porsche 2022 (taycan 9j1-1) electrics sports seat parts diagram

817-525 - Electrics sports seat

Porsche 2022 (Taycan 9J1-1) Electrics sports seat Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
        #
        Part number
        Description
        Price
        # 1
        MPN: 9JA971365AH
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £73.40
        from £73.40
        # 1
        MPN: 9JA971365AJ
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £73.40
        from £73.40
        # 1
        MPN: 9JA971365AK
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WT (MirrorLink)
        from £69.18
        from £69.18
        # 1
        MPN: 9JA971365AL
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WT (MirrorLink)
        from £69.18
        from £69.18
        # 1
        MPN: 9JA971365AT
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £73.40
        from £73.40
        # 1
        MPN: 9JA971365BA
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £76.80
        from £76.80
        # 1
        MPN: 9JA971365BH
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £76.80
        from £76.80
        # 1
        MPN: 9JA971365BJ
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £76.80
        from £76.80
        # 1
        MPN: 9JA971365BK
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £76.80
        from £76.80
        # 1
        MPN: 9JA971365BL
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £76.80
        from £76.80
        # 1
        MPN: 9JA971365BT
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £76.80
        from £76.80
        # 1
        MPN: 9JA971365CA
        WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £76.80
        from £76.80
        # 2
        MPN: 9JA971366AH
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £78.49
        from £78.49
        # 2
        MPN: 9JA971366AJ
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £78.49
        from £78.49
        # 2
        MPN: 9JA971366AK
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WT (MirrorLink)
        from £78.49
        from £78.49
        # 2
        MPN: 9JA971366AL
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WT (MirrorLink)
        from £78.49
        from £78.49
        # 2
        MPN: 9JA971366AT
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £73.40
        from £73.40
        # 2
        MPN: 9JA971366BA
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £73.40
        from £73.40
        # 2
        MPN: 9JA971366BH
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £73.40
        from £73.40
        # 2
        MPN: 9JA971366BJ
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £73.40
        from £73.40
        # 2
        MPN: 9JA971366BK
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £73.40
        from £73.40
        # 2
        MPN: 9JA971366BL
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £73.40
        from £73.40
        # 2
        MPN: 9JA971366BT
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ0 (Without add. lights (interior lighting)) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £73.40
        from £73.40
        # 2
        MPN: 9JA971366CA
        WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
        PL0R (Right-hand drive) | PQQ1 (Ambient Interor Lighting) | PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £73.40
        from £73.40
        # 3
        MPN: 9J1971369B
        WIRING HARNESS FOR BACKREST LEFT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £62.26
        from £62.26
        # 3
        MPN: 9J1971369C
        WIRING HARNESS FOR BACKREST LEFT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WT (MirrorLink)
        from £62.26
        from £62.26
        # 3
        MPN: 9J1971369E
        WIRING HARNESS FOR BACKREST LEFT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £57.18
        from £57.18
        # 3
        MPN: 9J1971369H
        WIRING HARNESS FOR BACKREST LEFT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £62.26
        from £62.26
        # 3
        MPN: 9J1971369J
        WIRING HARNESS FOR BACKREST LEFT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £62.26
        from £62.26
        # 3
        MPN: 9J1971369L
        WIRING HARNESS FOR BACKREST LEFT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £62.26
        from £62.26
        # 4
        MPN: 9J1971370B
        WIRING HARNESS FOR BACKREST RIGHT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £62.26
        from £62.26
        # 4
        MPN: 9J1971370C
        WIRING HARNESS FOR BACKREST RIGHT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WT (MirrorLink)
        from £62.26
        from £62.26
        # 4
        MPN: 9J1971370E
        WIRING HARNESS FOR BACKREST RIGHT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WT (MirrorLink)
        from £57.18
        from £57.18
        # 4
        MPN: 9J1971370H
        WIRING HARNESS FOR BACKREST RIGHT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £62.26
        from £62.26
        # 4
        MPN: 9J1971370J
        WIRING HARNESS FOR BACKREST RIGHT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D3 (Seat ventilation in front) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £62.26
        from £62.26
        # 4
        MPN: 9J1971370L
        WIRING HARNESS FOR BACKREST RIGHT ADJUSTMENT
        PQ1J (Sports front seats) | P3PN (Power seat adjustment for both front seats with memory feature) | P4A0 (Without seat heater) | P4D0 (Without seat ventilation/massage seat) | P9WU (Mirror Link and RSE (preparation)) | P9WY (Mirror Link plus Wireless App plus RSE (preparation))
        from £62.26
        from £62.26
        # 5
        MPN: 992959747D TM0
        SWITCH MODULE FOR SEAT LEFT SEAT ADJUSTER PAINTED D >>- 03.10.2021 - BLACK
        PQ1J (Sports front seats)
        from £289.74
        from £289.74
        This part replaces part number 992959747D
        # 5
        MPN: 992959747H 1E0
        SWITCH MODULE FOR SEAT LEFT SEAT ADJUSTER GRAINED D - 04.10.2021>>- BLACK
        PQ1J (Sports front seats)
        from £289.74
        from £289.74
        # 6
        MPN: 992959748D TM0
        SWITCH MODULE FOR SEAT RIGHT SEAT ADJUSTER PAINTED D >>- 03.10.2021 - BLACK
        PQ1J (Sports front seats)
        from £289.74
        from £289.74
        This part replaces part number 992959748D
        # 6
        MPN: 992959748H 1E0
        SWITCH MODULE FOR SEAT RIGHT SEAT ADJUSTER GRAINED D - 04.10.2021>>- BLACK
        PQ1J (Sports front seats)
        from £289.74
        from £289.74
        # 7
        -
        PANEL SCREW 4,2X9,5 INCLUDED IN ILLUSTRATION, POSITION: 817-120,5
        # 8
        MPN: PAD947415
        LED LIGHT
        from £19.73
        from £19.73
        # 9
        MPN: PAB963575
        BLOWER FOR SEAT UPPER/LOWER VENTILATION COMPONENT
        P4D3 (Seat ventilation in front)
        from £173.64
        from £173.64
        # 10
        MPN: 971881537
        BRACKET BACKREST
        P4D3 (Seat ventilation in front)
        from £13.92
        from £13.92
        # 11
        MPN: 971881538A
        BRACKET SEAT CUSHION
        P4D3 (Seat ventilation in front)
        from £18.88
        from £18.88
        # 13
        MPN: 992963553A
        SEAT OCCUPIED SENSOR
        PL0L (Left-hand drive) | P9P2 (Seat belt reminder India) | P9P3 (Seat belt reminder, electric contact in buckle) | P9P6 (Seat belt reminder, electric contact in buckle)
        from £54.34
        from £54.34
        # 14
        MPN: PAB959760E
        Control unit front Seat adjuster
        from £598.91
        from £598.91
