CVDA (4.0 Litre 8 Cyliner Engine (549 Horsepower / 404 Kilowatt with Engine Code: CVDA and installed 05/2016-12/2020) | CVD (4.0 Litre 8 Cyliner Engine (549 Horsepower / 404 Kilowatt with Engine Code: CVD and installed 05/2017-12/2020) with, P0K3 (Hybrid propulsion system PHEV)
porsche 2017 (panamera 971-1) gear oil cooler oil pressure line for gearbox oil cooling - pdk - gearbox parts diagram

360-020 - Gear oil cooler oil pressure line for gearbox oil cooling - PDK - Gearbox

Porsche 2017 (Panamera 971-1) Gear oil cooler oil pressure line for gearbox oil cooling - PDK - Gearbox Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: 9A731702301
                GEAR OIL COOLER
                from £393.07
                from £393.07
                GEAR OIL COOLER Genuine Porsche Part - New (to order)
                # 2
                MPN: 9A711725700
                RUBBER GROMMET
                RUBBER GROMMET
                from £0.56
                from £0.56
                RUBBER GROMMET Genuine Porsche Part - New (to order)
                # 2
                MPN: 9A711725701
                RUBBER GROMMET
                from £0.82
                from £0.82
                RUBBER GROMMET Genuine Porsche Part - New (to order)
                # 3
                MPN: N 91268401
                TUBULAR RIVET A9X1X8,5
                from £1.60
                from £1.60
                TUBULAR RIVET Genuine Porsche Part - New (to order)
                # 4
                MPN: N 91188301
                Hexagon socket head M6X20 bolt
                from £0.79
                from £0.79
                HEXAGONAL SOCKET HEAD Genuine Porsche Part - New In stock
                HEXAGON SOCKET HEAD BOLT Genuine Bentley Part - New (to order)
                HEXALOBULAR SOCKET Genuine Lamborghini - New In stock
                # 5
                MPN: 0DS317760A
                OIL PRESSURE LINE FOR GEARBOX OIL COOLING (COMPLETE)
                from £227.28
                from £227.28
                oil pressure line for Genuine Porsche Part - New (to order)
                OIL PRESSURE LINE FOR GEARBOX OIL COOLING Genuine Bentley Part - New (to order)
                # 5
                MPN: 0DS317760B
                OIL PRESSURE LINE FOR REAR GEARBOX OIL COOLING ALSO USE: 1X 0DS 317 760 C D - 25.09.2017>>
                from £227.28
                from £227.28
                oil pressure line for Genuine Porsche Part - New (to order)
                # 5
                MPN: 0DS317760C
                OIL PRESSURE LINE FOR FRONT GEARBOX OIL COOLING D - 25.09.2017>>
                from £178.82
                from £178.82
                oil pressure line for Genuine Porsche Part - New (to order)
                # 6
                MPN: 9A700819800
                O-RING 15X3,6
                from £2.08
                from £2.08
                O-RING Genuine Porsche Part - New In stock
                # 7
                MPN: N 10335206
                Hexagon socket flat M6X12 head bolt
                from £0.78
                from £0.78
                HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                HEXAGON SOCKET FLAT HEAD BOLT Genuine Bentley Part - New (to order)
                HEXALOBULAR SOCKETM6X12 Genuine Lamborghini - New In stock
                # 8
                MPN: N 10664801
                SOCKET HEAD COLLARED BOLT WITH M8X20 INNER MULTIPOINT HEAD
                from £0.96
                from £0.96
                SOCKET HD. SCREW WITH POLYGON Genuine Porsche Part - New (to order)
                SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD Genuine Bentley Part - New (to order)
                12-POINT SOCKET M8X20 Genuine Lamborghini - New In stock
