Porsche Panamera 971 (2017) air spring Parts Diagram

402-010 - air spring

Porsche Panamera 971 (2017) AIR SPRING Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Price
# 1
MPN: 971616037G
suspension strut complete
LEFT
Supersession
Supersession
# 1
MPN: 971616038G
suspension strut complete
RIGHT
Supersession
Supersession
# 2
MPN: 971413031D
SUSPENSION STRUT, COMPLETE
additionally to be used items: 2x 3 |
D >> - 05.05.2019
# 2
MPN: 971413031F
SUSPENSION STRUT, COMPLETE
additionally to be used items: 2x 3 | D - 06.05.2019>>
Supersession
Supersession
# 3
MPN: 971413047C
CAP
SUSPENSION STRUT, COMPLETE
from £8.64
from £8.64
# 4
MPN: N 10628301
BOLT, HEX. HD. WITH SHOULDER
M12X90
from £3.38
from £3.38
# 5
MPN: N 10402904
shouldered hex. nut
M12
from £2.14
from £2.14
# 6
MPN: 971616751
AIR CONNECTION
| air line
from £12.34
from £12.34
# 7
MPN: 971698425
REPAIR KIT FOR AIR SPRING
comprising: | O-Ring 3x | thrust ring 1x | hex. nut 1x
from £18.59
from £18.59
# 8
MPN: 971616051F
SPRING CYLINDER
left (PR:E0A,E8A)
Supersession
Supersession
# 8
MPN: 971616052F
SPRING CYLINDER
right (PR:E0A,E8A)
from £764.98
from £764.98
# 8
MPN: 971616051G
SPRING CYLINDER
left (PR:E0W)
from £1,100.52
from £1,100.52
# 8
MPN: 971616052G
SPRING CYLINDER
right (PR:E0W)
from £1,100.52
from £1,100.52
# 30
MPN: N 10261311
HEX. NUT
M10
from £1.17
from £1.17
# 35
MPN: 00004320468
GREASE
for | O-Ring
Supersession
Supersession
