CWDA (3.0 Litre 6 Cyliner Engine (420 Horsepower / 309 Kilowatt with Engine Code: CWDA and installed 05/2013-05/2016) | CWD (3.0 Litre 6 Cyliner Engine (420 Horsepower / 309 Kilowatt with Engine Code: CWD and installed 05/2014-05/2016) | CWFA (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWFA and installed 05/2013-05/2014) | CWF (3.0 Litre 6 Cyliner Engine (319 Horsepower / 235 Kilowatt with Engine Code: CWF and installed 05/2013-05/2016)
porsche 2016 (panamera 970) coolant pipe for exhaust gas turbocharger parts diagram

202-096 - Coolant pipe for Exhaust gas turbocharger

Porsche 2016 (Panamera 970) Coolant pipe for Exhaust gas turbocharger Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                    #
                    Part number
                    Description
                    Key
                    Price
                    # 1
                    MPN: 94610602760
                    Coolant pipe feed Cylinders 1-3
                    from £65.04
                    from £65.04
                    water tube Genuine Porsche Part - New (to order)
                    # 2
                    MPN: 94610623561
                    Coolant pipe return Cylinders 1-3
                    from £79.37
                    from £79.37
                    water tube Genuine Porsche Part - New (to order)
                    # 3
                    MPN: 99970767040
                    O-RING 10X3N TO BE USED FOR ITEM: 6,7
                    from £4.81
                    from £4.81
                    O-RING Genuine Porsche Part - New (to order)
                    # 3
                    MPN: 99970767041
                    O-RING 10X3 TO BE USED FOR ITEM: 1,2
                    from £7.26
                    from £7.26
                    O-RING Genuine Porsche Part - New (to order)
                    # 4
                    MPN: 99951111603
                    CLAMP D110X15
                    from £4.52
                    from £4.52
                    CLAMP - SCREW, HEX. HD Genuine Porsche Part - New (to order)
                    # 5
                    -
                    COOLANT PIPE FEED SEE ILLUSTRATION, ITEM: 105-032,1
                    # 6
                    MPN: 94610623760
                    Coolant pipe feed Cylinders 4-6
                    Coolant pipe feed Cylinders 4-6
                    water tube Genuine Porsche Part - New (to order)
                    # 6
                    MPN: 94610623761
                    Coolant pipe feed Cylinders 4-6
                    Coolant pipe feed Cylinders 4-6
                    from £46.10
                    from £46.10
                    water tube Genuine Porsche Part - New (to order)
                    # 6
                    MPN: 94610623762
                    COOLANT PIPE FEED CYLINDERS 4-6 USE IF REQUIRED: 1X 946 107 087 64 1X 999 073 601 01
                    from £68.14
                    from £68.14
                    water tube Genuine Porsche Part - New (to order)
                    # 7
                    MPN: 94610623960
                    Coolant pipe return Cylinders 4-6
                    Coolant pipe return Cylinders 4-6
                    water tube Genuine Porsche Part - New (to order)
                    # 7
                    MPN: 94610623961
                    Coolant pipe return Cylinders 4-6
                    from £68.83
                    from £68.83
                    water tube Genuine Porsche Part - New (to order)
                    # 8
                    MPN: 99950707540
                    CABLE HOLDER 3,0-12,0
                    Supersession
                    Supersession
                    Genuine Porsche Part (no longer available to order)
                    # 9
                    MPN: 90038504101
                    HEXAGON HEAD BOLT BM6X12
                    Supersession
                    Supersession
                    Genuine Porsche Part (no longer available to order)
                    # 10
                    MPN: N 10544703
                    SOCKET HEAD BOLT WITH M6X10 INNER HEX ROUND HEAD
                    from £0.63
                    from £0.63
                    SOCKET HEAD BOLT WITH INNER Genuine Porsche Part - New (to order)
                    HEXALOBULAR SOCKETM6X10 Genuine Lamborghini - New In stock
                    # 11
                    MPN: 99951111603
                    CLAMP D110X15
                    from £4.52
                    from £4.52
                    CLAMP - SCREW, HEX. HD Genuine Porsche Part - New (to order)
                    # 12
                    MPN: 99907360101
                    flat round head bolt M6X14
                    flat round head bolt M6X14
                    Supersession
                    Supersession
                    Genuine Porsche Part (no longer available to order)
                    # 12
                    MPN: PAF008923
                    flat round head bolt M6X14
                    from £0.85
                    from £0.85
                    This part replaces part number 99907360101
                    SCREW, ROUND HD Genuine Porsche Part - New (to order)
