PA8F (Sports equipment) | P2EB (Disc brakes in rear) | P2ET (Disc brakes in rear)
porsche 2020 (taycan 9j1-1) disc brake 18 rear axle red parts diagram

603-005 - Disc brake 18 Rear axle red

Porsche 2020 (Taycan 9J1-1) Disc brake 18 Rear axle red Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                            #
                            Part number
                            Description
                            Key
                            Price
                            # 1
                            MPN: 9Y0615601B
                            Brake disc additionally to be used items: 1X 6
                            from £212.55
                            from £212.55
                            BRAKE DISC Genuine Porsche Part - New In stock
                            # 2
                            MPN: N 10456004
                            Hexagon socket head bolt, M6X12 self-locking
                            from £0.47
                            from £0.47
                            HEXAGON SOCKET HEAD BOLT, Genuine Porsche Part - New (to order)
                            # 3
                            MPN: 971615611E
                            Cover plate for brake disc left
                            from £12.67
                            from £12.67
                            COVER PLATE FOR BRAKE DISC Genuine Porsche Part - New (to order)
                            # 3
                            MPN: 971615612E
                            COVER PLATE FOR BRAKE DISC RIGHT
                            from £12.67
                            from £12.67
                            COVER PLATE FOR BRAKE DISC Genuine Porsche Part - New (to order)
                            # 4
                            MPN: PAF100829
                            HEXAGON HEAD BOLT (COMBI) M6X16
                            from £0.61
                            from £0.61
                            This part replaces part number N 10082913
                            BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New In stock
                            # 5
                            MPN: 9J1615423H
                            CALIPER WITHOUT BRAKE PADS LEFT REAR ALSO USE: 2X N 911 837 01 D >>- 11.03.2022 1X 9J1 698 995
                            P2EB (Disc brakes in rear) | PA8F (Sports equipment)
                            from £394.47
                            from £394.47
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 9J1615423M
                            CALIPER WITHOUT BRAKE PADS LEFT REAR ALSO USE: 2X N 911 837 01 D - 13.03.2023>>- 29.08.2023 1X 9J1 698 995
                            P2EB (Disc brakes in rear) | PA8F (Sports equipment)
                            from £427.05
                            from £427.05
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 9J1615423AC
                            CALIPER WITHOUT BRAKE PADS LEFT REAR RED 2X N 911 837 01 D - 30.08.2023>>1X 9J1 698 995
                            P2EB (Disc brakes in rear) | PA8F (Sports equipment)
                            from £427.05
                            from £427.05
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 9J1615424H
                            CALIPER WITHOUT BRAKE PADS RIGHT REAR ALSO USE: 2X N 911 837 01 D >>- 11.03.2022 1X 9J1 698 995
                            P2EB (Disc brakes in rear) | PA8F (Sports equipment)
                            from £394.47
                            from £394.47
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 9J1615424M
                            CALIPER WITHOUT BRAKE PADS RIGHT REAR ALSO USE: 2X N 911 837 01 D - 13.03.2023>>- 29.08.2023 1X 9J1 698 995
                            P2EB (Disc brakes in rear) | PA8F (Sports equipment)
                            from £427.05
                            from £427.05
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 9J1615424AC
                            CALIPER WITHOUT BRAKE PADS RIGHT REAR RED 2X N 911 837 01 D - 30.08.2023>>1X 9J1 698 995
                            P2EB (Disc brakes in rear) | PA8F (Sports equipment)
                            from £427.05
                            from £427.05
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 9J1615423L
                            CALIPER WITHOUT BRAKE PADS LEFT REAR ALSO USE: 2X N 911 837 01 D >>- 11.03.2022 1X 9J1 698 995
                            P2ET (Disc brakes in rear) | PA8F (Sports equipment)
                            from £470.50
                            from £470.50
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 9J1615423P
                            CALIPER WITHOUT BRAKE PADS LEFT REAR ALSO USE: 2X N 911 837 01 D - 13.03.2023>>- 29.08.2023 1X 9J1 698 995
                            P2ET (Disc brakes in rear) | PA8F (Sports equipment)
                            from £470.50
                            from £470.50
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 9J1615424L
                            CALIPER WITHOUT BRAKE PADS RIGHT REAR ALSO USE: 2X N 911 837 01 D >>- 11.03.2022 1X 9J1 698 995
