porsche 2020 (taycan 9j1-1) outer roof panel damping parts diagram

801-550 - Outer roof panel Damping

Porsche 2020 (Taycan 9J1-1) Outer roof panel Damping Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
        #
        Part number
        Description
        Price
        # -
        -
        FASTENERS CAR BODY SEE ILLUSTRATION: 801-020
        # 1
        MPN: 9J1817111 YGRV
        ROOF - PRIMED
        P3FA (Without roof insert (standard roof))
        from £701.88
        from £701.88
        # 2
        MPN: 9J1817285
        SOUND INSULATION FOR ROOF FRONT
        P3FA (Without roof insert (standard roof))
        from £25.49
        from £25.49
        # 3
        MPN: 9J1817120
        SOUND INSULATION FOR ROOF REAR
        P3FA (Without roof insert (standard roof))
        from £27.20
        from £27.20
        # 4
        MPN: 9J1817575 YGRV
        ROOF FRAME REAR FOR LOWER TRANSVERSE ROOF RACK - PRIMED
        from £193.04
        from £193.04
        # 5
        MPN: 9J1817133 YGRV
        ROOF REINFORCEMENT FRONT FOR TRANSVERSE ROOF RACK - PRIMED
        P3FA (Without roof insert (standard roof))
        from £236.88
        from £236.88
        # 5
        MPN: 9J1817133AYGRV
        ROOF REINFORCEMENT FRONT FOR TRANSVERSE ROOF RACK - PRIMED
        P3FG (Glass roof)
        from £236.88
        from £236.88
        # 6
        MPN: 9J1817163 YGRV
        Transverse roof rack rear - primed
        P3FA (Without roof insert (standard roof))
        from £193.04
        from £193.04
        # 7
        MPN: 9J1817287 YGRV
        ROOF FRAME REAR FOR UPPER TRANSVERSE ROOF RACK - PRIMED
        P3FA (Without roof insert (standard roof))
        from £201.78
        from £201.78
        # 7
        MPN: 9J1817287AYGRV
        ROOF FRAME REAR FOR UPPER TRANSVERSE ROOF RACK - PRIMED
        P3FG (Glass roof)
        from £201.78
        from £201.78
        # 8
        MPN: 9J1817122 YGRV
        TRANSVERSE ROOF RACK FRONT - PRIMED
        from £245.65
        from £245.65
