price
        # 1
        MPN: 94610513562
        valve cover
        cylinders 1-3 |
        also use: 5x 99907390531 | 2x 99907390831 | 1x 00004330533 | No longer use the part here
        valve cover Genuine Porsche Part - New (to order)
        # 1
        MPN: 94610513563
        valve cover
        cylinders 1-3 |
        also use: 5x 99907390531 | 2x 99907390831 | 1x 00004330533 | No longer use the part here
        valve cover Genuine Porsche Part - New (to order)
        # 1
        MPN: 94610513564
        valve cover
        cylinders 1-3 |
        also use: 5x 99907390531 | 2x 99907390831 | 1x 00004330533 |
        M >> 0 06268 |
        M >> 0 07454 ( CWDA,CWD CWFA,CWF)
        valve cover Genuine Porsche Part - New (to order)
        # 1
        MPN: 94610513565
        valve cover
        cylinders 1-3 |
        also use: 8x 99907390531 | 4x 99907390831 | 1x 00004330533 | M 0 06269 >> | M 0 07455 >> ( CWDA,CWD CWFA,CWF)
        from £383.69
        from £383.69
        valve cover Genuine Porsche Part - New (to order)
        # 2
        MPN: 94610513662
        valve cover
        cylinders 4-6 |
        also use: 8x 99907390531 | 1x 99907390831 | 1x 00004330533 | No longer use the part here
        valve cover Genuine Porsche Part - New (to order)
        # 2
        MPN: 94610513663
        valve cover
        cylinders 4-6 |
        also use: 8x 99907390531 | 1x 99907390831 | 1x 00004330533 | No longer use the part here
        valve cover Genuine Porsche Part - New (to order)
        # 2
        MPN: 94610513664
        valve cover
        cylinders 4-6 |
        also use: 8x 99907390531 | 1x 99907390831 | 1x 00004330533 |
        M >> 0 06268 |
        M >> 0 07454 ( CWDA,CWD CWFA,CWF)
        valve cover Genuine Porsche Part - New (to order)
        # 2
        MPN: 94610513665
        valve cover
        cylinders 4-6 |
        also use: 9x 99907390531 | 3x 99907390831 | 1x 00004330533 | M 0 06269 >> | M 0 07455 >> ( CWDA,CWD CWFA,CWF)
        Supersession
        Supersession
        Genuine Porsche Part (no longer available to order)
        # 3
        MPN: 94610593560
        GASKET
        cylinders 1-3 |
        also use: Xx 00004330533 | No longer use the part here
        GASKET Genuine Porsche Part - New (to order)
        # 3
        MPN: 94610593565
        GASKET
        cylinders 1-3 |
        also use: 8x 99907390531 | 4x 99907390831 | 3x 94610593765 | 1x 00004330533
        from £28.49
        from £28.49
        GASKET Genuine Porsche Part - New (to order)
        # 4
        MPN: 94610593660
        GASKET
        cylinders 4-6 |
        also use: Xx 00004330533 | No longer use the part here
        GASKET Genuine Porsche Part - New (to order)
        # 4
        MPN: 94610593665
        GASKET
        cylinders 4-6 |
        also use: 9x 99907390531 | 3x 99907390831 | 3x 94610593765 | 1x 00004330533
        from £28.49
        from £28.49
        GASKET Genuine Porsche Part - New In stock
        # 5
        MPN: 94610593760
        GASKET
        inner |
        also use: Xx 00004330533 | No longer use the part here
        GASKET Genuine Porsche Part - New (to order)
        # 5
        MPN: 94610593765
        GASKET
        inner | cylinders 1-3 |
        also use: 8x 99907390531 | 4x 99907390831 | 1x 94610593565 | 1x 00004330533
        from £28.58
        from £28.58
        GASKET Genuine Porsche Part - New (to order)
        # 5
        MPN: 94610593765
        GASKET
        inner | cylinders 4-6 |
        also use: 9x 99907390531 | 3x 99907390831 | 1x 94610593665 | 1x 00004330533
        from £28.58
        from £28.58
        GASKET Genuine Porsche Part - New (to order)
        # 6
        MPN: 95810448510
        SEALING CAP
        from £14.94
        from £14.94
        SEALING CAP Genuine Porsche Part - New (to order)
        # 7
        MPN: 99916705690
        BALLPIN
        15
        from £10.59
        from £10.59
        BALLPIN Genuine Porsche Part - New (to order)
        # 8
        MPN: 99916705590
        BALLPIN
        10
        from £10.59
        from £10.59
        BALLPIN Genuine Porsche Part - New (to order)
        # 9
        MPN: 99970767741
        O-RING
        22,5 X 2,5
        from £11.39
        from £11.39
        O-RING Genuine Porsche Part - New (to order)
        # 10
        MPN: 99970767740
        O-RING
        22,5 X 2,5
        from £11.39
        from £11.39
        O-RING Genuine Porsche Part - New (to order)
        # 11
        MPN: 99907358101
        SCREW, ROUND HD.