                            P2ET (Disc brakes in rear) | PA8F (Sports equipment)
                            from £470.50
                            from £470.50
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 6
                            MPN: 9J1698451
                            1 SET OF BRAKE PADS FOR REAR DISK BRAKE ALSO USE: 4X N 911 837 01 2X 9J1 698 995
                            from £134.46
                            from £134.46
                            1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
                            # 6
                            MPN: 9J1698451E
                            1 SET OF BRAKE PADS FOR REAR DISK BRAKE ALSO USE: 4X N 911 837 01 2X 9J1 698 995
                            from £192.55
                            from £192.55
                            1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
                            # 7
                            MPN: 971907637A
                            SENDER WIRE (PAD WEAR INDICATOR)
                            from £24.80
                            from £24.80
                            This part replaces part number 958907637
                            SENDER WIRE (PAD WEAR INDICATOR) Genuine Porsche Part - New (to order)
                            # 8
                            MPN: N 91183701
                            SOCKET HEAD BOLT WITH INNER M12X1,5X115 MULTIPOINT HEAD
                            SOCKET HEAD BOLT WITH INNER M12X1,5X115 MULTIPOINT HEAD
                            Supersession
                            Supersession
                            Genuine Porsche Part (no longer available to order)
                            # 8
                            MPN: PAF911837
                            SOCKET HEAD BOLT WITH INNER M12X1,5X115 MULTIPOINT HEAD
                            from £8.40
                            from £8.40
                            This part replaces part number N 91183701
                            SCREW Genuine Porsche Part - New In stock
                            # 9
                            MPN: 9J1698995
                            CUP EXPANDER SPRING REPAIR SET
                            from £39.52
                            from £39.52
                            CUP EXPANDER SPRING Genuine Porsche Part - New (to order)
                            # 10
                            MPN: 9J1615701
                            connecting line
                            from £23.41
                            from £23.41
                            connecting line Genuine Porsche Part - New (to order)
                            # 11
                            MPN: 9J1698471
                            REPAIR SET 34MM 1 SET PROTECTIVE CAPS
                            from £10.38
                            from £10.38
                            REPAIR SET Genuine Porsche Part - New (to order)
                            REPAIR SET Genuine Lamborghini - New (to order)
                            # 12
                            MPN: 211611483
                            DUST CAP CONTAINS: 20 PC
                            from £3.60
                            from £3.60
                            dust cap - D >> - MJ 1983 Genuine Porsche Part - New (to order)
                            DUST CAP Genuine Lamborghini - New (to order)
                            # 13
                            MPN: 8A0615273
                            1 SET BLEEDER VALVES WITH DUST CAP
                            from £8.25
                            from £8.25
                            BLEEDER VALVE Genuine Porsche Part - New (to order)
                            BLEEDER SCREW Genuine Lamborghini - New (to order)
                            # 15
                            MPN: 00004330508
                            ASSEMBLY PASTE 1 TUBE 100 GRAM
                            from £17.99
                            from £17.99
                            This part replaces part number 00004302000
                            ASSEMBLY PASTE Genuine Porsche Part - New (to order)
                            # 17
                            MPN: N 91038002
                            SEALING PLUG M12X1,5X5
                            SEALING PLUG M12X1,5X5
                            from £3.66
                            from £3.66
                            THREADED PLUG Genuine Porsche Part - New (to order)
                            # 17
                            MPN: PAF 910 380
                            SEALING PLUG M12X1,5X5
                            from £4.55
                            from £4.55
                            SEALING PLUG Genuine Porsche Part - New (to order)
                            # 19
                            MPN: 9J1615133
                            CABLE HOLDER BRAKE PAD WEAR DISPLAY
                            from £9.76
                            from £9.76
                            CABLE HOLDER Genuine Porsche Part - New (to order)
