Tank ventilation. (4820,4840, 4870,CXPA, CXRA,CXR, CWBA,CWB, CWCA,C)
porsche panamera 970 (2016) throttle body parts diagram

107-000 - THROTTLE BODY

Porsche Panamera 970 (2016) THROTTLE BODY Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    MPN: 94811014420
    GASKET
    (4820,4840, CXPA,CXRA, CXR)
    from £10.61
    from £10.61
    GASKET Genuine Porsche Part - New (to order)
    # 1
    MPN: 94811014402
    GASKET
    (4870,CWBA, CWB,CWCA,CWC)
    from £10.61
    from £10.61
    GASKET Genuine Porsche Part - New (to order)
    # 2
    MPN: 99760511601
    THROTTLE BODY
    (4820,4840, CXPA,CXRA, CXR)
    from £344.48
    from £344.48
    THROTTLE BODY Genuine Porsche Part - New (to order)
    # 2
    MPN: 94860511503
    THROTTLE BODY
    (4870)
    THROTTLE BODY Genuine Porsche Part - New (to order)
    # 2
    MPN: 94860511504
    THROTTLE BODY
    (CWBA,CWB, CWCA,CWC)
    from £478.08
    from £478.08
    THROTTLE BODY Genuine Porsche Part - New (to order)
    # 3
    MPN: 99991900501
    FILLISTER HD. SCREW
    6 X 50
    from £0.91
    from £0.91
    FILLISTER HD. SCREW Genuine Porsche Part - New (to order)
    # 4
    MPN: 94811002073
    breather line
    Tank ventilation | Discontinued part (4870)
    breather line Genuine Porsche Part - New (to order)
    # 4
    MPN: 94811002074
    breather line
    Tank ventilation (4870,CWBA, CWB,CWCA,CWC)
    from £204.44
    from £204.44
    breather line Genuine Porsche Part - New (to order)
    # 4
    MPN: 94811002075
    breather line
    Tank ventilation | No longer use the part here (CWBA,CWB, CWCA,CWC)
    breather line Genuine Porsche Part - New (to order)
    # 4
    MPN: 94811002023
    breather line
    Tank ventilation | Discontinued part (4820,4840)
    breather line Genuine Porsche Part - New (to order)
    # 4
    MPN: 94811002024
    breather line
    Tank ventilation (4820,4840, CXPA,CXRA, CXR)
    from £149.40
    from £149.40
    breather line Genuine Porsche Part - New (to order)
    # 4
    MPN: 94811002025
    breather line
    Tank ventilation | No longer use the part here (CXPA,CXRA, CXR)
    breather line Genuine Porsche Part - New (to order)
    # 5
    MPN: 94811022100
    THRUST RING
    from £12.37
    from £12.37
    THRUST RING Genuine Porsche Part - New (to order)
    # 6
    MPN: 94811003050
    LINE HOLDER
    Tank ventilation (4870,CWBA, CWB,CWCA,CWC)
    from £8.07
    from £8.07
    LINE HOLDER Genuine Porsche Part - New (to order)
    # -
    -
    TIE WRAP
    1,5 - 50 | Mount | Breather line | Tank ventilation | wiring conduit
    # 7
    MPN: 94811002720
    BRACKET
    Breather line | Mount | Cover for timing chain
    from £3.87
    from £3.87
    BRACKET Genuine Porsche Part - New (to order)