        M 6 X 36 |
        M >> 0 06268 |
        M >> 0 07454 ( CWDA,CWD CWFA,CWF)
        from £1.60
        from £1.60
        SCREW, ROUND HD Genuine Porsche Part - New (to order)
        # 12
        MPN: 99907358201
        SCREW, ROUND HD.
        M 8 X 44 |
        M >> 0 06268 |
        M >> 0 07454 ( CWDA,CWD CWFA,CWF)
        from £2.66
        from £2.66
        SCREW, ROUND HD Genuine Porsche Part - New (to order)
        # 13
        MPN: 99907390531
        FILLISTER HD. SCREW
        aluminium | M 6 X 30 |
        M >> 0 06268 |
        M >> 0 07454 ( CWDA,CWD CWFA,CWF)
        from £1.41
        from £1.41
        FILLISTER HD. SCREW Genuine Porsche Part - New In stock
        # 13
        MPN: 99907390531
        FILLISTER HD. SCREW
        aluminium | M 6 X 30 | M 0 06269 >> | M 0 07455 >> ( CWDA,CWD CWFA,CWF)
        from £1.41
        from £1.41
        FILLISTER HD. SCREW Genuine Porsche Part - New In stock
        # 14
        MPN: 99907390831
        FILLISTER HD. SCREW
        aluminium | M 8 X 35 |
        M >> 0 06268 |
        M >> 0 07454 ( CWDA,CWD CWFA,CWF)
        from £1.45
        from £1.45
        FILLISTER HD. SCREW Genuine Porsche Part - New In stock
        # 14
        MPN: 99907390831
        FILLISTER HD. SCREW
        aluminium | M 8 X 35 | M 0 06269 >> | M 0 07455 >> ( CWDA,CWD CWFA,CWF)
        from £1.45
        from £1.45
        FILLISTER HD. SCREW Genuine Porsche Part - New In stock
        # 15
        MPN: 94810430521
        TRANSPORTATION SHACKLE
        from £15.33
        from £15.33
        TRANSPORTATION SHACKLE Genuine Porsche Part - New (to order)
        # 16
        MPN: 94610430600
        TRANSPORTATION SHACKLE
        from £11.82
        from £11.82
        TRANSPORTATION SHACKLE Genuine Porsche Part - New (to order)
        # 17
        MPN: 90038504201
        TORX SCREW
        M 8 X 35
        Supersession
        Supersession
        Genuine Porsche Part (no longer available to order)
        # 18
        MPN: 99311053001
        GROMMET
        TEMPERATURE SENSOR
        Supersession
        Supersession
        Genuine Porsche Part (no longer available to order)
        # 19
        MPN: 99760621300
        TEMPERATURE SENSOR
        Engine bay
        Supersession
        Supersession
        Genuine Porsche Part (no longer available to order)
        # 20
        MPN: 90030205600
        DOWEL PIN
        4 X 16
        from £20.82
        from £20.82
        DOWEL PIN Genuine Porsche Part - New (to order)
        # 21
        MPN: 00004330533
        SEALANT
        1 tube | 75 ML | for | valve cover | cylinder head | Cover for timing chain
        from £45.65
        from £45.65
        SEALANT Genuine Porsche Part - New (to order)
