DBUC (4.0 Litre 8 Cyliner Engine (421 Horsepower / 310 Kilowatt with Engine Code: DBUC and installed 05/2016-12/2020)
porsche 2020 (panamera 971-1) camshaft, valves parts diagram

103-055 - CAMSHAFT, VALVES

Porsche 2020 (Panamera 971-1) camshaft, valves Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                    #
                                    Part number
                                    Description
                                    Key
                                    Price
                                    # 1
                                    MPN: 9A710900700
                                    CAMSHAFT INLET CYLINDERS 1-4
                                    from £4,382.60
                                    from £4,382.60
                                    camshaft Genuine Porsche Part - New (to order)
                                    # 2
                                    MPN: 9A710900800
                                    CAMSHAFT OUTLET CYLINDERS 1-4
                                    from £4,382.60
                                    from £4,382.60
                                    camshaft Genuine Porsche Part - New (to order)
                                    # 3
                                    MPN: 9A710900701
                                    CAMSHAFT INLET CYLINDER 5-8
                                    from £3,502.34
                                    from £3,502.34
                                    camshaft Genuine Porsche Part - New (to order)
                                    # 4
                                    MPN: 9A710900801
                                    CAMSHAFT OUTLET CYLINDER 5-8
                                    from £3,602.41
                                    from £3,602.41
                                    camshaft Genuine Porsche Part - New (to order)
                                    # 5
                                    MPN: 9A710917100
                                    INTERMEDIATE SHAFT
                                    from £93.24
                                    from £93.24
                                    INTERMEDIATE SHAFT Genuine Porsche Part - New (to order)
                                    # 6
                                    MPN: 9A710911600
                                    CHAIN SPROCKET INLET
                                    from £28.03
                                    from £28.03
                                    SPROCKET Genuine Porsche Part - New (to order)
                                    # 7
                                    MPN: N 10672001
                                    SOCKET HEAD BOLT WITH INNER M8X50 MULTIPOINT HEAD
                                    from £2.33
                                    from £2.33
                                    BOLT, WITH POLYGON SOCKET HD. Genuine Porsche Part - New (to order)
                                    12-POINT SOCKET Genuine Lamborghini - New In stock
                                    # 8
                                    MPN: N 91052201
                                    SOCKET HEAD COLLARED BOLT WITH M8X12 INNER MULTIPOINT HEAD
                                    from £1.58
                                    from £1.58
                                    SOCKET HD. SCREW WITH POLYGON Genuine Porsche Part - New In stock
                                    # 9
                                    MPN: 9A710941720
                                    ROLLER ROCKER ARM
                                    from £14.38
                                    from £14.38
                                    ROLLER ROCKER ARM Genuine Porsche Part - New (to order)
                                    # 10
                                    MPN: 95510565110
                                    COTTER, SPLIT
                                    from £2.16
                                    from £2.16
                                    This part replaces part number 99610512352
                                    COTTER, SPLIT Genuine Porsche Part - New (to order)
                                    # 11
                                    MPN: 95810542310
                                    EQUALIZING ELEMENT, HYDRAULIC
                                    from £10.49
                                    from £10.49
                                    Differential Case Genuine Porsche Part - New (to order)
                                    # 12
                                    MPN: 95510564110
                                    SPRING DISC
                                    from £8.99
                                    from £8.99
                                    SPRING SEAT Genuine Porsche Part - New (to order)
                                    # 13
                                    MPN: 95510567500
                                    VALVE STEM SEAL INLET
                                    from £26.81
                                    from £26.81
                                    This part replaces part number 99610511552
                                    VALVE GUIDE SEAL Genuine Porsche Part - New (to order)
                                    # 14
                                    MPN: 95510567520
                                    VALVE STEM SEAL OUTLET
                                    from £10.07
                                    from £10.07
                                    VALVE GUIDE SEAL Genuine Porsche Part - New (to order)
                                    # 15
                                    MPN: 95510511910
                                    VALVE SPRING
                                    from £8.01
                                    from £8.01
                                    VALVE SPRING Genuine Porsche Part - New (to order)
                                    # 16
                                    MPN: 9A710960120
                                    INLET VALVE
                                    INLET VALVE
                                    Supersession
                                    Supersession
                                    Genuine Porsche Part (no longer available to order)
                                    # 16
                                    MPN: PAB109601
                                    INLET VALVE
                                    from £39.55
                                    from £39.55
                                    This part replaces part number 9A710960120
                                    INLET VALVE Genuine Porsche Part - New (to order)
                                    # 17
                                    MPN: 9A710961120
                                    EXHAUST VALVE
                                    from £57.63
                                    from £57.63
                                    EXHAUST VALVE Genuine Porsche Part - New (to order)
                                    # 18
                                    MPN: 958109307
                                    AXIAL BEARING
                                    from £5.02
                                    from £5.02
                                    AXIAL BEARING Genuine Porsche Part - New (to order)
