P0N1 (Standard rear axle) | P0N5 (Standard rear axle)
porsche 2020 (taycan 9j1-1) suspension sub-frame parts diagram

501-000 - SUSPENSION SUB-FRAME

Porsche 2020 (Taycan 9J1-1) Suspension sub-frame Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                      #
                      Part number
                      Description
                      Key
                      Price
                      # 1
                      MPN: 9J1 599 030 F
                      SUSPENSION SUB-FRAME
                      SUSPENSION SUB-FRAME
                      SUSPENSION SUB-FRAME Genuine Porsche Part - New (to order)
                      # 1
                      MPN: 9J1599030G
                      SUSPENSION SUB-FRAME D >>- 07.01.2021
                      P0N1 (Standard rear axle) | P0N5 (Standard rear axle)
                      from £1,353.93
                      from £1,353.93
                      SUSPENSION SUB-FRAME Genuine Porsche Part - New (to order)
                      # 1
                      MPN: 9J1599030H
                      SUSPENSION SUB-FRAME D - 08.01.2021>>
                      P0N1 (Standard rear axle) | P0N5 (Standard rear axle)
                      from £1,353.93
                      from £1,353.93
                      SUSPENSION SUB-FRAME Genuine Porsche Part - New (to order)
                      # 2
                      MPN: 9J1505541A
                      HYDRO-MOUNTING
                      from £61.91
                      from £61.91
                      MOUNTING Genuine Porsche Part - New (to order)
                      # 3
                      MPN: 9J1505543A
                      HYDRO-MOUNTING
                      from £75.01
                      from £75.01
                      MOUNTING Genuine Porsche Part - New (to order)
                      # 4
                      MPN: PAF912721
                      HEXAGON FLANGE SCREW M14X1.5X160X90 (COMBI)
                      from £6.79
                      from £6.79
                      HEXAGON FLANGE SCREW (COMBI) Genuine Porsche Part - New (to order)
                      # 5
                      MPN: 9J1599301D
                      CROSS MEMBER
                      P0N1 (Standard rear axle)
                      from £222.13
                      from £222.13
                      CROSS MEMBER Genuine Porsche Part - New (to order)
                      # 5
                      -
                      CROSS MEMBER STEERING SEE ILLUSTRATION: 503-000
                      P0N5 (Standard rear axle)
                      # 6
                      MPN: PAF009264
                      DISTANCE PIECE 12,2X28X23
                      P0N1 (Standard rear axle)
                      from £4.39
                      from £4.39
                      DISTANCE PIECE Genuine Porsche Part - New (to order)
                      # 7
                      MPN: N 10640301
                      Hex collared bolt M12X100
                      from £3.68
                      from £3.68
                      BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                      HEXAGON FLANGE BM12X1.5X100X90 Genuine Lamborghini - New In stock
                      # 8
                      MPN: N 91256501
                      FILLISTER HEAD BOLT WITH M12X1,5X75 MULTI-POINT SOCKET HEAD
                      from £3.40
                      from £3.40
                      FILLISTER HD. SCREW WITH Genuine Porsche Part - New (to order)
                      # 9
                      -
                      SCREW SET TRACK ROD SINGLE PARTS SEE ILLUSTRATION: 501-050
                      # 10
                      MPN: 9J1971843
                      CABLE HOLDER LEFT
                      from £5.26
                      from £5.26
                      CABLE HOLDER Genuine Porsche Part - New (to order)
                      # 10
                      MPN: 9J1971843A
                      CABLE HOLDER RIGHT
                      from £5.26
                      from £5.26
                      CABLE HOLDER Genuine Porsche Part - New (to order)
                      # 11
                      MPN: PAF100829
                      HEXAGON HEAD BOLT (COMBI) M6X16
                      from £0.61
                      from £0.61
                      This part replaces part number N 10082913
                      BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New In stock
                      # 12
                      MPN: 9J1971005A
                      CABLE HOLDER LEFT
                      from £8.34
                      from £8.34
                      CABLE HOLDER Genuine Porsche Part - New (to order)
                      # 12
                      MPN: 9J1971006A
                      CABLE HOLDER RIGHT
                      from £8.34
                      from £8.34
                      CABLE HOLDER Genuine Porsche Part - New (to order)
                      # 13
                      MPN: PAF100829
                      HEXAGON HEAD BOLT (COMBI) M6X16
                      from £0.61
                      from £0.61
                      This part replaces part number N 10082913
                      BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New In stock
